Jvc KS-DR3004 Amplifier

KS-DR3004 AMPLIFIER

Jvc KS-DR3004 Amplifier

KS-DR3004 AMPLIFIER

4-channel Power Amplifier

High power output drives the speakers to deliver dramatically high-quality sound. Easy upgradability is ensured with signal sensing turn-on function and abundant speaker inputs.

INFORMATION

BRAND

JVC

INPUT SENSITIVITY

0.2 - 15V

PRODUCT TYPE

Amplifier

ANTI-POP CIRCUIT

Yes

PROTECTION CIRCUITRY

Protection Circuitry (Thermal / Short Circuit / Overload / DC Offset) : Yes

DIMENSIONS

- Height : 52 cm
- Width : 322 cm
- Depth : 185 cm

Jvc KS-DR3004 Amplifier

MAXIMUM POWER OUTPUT

800W

CLASS

Class-AB

FREQUENCY RESPONSE (+0, -3DB)

5 - 50,000Hz

TOTAL HAMONIC DISTORTION


< 0.04%

SIGNAL-TO-NOISE RATIO (REFERENCE: 1W INTO 4 OHMS), CEA-2006 COMPLIANT

> 80dB

Jvc KS-DR3004 Amplifier

RMS POWER

- RMS Power Output (4 ohm) [ 1% THD 14.4V] : 60W x 4 (20 - 20,000Hz)
- RMS Power Output (2 ohm) [ 1% THD 14.4V] : 90W x 4 (20 - 20,000Hz)
- RMS Power Output (Bridged 4 ohm) [ 1% THD 14.4V] : 180W x 2 (1,000Hz)

HPF

120Hz (12dB)

LPF

80Hz (12dB)

Jvc KS-DR3004 Amplifier

HIGH LEVEL INPUT

Yes

RCA INPUT

-AL/AR -BL/BR

POWER CONTROL

High Level Input Auto Power Control : Yes

INSTALLATION

Speaker-level Inputs for Easy Installation : DR Series amplifiers feature speaker level inputs with Auto Turn-on function. Installation is possible without having to detach the receiver.

Jvc KS-DR3004 Amplifier

USE

Car Entertainment

TOROIDAL TRANSFORMER

Stable power supply is assured thanks to a large-size toroidal transformer. Its high winding density and low flux leakage improves conversion efficiency of the power. The result is natural and powerful music playback throughout the volume range.

Jvc KS-DR3004 Amplifier
