With sanitize and ultra wash & dual convection ultra dry

FEATURES

STATUS CENTER

Continue conversations without interruption and easily know when extra dinnerware is available via an LCD screen that displays the dishwasher cycle status.

Cafe Café™ Smart Stainless Steel Interior Dishwasher

STEAM + SANI

Save time with a steam and sanitize option that loosens tough soils before the wash cycle begins, so you get a complete wash with no pre-rinsing or soaking necessary. Plus, a sanitization cycle reduces 99.999% of bacteria on dishes.

Cafe Café™ Smart Stainless Steel Interior Dishwasher

ULTRA WASH & DUAL CONVECTION ULTRA DRY

Expect precision cleaning and superior dryness on fine china, dinnerware and even dishwasher-safe plastics, with exceptional features like Variable-Pressure Jets and Dual-Convection Ultra Dry to dry every item completely

LOADING FLEXIBILITY

A dishwasher with fold-down tines for uniquely shaped items and a third rack for extra capacity gives you the loading flexibility to store every dish how you want, and still get perfect results.

INFORMATION

BRAND

Cafe

PRODUCT TYPE

Dishwasher

CUSTOMIZABLE HARDWARE OPTIONS

Choose from six unique Café handle finishes to complement the rest of your kitchen, or your other Café appliances

Cafe Café™ Smart Stainless Steel Interior Dishwasher

CLAIMS & CERTIFICATIONS

-C
EC Regulated -Energy Star® Qualified -For California Residents California Prop 65 -Made in America 70 to 90% u.S. Content

COLOR APPEARANCE

Matte White

DOOR APPEARANCE

Full-length flat door

INSTALLATION

-B
uilt-Up Floor Capable -Flush Cabinet Installation -Side Installation or Top Installation Included

Cafe Café™ Smart Stainless Steel Interior Dishwasher

DIMENSIONS

- Overall Depth : 24 in
- Overall Height : 34 in
- Overall Width : 23 3/4 in
- Overall Depth with Handle : 27.40 in

OUTER WRAP

- Bitumen
- Full-wrap Blanket

FLOOR PROTECTION

Leak Defense with Active Flood Protect - Leak Pan with Sensor

CONTROL TYPE

- Top Controls
- 12 Touchpads
- Cap Touch Controls

CUTLERY TRAY

One piece removable 3rd rack

EXTERIOR STYLE

Traditional

DISHWASHER DRYING FEATURES

- Ultra/Normal/Off
- Fan Assist Dry
- Dual Convection Ultra Dry

RACK FEATURES

- Ball-Tipped Tines
- Adjustable Upper Rack
- Full Extension Slides - Upper
- 3-Piece Silverware Basket with Cell Covers
- 2 Utility Shelves with Stem Safe and Chop-stick slots - Upper

Cafe Café™ Smart Stainless Steel Interior Dishwasher

LEGS HEIGHT

-H
eight w/ Legs Retracted - Minimum Height : 33 3/8 in
-Height w/Legs Extended - Maximum Height : 34 5/8 in

DISHWASHER CONTROL FEATURES

-Multi function display -Last Cycle Memory -Audible End-of-Cycle Signal -Cycle Countdown with LCD Status Center on door

LATCH

Pull with Handle

LEVELING SYSTEM

3 Point Leveling

Cafe Café™ Smart Stainless Steel Interior Dishwasher

OU CERTIFIED

No

RACK COLOR

Black Pearl

DISPENSER

- Electronic Low Rinse Aid Sensor
- Rinse Aid with Indicator and Adjustment

DISHWASHER OPTIONS

- Delay Start 1-12 Hr.
- Lock Controls
- Sabbath Mode
- Hi-Temp Wash
- Heated Dry Off
- Normal Dry

- Start/Reset
- Bottle Wash
- Dual Convection Ultra Dry
- Wash Zone Upper Only
- Wash Zone Lower Only
- Presoak + Sanitize (Certified to NSF Standard 184)

NET WEIGHT

124 lb

NUMBER OF PLACE SETTINGS

Up to 16

DOOR INSULATION

Insulation Mastic

QUIET PACKAGE

39 dBA

MOTOR TYPE

Variable Speed

CALROD HEATER WATTS

1200/400

Cafe Café™ Smart Stainless Steel Interior Dishwasher

BUILT-IN WIFI DISHWASHER

Get the most out of your smart dishwasher with built-in WiFi powered by SmartHQ. Monitor performance, check status and automatically reorder detergent using your mobile device.

