Piazzetta P220 M Pellet Stove

P220 M PELLET STOVE

P220 C PELLET STOVE

Pellet Stove P220 M, with Majolica cladding, for Flush-with-the-wall/Corner installation, Energy class A+. It is fitted with the Multifuoco® System.

Piazzetta P220 M Pellet Stove

The Pellet Stove P220 M, for Flush-with-the-wall/Corner installation and cladded in Majolica, with its 8,5 KW and Energy class A+, is a refined appliance from the Premium Plus Line by Piazzetta. Discover all the features in the Multifuoco® System ducting system, the Apps, Distance Management and lots more

FEATURES

Piazzetta P220 M Pellet Stove

THE EFFICIENCY OF PELLETS

Performance and savings, the optimum solution for bringing warmth to the home.

Piazzetta P220 M Pellet Stove

MY PIAZZETTA APP

The My Piazzetta app can be used to monitor pellet- and wood-based operation and programme the switching on and off sequences remotely, using the standard Wi-Fi device. The My Piazzetta app can be comfortably used also from home, via Bluetooth.

Piazzetta P220 M Pellet Stove

OPTIMAL COMBUSTION

The Pellet Quality System allows for always optimising the fuel performance. Depending on the pellet characteristics, the remote control can be used to comfortably adjust the stove’s operation and improve combustion of the flame. In addition, thanks to the Air Quality System, the fine calibration of the combustion air intake allows for improving the stove’s performance.

Piazzetta P220 M Pellet Stove

ELECTRONIC CONTROL

Thanks to the fully electronic control, the stove’s operation can be monitored and optimised. The electronic devices mounted on the stove ensure easier management. For example, a sensor positioned in the pellet tank triggers a buzzer and a message on the remote control, signalling the need to top up the fuel.

INFORMATION

ENERGY EFFICIENCY CLASS

A+

RATED OUTPUT

3.3 - 8.5 kW

EFFICIENCY

89 - 90.3 %

HEATABLE VOLUME

145 - 245 m³

PRODUCTION

Made by Italy

TANK CAPACITY

18 kg

FLUE OUTLET

8 cm

WEIGHT

150 kg

PRODUCT MEASURES

53 x 54.4 x 116.7

MAIN FEATURES

-Reburn -Hermetic -Automatic cleaning -Fuel level sensor -Left rear flue -Maiolica radiante - Premium Plus -Majolica -Programming -Pellet quality system -Rolling top -APP WI-FI bluetooth -Wall attached -Multifuoco System -Natural mode -Top flue outlet

OPTIONAL

- Remote control
- Coaxial

TECHNICAL DRAWING

- A : 8 cm
- B : 7.5 cm
- C : 6 cm

Piazzetta P220 M Pellet Stove

COLORS

Piazzetta P220 M Pellet Stove
Rasso Lava
Piazzetta P220 M Pellet Stove
Bianco
Piazzetta P220 M Pellet Stove
Terra Cotta
Piazzetta P220 M Pellet Stove
Nero Oapco
Piazzetta P220 M Pellet Stove
Marrone Tenne
Piazzetta P220 M Pellet Stove
Bianco Cacle

MODEL

P220 M

PELLET CONSUMPTION

0.7 - 1.9 kg/h

P220 M SCARICO SUPERIORE

-Energy efficiency class : A+ -Rated output : 3,4 - 8,5 kW -Efficiency : 89,8 - 91,3 % -Heatable volume : 145 - 245 m³ -Pellet consumption :
0,7 - 1,9 kg/h -Tank capacity : 14 kg Flue outlet : 8 cm

GENERAL FEATURES

-Heating: Multifuoco System® with 3 power levels and manual or automatic control. Hot ductable air -Natural Mode: yes -Power levels: 4 -Radiant Majolica: yes -Cladding / Top: majolica / majolica and steel -Front ventilation: adjustable vent -Humidifier: stainless steel -Remote control with LCD display: -Multicomfort: standard -Multicomfort Plus: standard -Ambient probe for temperature control: as standard feature -Module WiFi -Bluetooth for MyPiazzetta App: standard -Wireless probe for temperature management: optional -Timer-controlled thermostat with programming: 6 daily time frames -Eco / Energy Saving function: yes / yes -Glass cleaning: continuous air flow
-Cyclic brazier cleaning: yes -Ash vacuum cleaner: as standard feature -Installation: wall-flush with the corner
-Standard flue outlet position: rear / RH top -Optional flue outlet: top balanced flue -One-piece firebox: airtight in steel -Firebox: steel - cast iron -Door / Handle: cast iron with ceramic glass resistant to 750°C / coated steel that can be opened with detachable handle -Air Combustion System Function: yes -Pellet Quality System Function: yes -Ash conveyor: steel -Side ventilation: optional vent, fixed -Combustion air kit:
