Jabra PanaCast 20 Camera

PANACAST 20 CAMERA

Jabra PanaCast 20 Camera

PANACAST 20 CAMERA

Engineered for intelligent AI-enabled personal video conferencing

FEATURES

WORKS WITH ALL LEADING UC PLATFORMS

PanaCast 20 is certified for Microsoft Teams, Zoom certified and works with all leading UC platforms.

Jabra PanaCast 20 Camera

INTEGRATED PRIVACY COVER

Slide over to stay hidden and slide it back when you’re ready for your close-up.

Jabra PanaCast 20 Camera

INTEGRATED VIDEO SOLUTION

Designed to be an all-in-one video solution, so you don’t need to buy any extra accessories like lighting rings when it’s your time to shine on screen. Simply pair with your choice of Jabra audio device for a professional experience every time.

Jabra PanaCast 20 Camera

INFORMATION

FIELD OF VIEW

- Horizontal : 90°
- Vertical : 75°
- Diagonal : 117°

PRODUCT TYPE

Camera

PRODUCTION

Made in Denmark

NUMBER OF CAMERAS

1

CAMERA RESOLUTION

13 megapixels

ZOOM

Up to 3x lossless digital zoom at 720p

IMAGE SENSOR

1/3.2"

FOCAL LENGTH

2.26 mm

OPERATING TEMPERATURE

- 5°C to 35°C
- 41°F to 95°F

Jabra PanaCast 20 Camera

STORAGE TEMPERATURE

- 20°C to 60°C
- 4°F to 140°F

MAIN UNIT DIMENSIONS

- Width : 44 mm (1.73 in )
- Height : 25 mm (1 in)
- Depth : 80 mm (3.14 in)

PACKAGING DIMENSIONS

- Width : 160 mm (6.3 in )
- Height : 50 mm (2 in)
- Depth : 130 mm (5.2 in)

MICROPHONE TYPE

Mems

NUMBER OF MICROPHONES

3

CERTIFICATIONS AND COMPLIANCE

-Zoom -Microsoft Teams -Works with all leading UC platforms

WEIGHT

136g | 4.9oz

WARRANTY

2 years

BOX CONTENTS

-PanaCast 20 -Carry Case -USB-C to USB-A cable 1.5m/4.9ft (USB 3.0)

MICROPHONE SENSITIVITY

-37dBFS

FREQUENCY RANGE

100Hz - 8000Hz

CONNECTIVITY

-USB-C
-Uvc Versions : 1.1
-Supported USB versions : USB 3.0, USB 2.0 (supplying more than 500mA of current)

Jabra PanaCast 20 Camera

VIDEO CONFERENCING

-Premium video quality : 4K Ultra-HD video
-Picture perfect : AI-enabled image enhancement
-Flexible : Portable, lightweight design

RESOLUTION

-4k Ultra-HD : 3840 x 2160 @ 30 fps
-720p HD : 1280 x 720 @ 30 fps
-1080p Full HD : 1920 x 1080 @ 30 fps

APERTURE

2.25

INTELLIGENT ZOOM

Yes

PICTURE IN PICTURE

Yes

VIVID HDR

Yes

MANUAL PAN-TILT-ZOOM

Yes

SOFTWARE DEVELOPMENT KIT

Yes

COMPATIBLE SOFTWARE AND/OR APPS

- Jabra Direct
- Jabra Xpress

SYSTEM REQUIREMENTS

- Compatible with Windows 11
- Windows 10
- MacOS 10.15 and later
- Including macOS 11.x
- Windows 8.1 (64-bit and 32bit)

CERTIFIED

Uc-optimised it’s all uc, you see

PanaCast 20 is certified for Microsoft Teams, Zoom, Google Meet and Works With Chromebook1 and works with all leading UC platforms for a seamless experience. So you’re free to focus on your meetings – not your tech.

Jabra PanaCast 20 Camera
Jabra PanaCast 20 Camera
Jabra PanaCast 20 Camera
Jabra PanaCast 20 Camera
Jabra PanaCast 20 Camera

DETAIL

Jabra PanaCast 20 Camera

PLUG-AND-PLAY

You’re used to hitting the ground running, so why settle for tech that holds you back? PanaCast 20 is plug-and-play, for instant connection from the very first time you use it. Simply connect the USB-C cable to your computer and you’re ready to collaborate from anywhere. Get right to it with PanaCast 20.And, action.

