CANON EOS 5D MARK IV DSLR CAMERAS

Canon Eos 5d Mark Iv DSLR Cameras

CANON EOS 5D MARK IV DSLR CAMERAS

No matter what you’re shooting, be assured of uncompromising image quality and a thoroughly professional performance.

PURSUE PERFECTION

Designed to perform in every situation, the EOS 5D Mark IV is beautifully engineered and a thoroughly accomplished all-rounder.

Canon Eos 5d Mark Iv DSLR Cameras

FEATURES

ENGINEERED FOR PERFORMANCE

Legendary cameras are built to last, and the EOS 5D series brought superior build quality, performance and advanced weathersealing1 to a new breed of photographers. The EOS 5D Mark IV continues that commitment to high speed performance and durability.

Canon Eos 5d Mark Iv DSLR Cameras

THE DIFFERENCE IS IN THE DETAIL

From the moment light passes through the lens, the EOS 5D Mark IV captures every nuance, every colour, every detail. Once again Canon has brought finer dimensions in detail thanks to a new sensor capable of extraordinary clarity. See your world like never before.

Canon Eos 5d Mark Iv DSLR Cameras

PRECISION AS STANDARD

The EOS 5D Mark IV features advanced focusing and metering which captures moments and tracks them the instant they happen, even in difficult lighting.

Canon Eos 5d Mark Iv DSLR Cameras

STEP UP TO CINEMATIC 4K

Unleash the 4K filmmaker in you and add 4K EOS Movie to your creative portfolio.

STAY CONNECTED

Connect and share your images with ultra-fast USB 3.0, WiFi and NFC workflows.

Canon Eos 5d Mark Iv DSLR Cameras

CANON AIMS TO ACHIEVE NET-ZERO CO2 EMISSIONS FROM ITS BUSINESS ACTIVITIES BY 2050

We will achieve this by delivering an average improvement of 3% per year in the lifecycle CO2 emissions improvement index per product. Which if sustained would mean roughly a 50% reduction from 2008 levels by the year 2030. We recognise this to be in line with the level of reduction called for by the Paris Agreement.

We will continue to undertake target reviews from a long-term perspective as a way of checking our contribution to the realisation of a low-carbon society.

Canon Eos 5d Mark Iv DSLR Cameras

CANON PHOTO COMPANION APP

The ultimate partner to any visual storyteller, our Photo Companion app gives you access to tailored, expert knowledge and content when you need it most – so you can truly bring your stories to life.

Canon Eos 5d Mark Iv DSLR Cameras

INFORMATION

LENS

-Lens Mount : EF (excludes EF-S / EF-M lenses)
-Focal length : Equivalent to 1.0x the focal length of the lens

SUPPORTED OPERATING SYSTEM

PC & Macintosh :  Windows 7 SP1 (excl. Starter Edition), Windows 8.1 and Windows 10 OS X v10.9-10.11

STORAGE

Type : 1x CompactFlash Type I (UDMA 7 compatible) (Incompatible with Type II and Microdrive)
1x SD/SDHC/SDXC and UHS-I

SOFTWARE

-Image Processing : Digital Photo Professional 4.5 or later (RAW Image Processing)
-Other : EOS Utility 3.5 or later (inc. Remote Capture ), Picture Style Editor, Map Utility, EOS Lens Registration Tool, EOS Web Service Registration Tool, Canon Camera connect app (iOS/ Android)

Canon Eos 5d Mark Iv DSLR Cameras

POWER SOURCE

-Batteries : Rechargeable Li-ion Battery LP-E6N (supplied) / LP-E6
-Battery life : Approx. 900 shots (at 23°C)12Approx. 850 (at 0°C)
-Battery Indicator : 6 levels + percentage
-Power saving : Power turns off after 1, 2, 4, 8, 15 or 30mins
-Power Supply & Battery Chargers : Battery charger LC-E6E (supplied), Battery charger LC-E6, AC Adapter AC-E6N and DC Coupler DR-E6, AC Adapter Kit ACK-E6N/ACK-E6, Car Battery Charger CBC-E6

SHUTTER

-Type : Electronically-controlled focal-plane shutter
-Speed : 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
-Shutter Release : Soft touch electromagnetic release

DIMENSIONS

- Height : 116.4 mm
- Width : 150.7mm
- Depth : 75.9 mm

Canon Eos 5d Mark Iv DSLR Cameras

WEIGHT (BODY ONLY)

