Handheld Flir Est™ Thermal Screening Solutions
The FLIR T540-EST handheld thermal camera is a non-contact screening tools that serve as a first line of defense against potential health risks. This 464 × 348 pixel resolution FLIR EST™ thermal screening solution detects and visualizes heat to quickly identify individuals with an elevated skin temperature.
Battery-powered and featuring an integrated touchscreen display, the T540-EST sets up quickly and easily for operation in temporary or mobile screening settings. The on-camera FLIR Screen-EST Mode offers visual positioning guides, automatic sampling to maintain an updated temperature average, and graphic pass/fail indicators for results, reducing the burden on screening station operators. Compatibility with FLIR Screen-EST Desktop software, an integrated tripod mount, and external power makes this camera a good fit for permanent installations.
INFORMATION
DISPLAY TECHNOLOGY
IPS
FIELD OF VIEW (FOV)
42° × 32°
IR RESOLUTION
464 × 348
HOUSING MATERIAL
Pcabs With Tpe, Magnesium
OBJECT TEMPERATURE RANGE
15°C to 45°C (59°F to 113°F)
PALETTE
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC
SIZE (L X W X H)
Lens Horizontal: 140 × 201.3 × 167.3 mm (5.5 × 7.9 × 6.6 in)
WEIGHT
1.3 kg (2.9 lb)
FLIR SCREEN-EST MODE
Yes
PROGRAMMABLE BUTTONS
2
COVER GLASS MATERIAL
Dragontrail®
DISPLAY
4 in., 640 × 480 optically-bonded PCAP touchscreen, with 400 cd/m2 surface brightness
THERMAL SENSITIVITY_NETD
<30 mK @ 30°C (86°F)
IMAGE FILE FORMAT
Standard radiometric JPEG, measurement data included
ACCURACY [DRIFT] IN SCREEN-EST MODE
±0.3°C (±0.5°F)
SAMPLING AVERAGE IN SCREEN-EST MODE
Recommended range: 30 to 45°C (86 to 113°F) in stable room temperature
MAINTAIN SAFETY AND PRIVACY
On-camera FLIR Screen-EST Mode does not store images or personal information and allows for social distancing in screening setups.
EASY SET-UP AND OPERATION
Begin screening quickly with limited ramp-up time, simple video connectivity, and choice of >4-hour battery or external power.
FAST, ACCURATE SCREENING
Optimal screening accuracy with automatic ambient drift compensation, visual pass/fail graphic indicators, and audible alarms.
MEASUREMENT & ANALYSIS
- Languages : 21
- Measurement Corrections : Yes
- Reference Temperature : Yes
- Automatic hot & cold detection : Auto-maximum/minimum markers within area
PACKAGING
Infrared camera with lens, front and rear lens caps, cleaning cloth, rechargeable battery (2 ea.), battery charger, power supplies, straps (lens cap, neck), hard transport case, cables (USB 2.0 A to USB Type-C, USB Type-C to USB Type-C,USB Type-C to HDMI and PD adapter), USB-C to USB-A with power supply included, remote operation button, 8 GB SD card, printed documentation
CONNECTIONS AND COMMUNICATIONS
- Communication Interfaces : USB 2.0, Bluetooth Wi-Fi
- Remote Control : Bluetooth®-enabled remote operation button
- Storage Media : Removable SD card (8 GB)
- USB : USB Type-C: data transfer/video/powerUSB - StandardUSB 2.0 High Speed
- Video Out : DisplayPort over USB Type-C
- WiFi : Peer to peer (ad hoc) or infrastructure (network)
- Setup Commands : Local adaptation of units, language, date and time formats
- Command and Control : On-camera screen, USB Type-C
ENVIRONMENTAL
- Drop : Designed for 2 m (6.6 ft)
- Emissivity Correction : Yes: variable from 0.01 to 1.0 or selected from materials list
- Operating Temperature Range : -15°C to 50°C (5°F to 122°F)
- Radio Spectrum : ETSI EN 300 328/FCC Part 15.249/RSS-247 Issue 2
- Safety : EN/UL/CSA/PSE 60950-1
- Storage Temperature Range : -40°C to 70°C (-40°F to 158°F)
- Tripod Mounting : UNC ¼"-20
- Shock & Vibration & Encapsulation : 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1
POWER
- Battery Life : (Operating)>4 hours at 25°C (77°F) and typical use
- Battery size : (L x W x H)59 × 66 × 94 mm (2.3 × 2.6 × 3.7 in)
- Battery Type : Rechargeable Li ion battery
- Battery voltage : 3.6 V
- Battery weight : 195 g (6.89 oz)
- Charging Temperature : 0°C to 45°C (32°F to 113°F)
- Charging Time (using two-bay charger) : 3.5 hours to 90% capacity with charging status indicated by LEDs
- External Power Operation : USB 2.0 A to USB Type-C with Power supply
- Power Management : No
IMAGING AND OPTICAL
- Aspect ratio : 4:3
- Auto Rotation : Yes
- Camera f-number : 1.1
- Camera software update : Using USB cable or SD card
- Color : Black
- Color depth (bits) : 24
- Detector Type and Pitch : Uncooled microbolometer, 17 µm
- Digital Data Streaming : USB Type-C
- Digital Zoom : 1-6x continuous
- Focal Length : 10 mm (0.39 in)
- Focus : Continuous laser distance meter (LDM), one-shot LDM, one-shot contrast, manual
- Frame Rate : 30 Hz
- Image Modes : Infrared, visual, MSX°, picture-in-picture
- Lens : 42°
- Lens Identification : Automatic
- Minimum Focus Distance : 0.15 m (0.49 ft)
- Spatial resolution (IFOV) : 1.66 mrad/pixel
- Spectral Range : 7.5–14 µm
- Viewfinder : No
- MSX : YesUltraMaxYesViewing Angle80°
