More than just a "side burner" Kalamazoo cooktops rival serious indoor ranges.

kalamazoogourmet Built-in Cooktop With Power Wok Burner
kalamazoogourmet Built-in Cooktop With Power Wok Burner

The power wok cooktop features one 26,000 BTU tri-ring burner and one 19,000 BTU brass burner. Install into masonry or one of our 24-inch modular cooktop cabinets.

information

BRAND

kalamazoogourmet

PRODUCT TYPE

Burner

PRODUCTION

Made in Italy

MATERIAL

Marine-grade stainless steel

DESIGN

Continuous grate design accommodates round-bottom woks

TOTAL BTUS

44,000 BTU liquid propane / 35,000 BTU natural gas

DIFFUSION

Diffusion cap on 19,000 BTU burner for superior simmering

COOKTOP BURNER

One 19,000 BTU cooktop burner

COVER INCLUDED

Stainless steel cover included

BATTERY

Battery-powered electronic ignition

TRIPLE-RING WOK BURNER

One 25,000 BTU triple-ring wok burner

OTHER DETAILS

- Stainless steel cover included
- Natural gas or liquid propane
- Built from heavy-gauge 304 stainless steel

DIMENSIONS

- Width : 16 in (407 mm)
- Depth : 28.38 in (720 mm)
- Height : 7 in (179 mm)

kalamazoogourmet Built-in Cooktop With Power Wok Burner

USE

For outdoor use only, do not install below overhead combustible surfaces

GAS REQUIREMENTS

-Natural Gas: 3/8" male NPT connection. 12 ft. (366 cm) gas hose with external regulator and quick disconnect provided. Gas service line to deliver 7 i.w.c. at grill location. See BTU information below for pipe sizing -Bulk Propane: 3/8" male NPT connection. 12 ft. (366 cm) gas hose with external regulator and quick disconnect provided. Gas service line to deliver 11 i.w.c. at grill location. See BTU information below for pipe sizing.

ELECTRICAL REQUIREMENTS

1.5V “AAA” battery x 1

kalamazoogourmet Built-in Cooktop With Power Wok Burner

SPECIFICATIONS & RESOURCES

- 44,000 total BTUs (LP)
- (1) 19,000 BTU cooktop burner
- 25,000 BTU triple-ring wok burner

CABINETS

Can be installed with masonry or Kalamazoo's range of 24-inch cooktop cabinets
