Gaggenau Culinary Warming Drawer 400 Series

CULINARY WARMING DRAWER 400 SERIES

CULINARY WARMING DRAWER 400 SERIES

WS061102

- Integrable in 14 cm high niche
- Cushioned closing system
- Hygienic stainless steel interior with glass bottom
- For slow cooking, dough proofing, herbs and fruits drying, chocolate melting and defrosting

Gaggenau Culinary Warming Drawer 400 Series

INFORMATION

HANDLING

Touch Key Operation

TIME CONTROL

No

CODE

WS061102

VARIANTS

Fully Integrated

VOLTAGE

220-240

FUSE PROTECTION

10

POWER LEVEL

0.820

DIMENSIONS

140 x 590 x 514

FREQUENCY

50; 60

NET WEIGHT

17.3

Gaggenau Culinary Warming Drawer 400 Series

GROSS WEIGHT

19.8

LENGTH OF ELECTRICAL SUPPLY CORD (IN)

71 ''

Gaggenau Culinary Warming Drawer 400 Series

DIMENSIONS OF THE PACKED PRODUCT

250 x 660 x 700

MIN. REQUIRED NICHE SIZE FOR INSTALLATION

140 x 560 x 550

CHARACTERISTICS

- Built-in
- Free-standing

PLUG TYPE

- Gardy plug w
- Earthing

COLOR / MATERIAL FRONT

Maximum number of plates : 6

MAXIMUM NUMBER OF ESPRESSO CUPS

64

LENGTH ELECTRICAL SUPPLY CORD

175

REQUIRED CUTOUT/NICHE SIZE FOR INSTALLATION (IN)

x x

DETAILS

FEATURES

- Net volume 20 litres.
- Volume capacity : Dinner service for 6 people including ø 27 cm plates and soup bowls, additional bowls and a serving dish depending on size. Capacity load max. 25 kg.
- Usable interior dimensions W547 mm x H 91 mm x D 410 mm.
- Heating system for even heat distribution and stable cavity temperature.
- Status display, visible in the glass front. Glass bottom made of safety glass.

SELECTED DIGITAL SERVICES (HOME CONNECT)

- Additional programmes and recipes. Remote control and monitoring. Timing function.
- Home network integration for digital services (Home Connect) wireless via WiFi.
- The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: homeconnect.com.

PLANNING NOTES

- Attention : To open the fully integrated variant, a handle or a recessed grip is necessary
- Front weight up to 3 kg
- The socket can be planned behind the appliance.

CONNECTION

- Total connected load 0.82 KW
- Connection cable 1.8 m, pluggable.

HEATING METHODS

- Slow cooking.
- Keeping meals warm.
- Warming ovenware.
- Cups and plates warming.
- Direct temperature control.
- Personalisation function via Home Connect.
- 16 additional programs via Home Connect.

TECHNICAL DIAGRAM
