Charnwood C-four Insert Stoves

C-FOUR INSERT STOVES

Charnwood C-four Insert Stoves

C-FOUR INSERT

Stoves

Based on the free standing C-Four, this stove is designed to fit into a standard fireplace.

Featuring a single air control and an integrated outlet for ducting external air, the C-Four Insert burns exceptionally clean with outstanding efficiency.

This stove also features our renowned converting grate for efficient multi fuel burning and meets the DEFRA requirements for smoke control exemption; allowing wood to be burnt in smoke control areas.

Charnwood C-four Insert Stoves
Charnwood C-four Insert Stoves
Charnwood C-four Insert Stoves

C-SERIES FAMILY

The C-Series is one of Charnwood’s latest innovations. A range of classically styled wood burning stoves that feature one single air control and an integrated inlet for ducting external air to improve performance and efficiency. There are six stoves within the C-Series.

INFORMATION

TECHNOLOGY

Cleanburn Airwash Technology

WEIGHT

100 kg

MAXIMUM LOG LENGTH

- 332 mm
- 13” Inches

NET EFFICIENCY

80 %

OUTPUT

5.0 kw (Range 2-5.5 kw)

MATERIALS

- Plate Steel
- Cast Iron
- Ceramic Glass

AVERAGE REFUELLING CYCLE

0.75 hrs, 1.0 hr

FLUE GAS MASS FLOW

4.4 g/s, 4.3 g/s

FLUE GAS TEMPERATURE

- 279°C
- 282°C

MIN DISTANCE  COMBUSTIBLES

- Side : 280 mm
- Rear : 310 mm

PRODUCTION

Made In England

COLORS

Eight Colors

FEATURES

- Cleanburn Airwash Technology
- Sia Eco Design Ready Model Available
- Single Air Control And An Integrated Outlet For Ducting External Air
- Defra Exempt Model For Burning Wood In Smoke Control Areas
- Drop Down Throat Plate Enabling The Chimney To Be Swept Through The Stove

TECHNICAL DRAWINGS

Charnwood C-four Insert Stoves

MAINTENANCE AND CLEANING

-Glass : Wipe With Damp, Lint Free Cloth. Any Stubborn Deposits On The Glass May Be Removed With A Proprietary Stove Glass Cleaner Or Ceramic Hob Cleaner. -Throat Plate : Take Down Once A Month And Clean. Sweep Sooty Deposits Into Fire. -Ash Pan : Ash Pan Is Removed Using Tool Provided. Empty Ash Pan Before Ash Comes Into Contact With Underside Of Grate. -Chimney : Have Chimney Swept Twice A Year. Chimney Can Be Swept Through Stove. -Servicing : Stove Should Be Serviced By A Professional At Least Once A Year.

COLORS

-Black -Almond -Blue -Bronze -Brown -Green -Gunmetal -Pewter

Charnwood C-four Insert Stoves
Black
Charnwood C-four Insert Stoves
Almond
Charnwood C-four Insert Stoves
Blue
Charnwood C-four Insert Stoves
Bronze
Charnwood C-four Insert Stoves
Brown
Charnwood C-four Insert Stoves
Green
Charnwood C-four Insert Stoves
Gunmetal
Charnwood C-four Insert Stoves
Pewter