Approx. 800 g

OPERATING ENVIRONMENT

0 – 40 °C, 85% or less humidity

  IMAGE SENSOR

-Aspect Ratio : 3:2
-Low-Pass Filter : Built-in/Fixed
-Type : 36 x 24 mm CMOS
-Total Pixels : Approx. 31.7 megapixels
-Colour Filter Type : RGB Primary Colour
-Effective Pixels : Approx. 30.4 megapixels
-Sensor Cleaning : Manual cleaning and Dust Delete Data acquisition

IMAGE PROCESSOR

Type : DIGIC 6+

DIRECT PRINT

PictBridge : Yes (Via Wireless LAN only)

WHITE BALANCE

-Type : Auto white balance with the imaging sensor
-Custom White Balance : Yes, 1 setting can be registered
-WB Bracketing : +/-3 levels in single level increments, 3, 2, 5 or 7
-White balance compensation: Blue/Amber +/-9, Magenta/ Green +/-9. bracketed images per shutter release, Selectable Blue/Amber bias or Magenta/ Green bias
-Settings : AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom (Approx. 2000 K - 10000 K).

SPECIFICATIONS

- 30.4MP CMOS
- Dual Pixel RAW
- Dual Pixel CMOS AF
- 7 frame per second
- 150,000 pixel metering sensor
- GPS
- Wi-Fi / NFC
- EOS Movie 4K + Full HD

INTERFACE

-Computer : SuperSpeed USB 3.0
-Wi-Fi : Wireless LAN (IEEE802.11b/g/n), (2.4 GHz only), with Dynamic NFC support11 Features supported - FTP/FTPS, EOS Utility, SmartPhone, Upload to Web , Wireless printing
-Other : HDMI mini out (Type C, HDMI-CEC compatible), External Microphone In / Line In (Stereo mini jack), Headphone socket (Stereo mini jack), N3-type terminal (remote control terminal)

Canon Eos 5d Mark Iv DSLR Cameras

ACCESSORIES

-Lenses : All EF lenses (excluding EF-S / EF-M lenses)
-Wireless File Transmitter : Wireless File Transmitter WFT-E7B
-Other : BG-E20 battery grip, Hand Strap E2, Connect Station CS100
-Flash : Canon Speedlites (90EX, 220EX, 270EX, 270EX II, 320EX, 380EX, 420EX, 430EX, 430EX II, 430EX III 550EX, 580EX, 580EX II, 600EX, 600EX-RT, 600EX-II-RT, Macro-Ring-Lite MR-14EX, Macro Ring Lite MR-14EX II, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)
-Remote Controller / Switch : Remote control with N3 type contact, Wireless Controller LC-5 and Speedlite 600EX-II-RT
-Viewfinder : Eyecup Eg, Eg-series Dioptric Adjustment Lens with Rubber Frame Eg, Anti Fog Eyepiece Eg, Angle Finder C

LCD MONITOR

-Coverage : Approx. 100%
-Type : 8.10cm (3.2") Clear View LCD II, approx. 1620K dots
-Viewing Angle (horizontally/vertically) : Approx. 170° vertically and horizontally
-Coating : Anti-reflection and Anti-smudge. Reinforced glass incorporated
-Brightness Adjustment : Manual: Adjustable to one of seven levels, Color Tone Adjument: 4 settings
-Touch-screen operations :  Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in Live View and Movies, touch shutter is possible in Live View still photo shooting.
-Display Options : (1) Quick Control Screen (2) Camera settings (3) Dual Axis Electronic Level (4) Custom Quick Control Screen

LIVE VIEW MODE

-Type : Electronic viewfinder with image senso
-Coverage : Approx. 100% (horizontally and vertically)
-Frame Rate : 29.97 fps (may increase when AF is performed
-Focusing : Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF (Face Detection and Tracking AF, FlexiZone - Single, FlexiZone - Multi), available with all EF lenses and Touch shutter
-Metering : Real-time evaluative metering with image sensor (315-zone),Partial metering (approx. 6.3% of Live View screen), Spot metering (approx. 2.7% of Live View screen), Center-weighted average metering, Active metering timer can be change
-Display Options : 4 levels available through INFO. button: No information, Basic shooting information, Advanced shooting information and Advanced shooting information with Histogram Multiple Exposure status also available in Multiple Exposure mode

