Built-in Hood Firstline

Firstline provides the most cost-effective point of entry to the world of berbel built-in hoods. Its space-efficient installation makes this berbel extractor hood a really smart partner. Thanks to the easy assembly, the Firstline built-in hood is particularly suitable for subsequent installation in existing kitchens. The dazzle-free hob illumination creates optimum lighting conditions.

Thanks to the intelligent combination of an extendible vapour screen and dual vapour capture function, this flat fan is a really strong performer. A smart solution for anyone who wants to hit the jackpot with an efficient and quiet extractor hood.

INFORMATION

BRAND

Berbel

PEODUCT TYPE

Strong Partner

AVAILABLE WIDTHS

60, 80, 90 cm

ANNUAL CONSUMPTION IN KWH

20, 23 kwh

FLUID DYNAMIC EFFICIENCY CLASS

A

ENERGY EFFICIENCY CLASS

A

LIGHTING EFFICIENCY CLASS"

A

SOUND LEVEL STAGE 3 (DB(A) RE 1 PW)

64

PERFORMANCE STAGES

3 + power stage (P)

FREE-BLOWING FAN PERFORMANCE, M3/H

650 m3/h

FAT SEPARATION CLASS

B

ACOUSTIC PRESSURE STAGE 3 DB(A) RE 20 ΜPA

52, 53

POWER CONSUMPTION, W

85

AFTERRUN FUNCTION FOR RECIRCULATION MODE

Manual, stage 2

REC. DISTANCE FROM HOB

55 (gas hob > 65)

LED COLOUR TEMPERATURE, K

3.500

RECIRCULATION FILTER SATURATION INDICATOR

Yes

A COMPACT KITCHEN PARTNER

The dual vapour intake in conjunction with an extendible vapour screen guarantees top efficiency when it comes to air cleaning. Dazzle-free LEDs for perfect hob illumination impress the chef during cooking and magic up a pleasant ambience in the kitchen. Thanks to its compact design, enough space remains in the top cupboard for a spice rack, for example.

LED, W

6.0 , 6.2

LED HOB ILLUMINATION, LUX

348, 185 , 193

NET WEIGHT

55 ,60 , 65 , 90 kg

STANDARD FEATURES

- Efficient and lastingly high rate of fat separation with the powerful berbel principle in combination with the effective CapillarTrap.
- Powerful and quiet extractor offers perfect capture of cooking vapours through innovative BackFlow technology
- Extra energy-efficient and low-noise EC fan motor -Extensible vapour screen -Removable collection tray and perfectly constructed interior for easy and fast cleaning -Timeless and robust control touch panel -Dazzle-free, warm-white LED hob lighting -Afterrun function for long recirculation filter life -3 fan stages plus one power stage (P)

VAPOUR EXTRACTION WITH FACETS

The Firstline built-in hood is an elegant, classic flat fan. Distinctive stainless steel with perfect workmanship and the silver-coloured control touch panel are the first things to catch the eye of the onlooker.

The extendible vapour intake forms a clear line with the fronts of the top cabinets and emphasises modern kitchen design.

Berbel A Strong Partner
Silver
Berbel A Strong Partner
Light

PLANNING INFORMATION

- Installation for cabinets with a side panel depth of 290 mm
- Power supply of 230 V (power socket) must be planned
- Recommended worktop depth: max. 600 mm -For use BUF 125, the required installation height is 540 mm, for exhaust air at least 345 mm -Not suitable for use of external or intermediate fan (BackFlow technology without function)  -For mounting in 80 or 90 cm wall units, please order assembly aid -With an installation depth of 195 mm the fan box can be installed behind the spice rack -With recirculation, plan at least 100 mm space between wall unit and ceiling

Berbel A Strong Partner

-Pipe connection Ø 125 mm, ideal for narrow exhaust air paths. For narrow exhaust air paths, e.g. Ø 100 mm, we recommend the berbel hybrid filter as a pressure relief valv -For required installation dimensions, please refer to the product pages and/or the operating and assembly instructions!

MODES

RECIRCULATION

Recirculation mode is the most energy-saving operating mode. The air is cleaned by an odour filter and directed back into the room. The room temperature is not altered. It is also simple to implement, because wall penetrations and exhaust channels are not required. Due to their large volume, are especially efficient at odour-binding and absorb up to 95% of bad smells.

A further advantage of the berbel recirculation filter: only the proactive carbon needs to be changed – not the entire filter – and it only needs to be replaced every two to three years depending on how hard the filter has to work. The berbel refill pack is available for a cost-effective and environmentally friendly replacement.

Berbel A Strong Partner

EXHAUST AIR

Exhaust air directed outside the building is particularly effective when it comes to the removal of odours, fumes and the moisture that results from cooking. It is advisable to use a berbel automatic wall sleeve to minimise heat loss. This seals and insulates the pipe outlet on the facade when the extractor hood is switched off.

The planning of the exhaust air flow path should be optimised, since this positively influences the efficiency and smooth running of the hood. The appropriate duct material for this can be found in the exhaust air accessories section.
