INTERCOM - 2N® IP VERSO
INTERCOM - 2N® IP VERSO
The 2N® IP Verso security intercom is configurable to your needs thanks to its modularity.
It provides reliable access control and allows you to easily interface with other systems, achieving even higher site security.
Available also in black, with a fingerprint reader, Bluetooth module, or touch display.
- Progressive mobile access
- Touchscreen
- Camera with night vision
INFORMATION
APPLICATIONS
Internal, external
USE
Security Intercom
CHARACTERISTICS
Robust metal body, fast help in case of emergency, high intelligibility, automatic audio loop test, integration into an existing system
APPLICATION AND USE IN CONSTRUCTION
Exterior / Outdoor, Interior
SIZES
- 217 x 109 x 83 mm
- 242 x 136 x 83 mm incl. frame
FEATURES & BENEFITS
PROGRESSIVE MOBILE ACCESS
Captivate your customers with the speed and convenience of WaveKey – our Bluetooth access control technology. You can forget about distributing keys and RFID cards once and for all.
FINGERPRINT READER
Provide maximum access security for your building using modern, completely secure, and reliable access technology combined with luxury design.
INTUITIVE CONTROLS AND SEARCH
The touchscreen has all the functions of a mechanical keyboard. Discover its luxury design and intuitive controls and search.
MODULARITY
The modularity of this IP intercom allows you to configure it to your requirements. Select the specific module,accessories and configurable functions.
SIP SUPPORT WITH NO SERVER NEEDED
SIP protocol support makes it easy to link the intercom with IP phones and PBX from other producers, without having to connect to the server.
PICTURE TO EMAIL
2N® IP Verso allows you to email snapshots of the visitor captured by the camera at the time of the call.
EXTERNAL CAMERA
Simply connect an external IP camera to the intercom to cover all the blind spots.
CALLS TO MOBILE PHONE AND TABLET
The 2N® Mobile Video cloud service allows the 2N® IP Verso intercom to call a mobile phone or tablet.
TOUCH KEYPAD
A highly sensitive touch keypad reliably records and evaluates every touch and ensures access to the building via the entered PIN.
TOUCHSCREEN
Create an intuitive and structured contact list similar to that in your mobile phone. It is water resistant vandal resistant and easy to read even in direct sunlight.
ACCESS CONTROL
Achieve a greater level of security for all those at its location. 2N® IP Verso makes it easy to prevent the entry of unauthorized persons.
TROUBLE-FREE INSTALLATION
The IP intercom by 2N is so intuitive that it can easily be installed by a user with only basic knowledge of IT.
SECURITY RELAY
This simple additional device prevents intrusion by detecting any unauthorized manipulation of the electronic locking system.
CAMERA WITH NIGHT VISION
See who is standing in front of your door, even in total darkness. Moreover, the camera is hidden from normal view. The intruder has no clue they’re being monitored.
SUITABLE FOR THE DISABLED
The device can be fitted with an induction loop and pictograms suitable for communication with the hearing impaired.
INTEGRATION TO THE SECURITY SYSTEM
Easily link the intercom to the existing security system and increase site security.
TECHNICAL PARAMETERS
BUTTONS
- Buttons: Transparent buttons with white backlight and easily removable label
- Number of buttons: 1 to 146
- Numeric keypad: optional
SIGNALLING PROTOCOL
SIP 2.0 (RFC - 3261)
FINGERPRINT READER (OPTIONAL)
- Sensor: Optical sensor protected by resistant glass
- Reliability: Algorithm for fake fingerprint detection
- Resistance: Resistant to water and dust
- Status signalisation: Acoustic and with the aid of multicoloured LEDs
- Sensing area: large with dimensions of 15.24 x 20.32mm
- Operating temperature: -20°C - 55°C
- Certification: FBI PIV
VIDEO STREAM
Codecs: H.263+, H.263, H.264, MJPEG, MPEG-4
AUDIO STREAM
Codecs: G.711, G.729, G.722, L16/16kHz
BLUETOOTH READER (OPTIONAL)
Bluetooth Smart technology
- Security: Range:RSA-1024 and AES-128
- Range: (short - typically up to 3m*, long - typically up to 10m*)
*distances should serve only as an approximate guide and may vary depending on the phone model and installation environment
MECHANICAL PROPERTIES
- Operating temperature: -40°C – 60°C
- Storage temperature: -40°C – 70°C
- Operating relative humidity: 10%-95%
- Officially certified outdoor coverage level: IP54, IK08
TOUCHSCREEN (OPTIONAL)
- Buttons and keyboard functions
- Operating temperature: -20°C – 60°
- Coverage level: IK07
SURFACE MOUNTING FRAME – DIMENSIONS
- 1 module: 107 (W) x 130 (H) x 28 (D) mm
- 2 modules: 107 (W) x 234 (H) x 28 (D) mm
- 3 modules: 107 (W) x 339 (H) x 28 (D) mm
AUDIO
- Microphone: 1 built-in microphone
- Speaker: 2W
- Sound pressure at 1kHz at 1m distance: 78dB
FLUSH MOUNTING FRAME – DIMENSIONS
1 module: 130 (W) x 153 (H) x 5 (D) mm
2 modules: 130 (W) x 257 (H) x 5 (D) mm
3 modules: 130 (W) x 361 (H) x 5 (D) mm
FLUSH MOUNTING BOX (MINIMUM HOLE DIMENSIONS)
1 module: 108 (W) x 131 (H) x 45 (D) mm
2 modules: 108 (W) x 238 (H) x 45 (D) mm
3 modules: 108 (W) x 343 (H) x 45 (D) mm
INTERFACES
- Power supply: 12V ± 15%/ 2A DC, or PoE
- PoE: PoE 802.3af (Class 0 - 12.95W)
- LAN: 10/100BASE-TX with Auto-MDIX, RJ-45
- Switch output: NC/NO contacts, max 30V/1A AC/DC
- Active switch output: 8 to 12V DC depending on Power supply (PoE: 10V; adapter: source voltage minus 2V), max 400mA
- Passive / active input: 1; (-30 V to +30 V)
- Tamper switch: optional accessory
- Supported protocols: SIP2.0, DHCP opt. 66, ONVIF, SMTP, 802.1x, RTSP, RTP, TFTP, HTTP, HTTPS, Syslog
USAGE
VIDEO DOOR COMMUNICATORS FOR YOUR HOME
A stylish door intercom by 2N will always provide a proper welcome for your visitors. In addition to its modern design, created using extremely durable materials, you are sure to appreciate its unique functions.
You will not only increase your home’s security, but afford your loved ones a feeling of safety.
- See your visitors on screen thanks to the hidden HD camera
- Excellent clarity, even in a noisy environment
- Access control system integrated in the intercom
RESIDENTIAL VIDEO DOOR COMMUNICATION
Welcome your visitors in style. Choose the stylish door intercom from 2N.
You will see the benefit not only of increased security for your loved ones, but also the modern design, ground-breaking functionality and materials that are resilient to the utmost.
- Excellent intelligibility even in noisy environments
- The highest durability on the market
- Wide-angle colour camera with CCTV link
2N IS NOT JUST AN INTERCOM BY THE DOOR
Don’t miss your chance to offer your customers an integrated access control solution for commercial projects. Our 2N Virtual Experience will show you how to use all the products in our IP portfolio.