Jabra PanaCast 20 Camera

ADVANCED EDGE AI CHIP

Collaborate in confidence

PanaCast 20 is engineered for data security. An advanced on-board Edge AI chipset drives all of the intelligent features, as well as processing your video on the device itself to reduce the risk of data breaches. So you can get on with whatever you’re doing, without worrying. Secure personal video conferencing that gives you the Edge.

Jabra PanaCast 20 Camera

INTELLIGENT LIGHTING OPTIMIZATION

Any light is good light

Today’s professionals need to take video calls from everywhere. With PanaCast 20, AI-based Intelligent Lighting Optimization analyses your environment and automatically adjusts your image in real-time to enhance the video quality. Your next meeting calls for next-generation technology.

Jabra PanaCast 20 Camera

PAIR WITH JABRA AUDIO

Superheroes need sidekicks.

OK, so you’ve got the video part all figured out, but what about the sound? From the world-leading Evolve Series, to the crystal-clear audio of the Speak Series – here at Jabra we've got the perfect audio partner for your PanaCast 20, however you like to work. Because intelligent video and world-leading audio is a powerful combination.

Jabra PanaCast 20 Camera

PICTURE-IN-PICTURE

Two streams are better than one

Get ready for more engaging presentations with PanaCast 20. Our unique Picture-in-Picture mode enables you to share a close-up as your main image while continuing to present in a smaller window, thanks to on-board Edge processing that combines two real-time video streams into one. What's more Picture-in-Picture mode works with any UC platform, even if they don't support dual-stream devices. Because showing is so much more powerful than telling.

4K ULTRA-HD PICTURE QUALITY

Picture perfect. Wherever you work.

Video calls are now part of everyday life, but poor picture quality impacts the whole experience.

Jabra PanaCast 20 Camera

PanaCast 20 uses advanced processors, powerful on-board AI and a 13-megapixel camera to deliver an impressive real-time 4K Ultra-HD image that’s crystal-clear, with virtually no latency. So you can deliver that big presentation knowing you’ll look your best. Give your personal video conferencing a complete makeover.

INTELLIGENT ZOOM

Are you ready for your close-up?

When you’re on an important video call, being seen clearly makes all the difference. Our Intelligent Zoom feature uses powerful AI to continuously scan and adjust your picture in real-time, ensuring you’re always in the centre of the frame.

Jabra PanaCast 20 Camera

Now you can experience more immersive, natural video collaboration without having to stay rooted to the spot. PanaCast 20 delivers a meeting experience that’s not just better, it’s completely reinvented. With Intelligent Zoom, you’re always centre-stage.

ON-DEVICE BACKGROUND EFFECTS

Out of sight. Peace of mind.

X-rays. Financial records. Trade agreements. Even the secret bunker VIP list. Whatever sensitive information you want to keep hidden during video calls, On-device Background Effects have - quite literally- got you covered.

Jabra PanaCast 20 Camera

They blur your background or replace it with a solid colour, using the powerful Edge AI on PanaCast 20 to process image alterations directly on the device, unlike similar features on UC platforms. This reduces the risk of cyber attack when you’re hybrid working since the real background data isn’t seen, sent or stored on the cloud. Ensuring any data you need to conceal stays strictly “for your eyes only”. How very 007. Make video calls less I-spy and more stealth mode.

INTEGRATED PRIVACY COVER

Share what’s good. Hide what’s not.

You can’t be camera-ready all the time. That’s why PanaCast 20 comes with an integrated privacy cover, to give you total control.

Jabra PanaCast 20 Camera

Simply slide the privacy cover across your camera lens when you need privacy and slide it back again when you’re ready to turn your video on. Because video calls are great. But sometimes you just need a minute.

PREMIUM PORTABLE COLLABORATION

Here. There. Anywhere.

When you work flexibly, you can be joining meetings from anywhere. This clever little camera is perfectly portable, with a compact design that easily slots over the top of any screen, an integrated, foldable mounting clip and a protective carry case.

Jabra PanaCast 20 Camera

So you’re only ever seconds away from seamless, intelligent, high-quality video collaboration. From the café to the kitchen table. Enjoy great video meetings anywhere.

NEXT-GENERATION VIDEO COLLABORATION

Personal video conferencing, but not as you know it

As we all navigate the realities of trying to stay connected and productive, video conferencing is more important than ever. It’s time to experience the next generation of intelligent, secure, portable video collaboration with Jabra PanaCast 20.

Harnessing advanced on-board AI to deliver an intelligent feature set that takes your video experience to the next level, PanaCast 20 is a personal camera that knows exactly what you need, when you need it. Let your camera do the thinking.
