Piazzetta P220 M Pellet Stove
P220 M PELLET STOVE
P220 C PELLET STOVE
Pellet Stove P220 M, with Majolica cladding, for Flush-with-the-wall/Corner installation, Energy class A+. It is fitted with the Multifuoco® System.
The Pellet Stove P220 M, for Flush-with-the-wall/Corner installation and cladded in Majolica, with its 8,5 KW and Energy class A+, is a refined appliance from the Premium Plus Line by Piazzetta. Discover all the features in the Multifuoco® System ducting system, the Apps, Distance Management and lots more
FEATURES
THE EFFICIENCY OF PELLETS
Performance and savings, the optimum solution for bringing warmth to the home.
MY PIAZZETTA APP
The My Piazzetta app can be used to monitor pellet- and wood-based operation and programme the switching on and off sequences remotely, using the standard Wi-Fi device. The My Piazzetta app can be comfortably used also from home, via Bluetooth.
OPTIMAL COMBUSTION
The Pellet Quality System allows for always optimising the fuel performance. Depending on the pellet characteristics, the remote control can be used to comfortably adjust the stove’s operation and improve combustion of the flame. In addition, thanks to the Air Quality System, the fine calibration of the combustion air intake allows for improving the stove’s performance.
ELECTRONIC CONTROL
Thanks to the fully electronic control, the stove’s operation can be monitored and optimised. The electronic devices mounted on the stove ensure easier management. For example, a sensor positioned in the pellet tank triggers a buzzer and a message on the remote control, signalling the need to top up the fuel.
INFORMATION
ENERGY EFFICIENCY CLASS
A+
RATED OUTPUT
3.3 - 8.5 kW
EFFICIENCY
89 - 90.3 %
HEATABLE VOLUME
145 - 245 m³
PRODUCTION
Made by Italy
TANK CAPACITY
18 kg
FLUE OUTLET
8 cm
WEIGHT
150 kg
PRODUCT MEASURES
53 x 54.4 x 116.7
DOWNLOADS P220 M SCARICO SUPERIORE
↓ Product sheets
↓ Technical drawings
↓ Energy class label
MAIN FEATURES
-Reburn -Hermetic -Automatic cleaning -Fuel level sensor -Left rear flue -Maiolica radiante - Premium Plus -Majolica -Programming -Pellet quality system -Rolling top -APP WI-FI bluetooth -Wall attached -Multifuoco System -Natural mode -Top flue outlet
OPTIONAL
- Remote control
- Coaxial
TECHNICAL DRAWING
- A : 8 cm
- B : 7.5 cm
- C : 6 cm
COLORS
MODEL
P220 M
PELLET CONSUMPTION
0.7 - 1.9 kg/h
P220 M SCARICO SUPERIORE
-Energy efficiency class : A+ -Rated output : 3,4 - 8,5 kW -Efficiency : 89,8 - 91,3 % -Heatable volume : 145 - 245 m³ -Pellet consumption :
0,7 - 1,9 kg/h -Tank capacity : 14 kg -Ø Flue outlet : 8 cm
DOWNLOADS P220 M SCARICO POSTERIORE
↓ Product sheets
↓ Technical drawings
↓ Energy class label
GENERAL FEATURES
-Heating: Multifuoco System® with 3 power levels and manual or automatic control. Hot ductable air -Natural Mode: yes -Power levels: 4 -Radiant Majolica: yes -Cladding / Top: majolica / majolica and steel -Front ventilation: adjustable vent -Humidifier: stainless steel -Remote control with LCD display: -Multicomfort: standard -Multicomfort Plus: standard -Ambient probe for temperature control: as standard feature -Module WiFi -Bluetooth for MyPiazzetta App: standard -Wireless probe for temperature management: optional -Timer-controlled thermostat with programming: 6 daily time frames -Eco / Energy Saving function: yes / yes -Glass cleaning: continuous air flow
-Cyclic brazier cleaning: yes -Ash vacuum cleaner: as standard feature -Installation: wall-flush with the corner
-Standard flue outlet position: rear / RH top -Optional flue outlet: top balanced flue -One-piece firebox: airtight in steel -Firebox: steel - cast iron -Door / Handle: cast iron with ceramic glass resistant to 750°C / coated steel that can be opened with detachable handle -Air Combustion System Function: yes -Pellet Quality System Function: yes -Ash conveyor: steel -Side ventilation: optional vent, fixed -Combustion air kit:
