K-array Truffle-ktr26 Subwoofer

TRUFFLE-KTR26 SUBWOOFER

K-array Truffle-ktr26 Subwoofer

TRUFFLE-KTR26 SUBWOOFER

The Truffle-KTR26 is the largest model in the compact line of Truffle subwoofers applied when low-end sustain is needed. The source subwoofer has a frequency range of 45 Hz to 150 Hz and is comprised of a single 6.5" driver with passive radiators.

For a hidden installation, the Truffle-KTR26 was designed with an 12"-long cylindrical speaker box equipped with one 6.5" active driver on one end and one symmetrical 6.5" passive speaker on the opposite end, perfect for an omnidirectional low-end source. This subwoofer provides the low-end frequencies for the Azimut-KAMUT2V25 audio system.

INFORMATION

DRIVERS

6.5” ferrite magnet woofer with 1” voice coil + 6.5” passive radiator

BRAND

K-array

IP RATING

IP64

PRODUCT TYPE

Passive Subwoofer

PRODUCTION

Made In Italy

DIMENSIONS


- Height : 182 mm (7.1 in)
- Width : 176 mm (6.9 in)
- Depth : 341 mm (13.4 in)

K-array Truffle-ktr26 Subwoofer

WEIGHT

3.5 kg (7.72 lb)

MATERIAL

Aluminum

FINISHES

Powder Matte

RECOMMENDED AMPLIFIER

Kommander-KA02

TRANSDUCERS

6.5" woofer + passive radiator

K-array Truffle-ktr26 Subwoofer

FREQUENCY RESPONSE

- 45 Hz - 150
- 500 Hz (-6 dB)

MAX SPL

120 dB1

RATED POWER

100 W

COVERAGE

Omni

NOMINAL IMPEDANCE

2 Ω

K-array Truffle-ktr26 Subwoofer

CONNECTORS

2PIN euroblock connector (included)