Canon Eos 5d Mark Iv DSLR Cameras

FLASH

-Modes : E-TTL II Auto Flash, Metered Manual
-X-sync : 1/200sec
-Flash Exposure Compensation : +/- 3EV in 1/3 increments with EX series Speedlites
-Flash Exposure Bracketing : Yes, with compatible External Flash
-Flash Exposure Lock : Yes
-Second Curtain Synchronisation : Yes
-HotShoe / PC terminal : Yes / Yes
-External Flash Compatibility : E-TTL II with EX series Speedlites, wireless multi-flash support
-External Flash Control : via camera menu screen

FILE TYPE - STILLS

-Still Image Type : JPEG: 3 compression options
-RAW: RAW, M-RAW, S-RAW and Dual Pixel RAW (14bit, Canon original RAW 2nd edition)
-Complies with Exif 2.30 and Design rule for Camera File system 2.0
-Complies with Digital Print Order Format [DPOF] Version 1.1
-RAW+JPEG simultaneous recording : Yes, any combination of RAW + JPEG possible, separate formats to separate cards possible including Dual Pixel RAW +JPEG
-Image Size : JPEG: 3:2 ratio (L) 6720x4480, (M1) 4464x2976, (S1) 3360x2240 , (S2) 1696x1280 , (S3) 640x480
4:3 ratio (L) 5952x4480, (M1) 3968x2976, (S1) 2976x2240 , (S2) 1920x1280 , (S3) 720x480
16:9 ratio (L) 6720x3776, (M1) 4464x2512, (S1) 3360x1888 , (S2) 1920x1080 , (S3) 720x408
1:1 ratio (L) 4480x4480, (M1) 2976x2976, (S1) 2240x2240 , (S2) 1280x1280 , (S3) 480x480
RAW: (RAW) 6720x4480, (M-RAW) 5040x3360, (S-RAW) 3360x2240
-Folders : New folders can be manually created and selected
-File Numbering : (1) Consecutive numbering (2) Auto reset (3) Manual reset

BUILT-IN GPS

-Digital Compass : Not provided
-Mode 2: GPS is switched off when power is switched off
-Log Files Format : NMEA Format. One log file per day based
-Geotag Information : Longitude, Latitude, Elevation, Coordinated Universal Time
-Positioning Modes : Mode 1: Camera continues to receive GPS signals at regular intervals when power is switched off
-Position Accuracy : Within approx. 30 m/98.4 ft (Based on good GPS satellite reception conditions on a clear day with no surrounding obstructions)
-Compatible Satellite Navigation Systems : GPS satellites (USA), GLONASS satellites (Russia), Quasi-Zenith Satellite Michibiki (Japan)
-Log File Usage : Transfer log data to memory card and copy it to a computer, Use Map Utility to append the log file to the images

VIEWFINDER

- Type : Pentaprism
-Eyepiece shutter : On strap
-Magnification : Approx. 0.71x3
-Mirror : Quick-return half mirror
-Dioptre Correction : -3 to +1 m-1 (dioptre)
-Coverage (Vertical/Horizontal) : Approx. 100%
-Composition information: Grid, Electronic level
-Eyepoint : Approx. 21mm (from eyepiece lens centre)
-Focusing Screen : Fixed, with information Transparent LCD overlay
-Depth of field preview : Yes, with Depth of Field preview button
-Other information: Battery check, Warning symbol, Flicker Detection, drive mode, white balance
-Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light
-Image information: Card information, maximum burst (2 digit display), Highlight tone priority (D+), JPEG/RAW indicator, Dual Pixel RAW, Digital Lens Optimizer.
-Viewfinder Information : AF information: Single/Spot AF points, AF Frame, AF status, Focus indicator, AF mode, AF point selection, AF point registration
-Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, flash metering, spot metering circle, exposure warning, AEB, metering mode, shooting mode