HANDLE COLOR

Brushed Bronze

HANDLE DESIGN

Customizable

Cafe Café™ Smart Stainless Steel Interior Dishwasher

NUMBER OF CYCLES

5

NUMBER OF OPTIONS

10

ADDITIONAL PROTECTION

- Active Flood Protect
- Leak Defense with Active Flood Protect

WARRANTY

- Labor Warranty : Limited 1-year entire appliance
- Parts Warranty : Limited 1-year entire appliance
- Warranty Notes : See written warranty for full details

CABINET WIDTH

24 in

APPROXIMATE SHIPPING WEIGHT

137 lb

AMPS

10.2A

WIFI CONNECT

Built-In

QUIET FEATURES

- Quiet Water Valve
- Sealed Toe Kick
- Tub Collar Trim

Cafe Café™ Smart Stainless Steel Interior Dishwasher

WASH SYSTEM

- 3-Level
- 800 Series

RACKING

- Material : Nylon
- System : Full 3rd rack

VOLTS

120V

HERTZ

60Hz

Cafe Café™ Smart Stainless Steel Interior Dishwasher

STYLE

Built-In Top Control

SHOWROOM POWER MODE

Yes

DISHWASHER CYCLES

- Auto
- Pots
- Normal
- China
- Express

WASH ARMS

- 3 Wash Levels
- Bottle Jets
- Middle - Quad Blade
- Jets - Variable Pressure
- Deep Clean Silverware Jets
- Deep Clean Silverware Jets

 UPPER RACK

- Ball-Tip Tines
- 1 Rack handle
- Chop stick slots
- 2 Stem Safe Shelves
- Premium Height Adjustable
- Fixed tines with Bottle Jets
- 1/2 fixed tines, 1/2 fold down tines

SABBATH MODE

Yes

SENSOR

Clean Sensor

WASH SYSTEM FEATURES

-H
idden Heater -Bottle Jets (4) -Drain Pump -Automatic HotStart -90+ Spray Jet Wash System -Deep Clean Silverware Jets -Quad Blade Middle Wash Arm  -Side Jets -Automatic Temperature Control -Variable Speed Dual Pumps and Motors -Hard Food Disposer with removable filter -Reversing Quad Blade Lower Wash Arm

Cafe Café™ Smart Stainless Steel Interior Dishwasher

ACCESSORIES

- CXADTH1PMCU Brushed Copper
- CXADTH1PMBT Brushed Black
- CXADTH1PMSS Brushed Stainless
- CXADTH1PMBZ Brushed Bronze
- CXADTH1PMCG Brushed Brass
- CXADTH1PMFB Flat Black

TUB

- Tub Type : Tall Tub
- Tub and Door Liner : Stainless Steel

WATER FILTRATION SYSTEM

- 100% Filtration with Hard Food
- Disposer and Removable Filter

COLORS

BASE COLORS

- Matte White
- Matte Black
- Stainless Steel

Cafe Café™ Smart Stainless Steel Interior Dishwasher
Matte White
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Matte Black
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Stainless Steel

HARDWARE

Cafe Café™ Smart Stainless Steel Interior Dishwasher
Brushed Bronze
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Brushed Copper
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Brushed Black
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Brushed Stainless
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Brushed Brass
Cafe Café™ Smart Stainless Steel Interior Dishwasher
Flat Black
