Haier 90 cm, T-Shaped - Hood Kitchen Appliance
T-SHAPED - HOOD KITCHEN APPLIANCE
T-SHAPED - HOOD KITCHEN APPLIANCE - HIH-T90HM-V
- Heat Auto Clean
- Gesture Control
- Touch Control
FEATURES
HEAT AUTO CLEAN
The oil/grease melts under high temperature and flows to the oil collector. As a result, it improves the efficiency of the chimney.
W SHAPED DOUBLE FILTER
The innovative “W” shaped double filter ensures the oil drops flow into the oil cup freely. As a result, it increases the air intake and filtration area by 110%.
MOTION CENSOR AND TOUCH CONTROL
Motion Censor and Touch Control enables easy operation of the chimney with just a wave of your hand.
AIRFLOW
It comes with 1350m³/h suction power and a 90cm tempered glass panel that easily vent out the unwanted smoke in the kitchen.
DEEP PYRAMID CAVITY FILTER
The suction effect of Haier's Deep Pyramid Cavity Design is much faster than that of a traditional hood leaving no space for smoke in your kitchen.
INFORMATION
BRAND
Haier
MODEL NO
HIH-T90HM-V
AIRFLOW
1350 CMH（m³/h）
LTER TYPE
Filter Less Concept
AIR PRESSURE
Maximum Air Pressure 380 Pa (Pascal)
COMPATIBILITY
90 CM – 3/4/5 Burner Hob/Tablet (90/76/75/65 & 60 cm)
LAMP
1 x 1.5 W LED Lamp
NOISE LEVEL
58 db
MOTOR POWER (W)
280 W
SEGMENT
T-Shaped-Hood
CAPACITY
90 Cm
DOWNLOAD
↓ 05 user manual HIH-T90HM-V
ALUMINIUM EXHAUST VENTILATION PIPE
Complimentary 1.5 Mtr. X 2 Aluminium Foil (Exhaust Ventilation Pipe)
DIMENSIONS
- Width : 900 mm
- Height : 580 mm
- Depth : 450 mm
WARRANTY
2 Yrs. Comprehensive* & additional 4 Yrs. on Motor & Rotor
