Kettal Superfan Ceiling With Downrod Fan

SUPERFAN CEILING WITH DOWNROD FAN

SUPERFAN CEILING WITH DOWNROD FAN

Designed by Michael Anastassiades

Superfan is a tri-blade fan whose geometry is simply defined through three angled blades, meeting at the rotating axis.

Kettal Superfan Ceiling With Downrod Fan

All design decisions are made to maximise performance and improve efficiency: the angle of the blades, the lightness of the aluminium material and the selection of the motor for accurate speed control and quiet function.

The two fan versions operate with equal efficiency both with and without a pendant, offering flexibility of use for different ceiling heights.

Kettal Superfan Ceiling With Downrod Fan

INFORMATION

MATERIAL

Aluminium : Antioxy, Heavy Load, Resistant En-1421, Kettalize-It, Anti- Scratch, Easy Clean, Flame Retardant M1, Eco Friendly Ecoembes Recycling Process

BRAND

Kettal

PRODUCT TYPE

Fan

DESIGNER

Michael Anastassiades

REFERENCE CODE

KSA900200

COLLECTION

Superfan

FIXATION

Ceiling

NO. OF SPEEDS

6-speed selection

IP

44

ENGINE TYPE

Super silence motor BLDC (brushless direct current)

DIMENSIONS

- Height : 62,3 cm
- Width : 140 cm
- Ceiling Base : 15 cm

Kettal Superfan Ceiling With Downrod Fan

VOLTAGE

220-240, 2A

BODY/STRUCTURE

Aluminium

HERTZ

50/50 Hz

NO. OF BLADES

3

WEIGHT

7,5 kg (16,5 lbs). It must be installed on a structure capable of supporting 30kg (66lbs)

Kettal Superfan Ceiling With Downrod Fan

FAN LOCATION

Allow a minimum clearance of 2,1 m (7 ft) for USA and 2,3 m (7,5 ft) for Europe from the floor to the blades and 30 inches (76 cm) from the wall to the end of the blades.

DATA

Includes remote control The instalation requires a 220-240 2A 50/50Hz supply connection. The client must

TYPE OF CONTROL INCLUDED

Remote control / Fan reverse function control

MAX. POWER CONSUMTION

Less than 35W

VERSIONS

- A92FN0AW00
- A92FN00000

Kettal Superfan Ceiling With Downrod Fan
A92FN0AW00
Kettal Superfan Ceiling With Downrod Fan
A92FN00000

MAINTENANCE

- Clean with mild soap using sponge or cloth. Be gentle while cleaning, do not scrub aggressively the fabric. Once cleaned please make sure you remove soap excess. In case of aggressive stains clean with diluted household bleach
- Clean stains promptly. The longer it remains, more difficult will be to remove.
- Once cleaned the fabric steam iron the fabric. Just use steam, be carefull NOT placeing the iron directly in the fabric it will get damage.

Kettal Superfan Ceiling With Downrod Fan

DESIGNER - MICHAEL ANASTASSIADES

Michael Anastassiades is a Cypriot-born, London-based designer whose practice encompasses product, spatial interventions and experimental works, often transcending the distinctions between different fields of creativity. "Ringer is a robust collection which is still easy to move and rearrange".

COLORS

FRAME COLOUR OPTIONS

Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
Kettal Superfan Ceiling With Downrod Fan
