Adurofire Aduro 9
ADURO 9
ADURO 9
An impressively large glass area is achieved by adding side panes and minimising the bars between the glass in the door and the glass at the sides. Visual access to the living fire has been a crucial parameter
all the way – so an efficient air-wash system ensures that soot doesn’t collect on the glass at the front or sides. This is a timeless and elegant fixture for modern homes.
ADURO 9 AIR
Aduro 9 is also available in a version with an external air supply. This version is particularly suitable for houses that are very well-insulated.
INFORMATION
NOMINAL POWER
6,0 kW
OPERATIONAL AREA
3-9 kW
HEATS
30-140 m2
ENERGY EFFICIENCY
81,3%
ENERGY CLASS
A+
FLUE OUTLET TOP/REAR
Ø150 mm
DISTANCE TO COMBUSTIBLE MATERIAL TO FURNITURE
80 cm
WEIGHT
93 kg
DISTANCE FROM CENTRE OF EXHAUST BRANCH TO REAR EDGE OF WOOD BURNING STOVE
19,3 cm
DISTANCE FROM BOTTOM TO CENTRE OF REAR OUTLET
84 cm
DISTANCE TO COMBUSTIBLE MATERIAL AT SIDE
70 cm
DISTANCE TO COMBUSTIBLE MATERIAL BEHIND
20 cm
DIMENSIONS
- Height : 95,8cm
- Width :50cm
- Depth : 44,7cm
- Width of wood chamber : 40 cm
- Max log length : 39 cm
DISTANCE TO COMBUSTIBLE MATERIAL