EXPOSURE CONTROL

-Metering Brightness Range : EV 0 - 20 (at 23°C, ISO100, with evaluative metering)
-Anti-flicker shooting : Yes. Flicker detected at a frequency of 100 Hz or 120 Hz. Maximum continuous shooting speed may decrease
-ISO Sensitivity : Auto 100-32000 (in 1/3-stop or whole stop increments), ISO can be expanded to L:50, H1: 51200, H2: 102400,2
-AE Lock : Auto: In the One-Shot AF mode with evaluative metering, AE lock takes effect when focus is achieved
Manual: By AE lock button in P, Av, Tv and M modes
-Exposure Compensation : +/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).
-AEB : +/-3 EV in 1/3 or 1/2 stop increments
-Metering modes : Approx. 150,000-pixel RGB+IR metering sensor, 252-zone metering. EOS Intelligent Subject Analysis system
(1) Evaluative metering (linked to All AF point)
(2) Partial metering (approx. 6.1% of viewfinder at centre)
(3) Spot metering: Center spot metering (approx. 1.3% viewfinder at centre)
AF point-linked spot metering not provided
(4) Centre weighted average metering

FOCUSING

-Manual Focus : Selected on lens
-Adjust all lenses by same amount
-Adjust up to 40 lenses individually
-Manual selection: Single point Spot AF
-AF working range : EV -3 - 18 (at 23°C & ISO100)
-Manual selection: AF point Expansion surrounding 8 points
-Manual selection: AF point Expansion 4 points (up, down, left, right)
-AF Assist Beam : Emitted by an optional dedicated Speedlite
-Manual selection: Zone AF (all AF points divided into 9 focusing zones)
-AF points can be selected separately for vertical and horizontal shooting
-The number of cross-type AF points will differ depending on the lens.
-Manual selection: Large Zone AF (all AF points divided into 3 focusing zones)
-AF Point Selection : Automatic selection: All 61 point AF (based on EOS iTR AF setting)
-Selected AF point display : Transparent lcd in viewfinder and shown on quick control screen
-Manual selection: Single point AF (selectable points 61, 15, 9 or cross type only points selectable)
-Type : TTL-secondary image-forming phase-difference detection system with dedicated AF senso
-AF Lock : Locked when shutter button is pressed half way or AF ON is pressed in One Shot AF mode. Using customised button set to AF stop in AI servo
-AF System / Points : 61 Point / max of 41 cross-type AF points inc 5 dual cross type at f/2.8 and 61 points / 21 cross-type AF points at f/81
-AF Microadjustment : Manual: Enter adjustment +/- 20 steps (wide and tele setting for zoom lenses)-

SHOOTING

-Multiple exposure
-Lens optical correction4:
-RAW image processing6
-Long exposure noise reduction
-Auto Lighting Optimizer (4 settings)
-Colour Space : sRGB and Adobe RGB
-Image Processing : Highlight Tone Priority
-High ISO speed noise reduction (4 settings)
-Max. 4.3fps in Live View mode with AF Tracking
-45 cropping sizes selectable, from 11% to 95% (diagonal)
-Switch between vertical and horizontal cropping orientation
-Cropping frame can be moved using touch screen operation
-Cropping: JPEG images can be cropped (Aspect ratios 3:2, 4:3, 16:9, 1:1)
-Picture Styles : Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
-Peripheral illumination correction, Chromatic aberration correction (during/after still photo shooting, during Video only)
-Modes : Scene Intelligent Auto, Program AE , Shutter priority AE, Aperture priority AE, Manual (Stills and Movie), Bulb and Custom (x3)
-Distortion correction, Diffraction correction, Digital Lens Optimizer (during/after still photo shooting)
Resize to M, S1, S2 or S35
-Drive modes : Single, Continuous High, Continuous Low, Silent Single, Silent Continuous, Self timer (2s+remote, 10s+remote)
-Continuous Shooting : Max. Approx. 7fps. with full AF / AE tracking, speed maintained for up to unlimited number of JPEGs or 21 RAW images7 8 9
-Interval timer : Built-in, number of shots selectable from 1-99 or unlimited (Selectable interval time - 1sec to 99hr 59mins 59sec). Bulb timer possible (Selectable time - 1sec to 99hr 59mins 59sec)

