Olimpia Splendid Alyas Pro E Air Conditioner

ALYAS PRO E AIR CONDITIONER

Olimpia Splendid Alyas Pro E Air Conditioner

ALYAS PRO E AIR CONDITIONER

The high wall mono-split air conditioner with a superior heating performance (compared to standard splitters) in the coldest climate areas. The external operating temperature limit is -22°C. Alyas Pro E also has a multi-filter system consisting of an anti-dust electrostatic filter and active carbon filter (to combat unpleasant odours).

FEATURES

HIGH EFFICIENCY

High-performance R32 refrigerant gas with maximum technological efficiency, up to energy class A+++.

Olimpia Splendid Alyas Pro E Air Conditioner

LOW-ENVIRONMENTAL IMPACT GAS

It uses R32 refrigerant, which has a greenhouse effect reduced by almost 70% (compared to R410A).

Olimpia Splendid Alyas Pro E Air Conditioner

HIGH PERFORMANCE IN COLD CLIMATES

In the heating of the more rigid climatic zones, it has a higher performance than the common split units (operating limit of the external ambient temperature -22°C).

Olimpia Splendid Alyas Pro E Air Conditioner

PURE SYSTEM

Equipped with a multi-filtering system, consisting of an electrostatic filter (with anti-dust function) and activated carbon filter (effective against unpleasant odours).

Olimpia Splendid Alyas Pro E Air Conditioner

INFORMATION

BRAND

Olimpia Splendid

PRODUCT TYPE

Air Conditioner

MOUNTING

Mounted on Wall

FILTER

Electrostatic filter and active carbon filter

REFRIGERANT GAS

R32

COLLECTION

Alyas

PRODUCTION

Made in Italy

TWO MODELS AVAILABLE

Alyas Pro E Inverter 9 and 12

EXTERNAL AMBIENT TEMPERATURE

-22°C

FEATURES

- Cooling
- Heating
- Dehumidification and ventilation

USE

Indoor

SYSTEM

Multi-filtering System

HEAT PUMP APPLIANCES

- During operation in heating mode, condensate is produced in the outdoor unit due to defrosting, which must be able to run-off freely to prevent stagnation. - When positioned on a flat surface, a draining channel must be created around the unit that goes directly into the rainwater collection well of the water network (figure 15).- In the case of installation on a balcony or terrace, it must be possible to position a recipient under the unit, possibly in galvanised sheet or stainless steel (preferable), with drain pipe that flows directly into the gutter.

Olimpia Splendid Alyas Pro E Air Conditioner

-Another option (figure 16) is to position the gasket (6) on the fitting (5) and then insert the latter into the hole made on the bottom of the outdoor unit and turn it by 90° to fix it securely. - Connect a rubber hose (not supplied) to the fitting (6) if water is drained from the outdoor unit in heating mode.

PERFORMANCE

Golden Fin treatment on the battery of the outdoor unit, to prevent the corrosive action of atmospheric agents and improve performance efficiency.

COP

4.41 - 3.7

EER

4.4 - 3.6

DISPLAY

Display LED

TIMER

24 H

OUTPUT POWER

- Cooling mode rating : 2.64 kW - 3.52 kW
- Heating mode rating : 2.86 kW - 3.81 kW

FUNCTIONS

-Timer, Auto, Eco, Sleep, Silent, Turbo, Auto-restart and Auto-diagnosis functions -Swing function : oscillation of the flap for better air diffusion in the environment. -Auto-Restart function : After a power failure, it restarts at the last function set. -Auto-Diagnosis function : In the event of a failure, the display shows the error c ode. -Follow Me function : The remote control thermostat allows correct temperature control where the occupants are present in the room.
