Vortice Ariett I Bathroom Fan

ARIETT I BATHROOM FAN

Vortice Ariett I Bathroom Fan

ARIETT I BATHROOM FAN

Suitable for use with 100mm diameter ducting and flat ducting (FD100 – 110 x 55). Flexible aluminium and flexible insulated.

information

BRAND

Vortice

PRODUCT TYPE

Bathroom Fan

CODE

12012

INSULATION CLASS

II°

ABSORBED CURRENT MAX

0.13 (A)

ABSORBED POWER

Max. 19 W

FREQUENCY

50 hz

VOLTAGE

230 V

WEIGHT

1.9 kg

RPM

2360

RPM SIDE AIR OUTLET

2460 max speed

USE

Bathroom

IP

X4

Ø DISCHARGE HOLE

96.5 mm

NOMINAL DIAMETER

100 mm

MAX AMBIENT TEMPERATURE

50 °C

Vortice Ariett I Bathroom Fan

MAX AMBIENT TEMPERATURE

- 40 (°C)

MAX. ABSORBED POWER

19 (W)

CERTIFICATIONS

-I
MQ -CE

IMQ PERFORMANCE

EAC

MATERIAL

UV resistant plastic (prevents ageing caused by exposure to sunlight).

PRESSURE MAX

- 4,7 (mmH2O)
- 46,09 (Pa)

DELIVERY MAX

- 18,1 (l/s)
- 65 (m³/h)

MAXIMUM AIR FLOW

- Rear: 80 m3/h
- Side: 70 m3/h

VERTICAL OUTLET

 Vertical outlet port supplied as standard with spigot positionable horizontally by means of divert.

MOTOR PROTECTED

Motor with thermal overload protection and shaft turning in ball bearings

DIMENSIONS

Vortice Ariett I Bathroom Fan
SIZENO.
Size A (mm)252
Size B (mm)23
Size C (mm)65
Size D (mm)214.5
Size E (mm)135.3
Size F (mm)31.5/76.7
Size G (mm)Ø 96.5
Size H (mm)180
Size L (mm)92
Size M (mm)76

DETAIL

- Rear outlet port equipped with non-return damper
- IMQ SAFETY and IMQ PERFORMANCE certifications
- Vortice speed controller

FEATURES

- Two speeds
- Suitable for wall and ceiling installation
- For intermittent extract of bathrooms, shower rooms, en suites, w.c’s
- Suitable for ducting up to roof tile vents
- Contains integral backdraught shutter
- IPX4 splash proof protection on all models
- The standard models can be speed regulated
- Recessed models contain a metallic washable filter
