Goalzero 6300Wh Home Backup System

6300Wh Home Backup System

6300WH HOME BACKUP SYSTEM

This all-in-one bundle provides roughly 6,300 Watt Hours of power for your portable home energy needs.

Equipped with a portable Yeti 1500X, Yeti Home Integration Kit transfer switch, four Yeti Tank Expansion Batteries, and the Link Expansion Module.

Goalzero 6300Wh Home Backup System

HIGHLIGHTS

EXPERIENCE UNLIMITED POWER

Charge the Yeti 1500X from the sun with our portable solar panels while away from the grid and keep it topped off from a wall outlet when you’re home. Integrated MPPT charge controller ensures you’re getting the most efficient solar charge possible.

GOODBYE GAS GENERATOR. HELLO YETI X.

With a lithium-ion battery at its core, the Goal Zero Yeti X equips you with safe, clean, portable power for camping, tailgating, off-grid events, workshops, and emergency home backup.

TAKE YOUR WALL OUTLET ANYWHERE

ncreased 2000W AC (3500W Surge) inverter allows you to run power-hungry devices and appliances with confidence. Our new industry-leading inverter can handle surges from power tools, medical devices, and home appliances, including full-size refrigerators.

POWER IN THE PALM OF YOUR HAND

Monitor, control, and optimize your power usage from anywhere with Yeti App 3.0. Features remote control of power in/out, real-time power consumption notifications, historical power tracking, and charging profiles to optimize your battery life.

VERSATILE PORT OPTIONS

Power a wide range of devices with seven different port options including fast-charging 60W USB-C Power Delivery, multiple USB-A ports, regulated 12V, and two 120V AC ports.

INFORMATION

PRODUCT TYPE

Power Station

CABLE LENGTH

9' 4"

SKU

- 23105
- 98210

WEIGHT

- 1.5 lbs (680 g)
- 77.1 lbs (34.97 kg)

YETI TANK BATTERY DETAILS

- Lead Acid (AGM)
- 1200Wh (12V, 100Ah)

YETI TANK BATTERY CHARGE TIMES

Wall Charger (120W): 11hrs per tank

WARRANTY

12 Months

CELL CHEMISTRY

Li-ion NMC

YETI TANK PORTS

- Expansion port male connector (input/output) 100A Max
- Expansion port female connector (input/output) 100A Max

DIMENSION 1

- 15.5 x 7.5 x 10.5 in
- 39.37 x 19.05 x 26.67 cm

HIK PORTS

-Voltage: 120 Single-Phase -Frequency: 60 Hertz -Rated Amps: 15A @ 120 Volts (Single Phase) -Number of Circuit Breakers: 4 -Max Generator Input: 15 Amps -Maximum Wattage: 1875 Watts -Transfer Switch Circuits: 15A 120V -Circuit Breaker Protection: Each Circuit

DIMENSION 2

- 2.5 x 5.9 x 1.4 in
- 6.5 x 15 x 3.5 cm

DIMENSION 3

- 10.25 x 3.3 x 1.5 in
-  26 x 8.4 x 3.8 cm

Goalzero 6300Wh Home Backup System

GENERAL

-Simultaneous Recharge & Discharge: Yes -Operating usage temperature: 32-104 F (0-40 C) -Warranty: 2 years -Weight: 45.64 lbs (20.7 kg)

HIK GENERAL

-Made: USA -Enclosure: NEMA 1R -Conduit Length: 18 -UL Listed: Yes -Compatible with Yeti X and Yeti Lithium Power Stations 1000W and up

YETI LINK PORTS

- Do not exceed 22V input
- 8mm Charging Port (input): 14 - 22V Do not exceed 150W (10A) per port
- External Battery Connector (output): 65A charge controller
- External Battery Connector (Input/Output): 10.7-15V. Do not exceed 15V
- YETI X 120W POWER SUPPLY
- Input: AC Wall Plug 100-240V - 50/60Hz 3.0A
- Output: 8.0mm 16V- 7.5A, 120W

GAUGE

16AWG

POWER SUPPLY

YETI X 120W

 YETI LINK CHARGE TIMES

-Max Input from Yeti Tank to -Goal Zero Yeti 1000/1000X: 454-605W -Goal Zero Yeti 1400/1500X: 454-750W -Goal Zero Yeti 3000/3000X: 750W -Goal Zero Yeti 6000X: 750W