EOS MOVIE

-Microphone : Built-in monaural microphone (48Khz, 16 bit x 2 ch)
-4K Frame Grab : 8.8 megapixel JPEG still image frame grab from 4K movie possible
-Focusing : Dual Pixel CMOS AF with Face Detection and Tracking AF, Movie Servo AF Manual Focus
-Colour Sampling (Internal recording) : 4K - YCbCr4:2:2 (8 bit), Full HD/ HD - YCbCr4:2:0 (8 bit)
-High Frame Rate Movie : MOV Video: HD - 1280 x 720 at 100fps or 119.9fps, Recorded as 1/4-speed slow motion movie
-Movie Length : 4K and Full HD - Max duration 29min 59sec. (excluding High Frame Rate movies). No 4GB file limit with exFAT CF card Single scene maximum recording up to 7min 29sec.
-HDMI Display : External monitor only, External Monitor only without information display or Simultaneous on camera and external monitor
-HDMI Output : Full HD recording only, uncompressed YCbCr 4:2:2, 8-bit, sound output via HDMI is also possible
-ISO : 4K - Auto: 100-12800, H: 25600, H: 32000, H1: 51200, H2: 102400,, Full HD / HD - Auto: 100-25600, H: 32000, H1: 51200, H2:102400
-Movie Size : 4K (17:9) 4096 x 2160 (29.97, 25, 24, 23.98 fps) Motion JPEGFull HD (16:9) 1920 x 1080 (59.94, 50, 29.97, 25, 23.98 fps) intra or inter frame,Full HD (16:9) 1920 x 1080 HDR ( 29.97, 25 fps) inter frame,Full HD (16:9) 1920 x 1080 (29.97, 25) lite inter frame,HD (16:9) 1280 x 720 (119.9, 100 fps) intra frame
-Movie Type : MOV Video: 4K (17:9) 4096 x 2160 - Motion JPEG (internal recording only)10, Full HD, HD - MPEG4
-AVC / H.264 variable (average) bit rate, Audio: Linear PCM -MP4 Video: Full HD (16:9) 1920 x 1080 - MPEG4 AVC/H.264, Audio: AAC
-Bitrate / Mbps : MOV: 4K (29.97p/25.00p/24.00p/23.98p): Approx. 500 Mbps Full HD (59.94p/50.00p)/ALL-I: Approx. 180 Mbps,Full HD (59.94p/50.00p)/IPB Approx. 60 Mbps,Full HD (29.97p/25.00p/24.00p/23.98p)/ALL-I: Approx. 90 Mbps,Full HD (29.97p/25.00p/24.00p/23.98p)/IPB (Standard): Approx. 30 Mbps,HD (119.9p/100.0p)/ALL-I: Approx. 160 Mbps,MP4: Full HD (59.94p/50.00p)/IPB (Standard): Approx. 60 Mbps,Full HD (29.97p/25.00p/24.00p/23.98p)/IPB (Standard): Approx. 30 Mbps,Full HD (29.97p/25.00p)/IPB (Light): Approx. 12 Mbps

OTHER FEATURES

-Highlight Alert : Yes
-Water / Dust resistance : Yes
-Intelligent Orientation Sensor : Yes
-LCD Panel / Illumination : Yes / Yes
-Display Formats : (1) Single image
-Histogram : Brightness: Yes, RGB: Yes
-Image Erase : Single image, Selected images, Folder, Card
-Custom Functions : 17 Custom Functions with 46 settings
-Image Erase Protection : Erase protection of Single image, Folder or Card
-Playback zoom : 1.5x - 10x in 15 steps (2) Single image with information (2 levels )
-Firmware Update : Update possible by the user (Camera, Lens, WFT, External Speedlite)
-Slide Show :  Image selection: All images, by Date, by Folder, Movies, Stills, Protected images or Rating
Playback time: 1/2/3/5/10 or 20 seconds, Repeat: On/Off
-Menu Languages : 25 Languages, English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese
-Metadata Tag : User copyright information (can be set in camera) Image rating (0-5 stars) IPTC data (registered with EOS Utility) Image transfer with caption (Caption registered with EOS Utility)
-Voice Memo : Yes via Chargable update - Up to 30sec per image - 48Khz/16 Bit or 8Khz/8 Bit Basic - Shooting information (shutter speed, aperture, ISO and Image quality)
Detailed - Shooting information (shutter speed, aperture, ISO, metering Image, quality and file size), Lens information , Brightness and RGB histogram, White balance, Picture Style, Color space and noise reduction, Lens optical correction, GPS information(3) 4 image index (4) 9 image index (5) 36 image index (6) 100 image index (7) Jump Display (1, 10 or 100 images, Date, Folder, Movies, Stills, Protected images, Rating) (8) Movie edit (9) RAW processing (10) Rating