Goalzero 6300Wh Home Backup System

PORTS

- Input : -1x High Power Charging port (AC or Solar): 600W Max (14-50V, up to 50A) -2x 8mm charging port (AC or Solar): 150W Max (14-50V, up to 10A); Front face & under lid
- Input/Output :  -1x USB-C PD port: 60W Max (5 - 20V, up to 3.0A), regulated
- Output : -2x AC: 2000W, 3500W Surge (120VAC 60Hz, 16.5A), Pure Sine Wave -2x USB-A: 12W Max (5V, up to 2.4A), regulated -1x USB-C: 18W Max (5 - 12V, up to 3.0A), regulated -2x 6mm: 120W Max (12V, up to 10A), regulated -1x Car Port: 160W Max (12V, up to 13A), regulated -2x High Power Port: 360W Max (12V, up to 30A), regulated; Front face & under lid -Expansion Module Port: Under the lid -To be used with Goal Zero expansion modules only

Goalzero 6300Wh Home Backup System

BATTERY DETAILS

- Cell chemistry: Li-ion NMC
- Pack capacity: 1516Wh (10.8V, 140.4Ah)
- Single Cell Equivalent Capacity: 421Ah @ 3.6V
- Pack Lithium Content: 126g
- Lifecycles: 500 Cycles to 80% capacity (Discharge rate: 1C, Full charge/discharge, Temp: 25C)
- Shelf-life: Charge every 3-6 months
- Management system: MPPT charge controller

YETI LINK PORTS

-Do not exceed 22V input -8mm Charging Port (input): 14 - 22V Do not exceed 150W (10A) per port -External Battery Connector (output): 65A charge controller -External Battery Connector (Input/Output): 10.7-15V. Do not exceed 15V -YETI X 120W POWER SUPPLY -Input: AC Wall Plug 100-240V - 50/60Hz 3.0A -Output: 8.0mm 16V- 7.5A, 120W

Goalzero 6300Wh Home Backup System

SOLAR CHARGING (600W ACTUAL INPUT MAX)

- 100W Rated Panels (Boulder 100 BC/Nomad 100): 18-36 hours of sunlight
- 100W (Boulder/Nomad 100 (BC)): 18-36 Hours
- 200W Rated Panels (Boulder 200 BC/Nomad 200): 9-18 hours of sunlight
- 400W Rated Panels (2x Boulder BC/Nomad 200): 4-8 hours of sunlight
- 800W* Rated Panels (4x Nomad 200/etc.): 3-4 hours of sunlight
- 1200W* Rated Panels (4x Ranger 300/etc.): 3 hours of sunlight
- Rated Panel systems greater than 600W increase likelihood of yielding the max Yeti solar input throughout the day and in imperfect conditions

AC WALL CHARGERS (600W INPUT MAX)

- 120W Power Supply (Included): 14 hours
- 230W Power Supply (Add-on Purchase): 7 hours
- 600W Power Supply (Add-on Purchase): 3 hours

Goalzero 6300Wh Home Backup System

WHAT'S IN THE BOX

-Goal Zero Yeti 1500X Portable Power Station -120W Power Supply (AC Wall Charger) -Yeti Home Integration Kit -Yeti Link Expansion Module -(4x) Yeti Tank Expansion Battery -600W Fast Charge Power Supply

DETAIL

BACK UP YOUR HOME

- Customizable, versatile energy storage system backs up four essential circuits in your home and scales to meet your specific power needs.
- Power everything from lights in high-use rooms and fridges to medical devices, internet modems, and more. Integrate directly with your home's circuits for a more seamless backup power experience.

Goalzero 6300Wh Home Backup System

YETI HOME INTEGRATION KIT HIGHLIGHTS

- The Home Integration Kit (HIK) is a Reliance Pro/Tran 2 Series 15-Amp, 4-Circuit 120V Manual Transfer Switch - Customize your backup power by working with a licensed electrician and selecting up to 4 circuits from your breaker panel.
- Suggested circuits include fridge/freezer, garage door, outlets in main living areas, light switches, etc.
- Yeti Extension Cable includes 10ft 14AWG to connect your Yeti Portable Power Station.
