An Unobtrusive Talent

The Glassline extractor hood adds value to any kitchen with its timeless screen of shatterproof glass.

Whether in black or white, the decorative glass that hides the control element always makes a good impression. This is kitchen technology with real charm!

The really quiet Glassline built-in hood can work in exhaust air or recirculation mode as desired - the EcoSwitch control gives gourmet chefs space for total flexibility.

Perfect vapour capture is achieved thanks to BackFlow technology over the entire depth of the hob.

Berbel Glassline Hoods

INFORMATION

PEODUCT TYPE

Glassline Hoods

BRAND

Berbel

LED

4.7, 6.6 W

AVAILABLE WIDTHS

60, 90 cm

FREE-BLOWING FAN PERFORMANCE

650 m3/h

ACOUSTIC PRESSURE STAGE 3 (DB(A) RE 20 ΜPA)

52,53

SOUND LEVEL STAGE 3 (DB(A) RE 1 PW)

64

PERFORMANCE STAGES

3 + power stage (P)

FAN POWER CONSUMPTION

85 W

LIGHTING EFFICIENCY CLASS

A

FAT SEPARATION CLASS

B

Berbel Glassline Hoods

FLUID DYNAMIC EFFICIENCY CLASS

4.7, 6.6 W

AFTERRUN FUNCTION FOR RECIRCULATION MODE

Yes, Automatic

REC. DISTANCE FROM HOB

55 cm (gas hob > 65cm)

LED COLOUR TEMPERATURE

2,700 - 6,500  K

RECIRCULATION FILTER SATURATION INDICATOR

Yes

A DISCREET POWERHOUSE

The powerful combination of discreet optics and top vapour capture make the Glassline into a unique and particularly powerful built-in hood. The extendible screen and the supporting effect of the BackFlow technology ensure full vapour capture - even from the front cooking zones. Fitted with modern EC motors, the Glassline is energy-saving and quiet at the same time.

DOWNLOAD

↓ Data Sheet

PIPE CONNECTION

125 Ø in mm

LED HOB ILLUMINATION

204, 281 Lux

ENERGY EFFICIENCY CLASS

A

ANNUAL CONSUMPTION IN KWH

85 W

NET WEIGHT

16, 20 kg

SPECIAL EQUIPMENT

-Elegant EcoSwitch control enables easy switching between exhaust air and recirculation mode. -Intelligent solutions with the berbel wall box and/or window contact switch

STANDARD FEATURES

-Efficient and lastingly high rate of fat separation with the powerful berbel principle in combination with the effective CapillarTrap. -BackFlow technology for top vapour capture efficiency -Energy-saving and quiet thanks to a modern EC fan motor -Removable stainless steel collection tray and perfectly constructed interior for easy and fast cleaning -Elegant capacitive control panel - hidden behind the glass - that even responds if your fingers are wet -EcoSwitch preparation -LED hob illumination with adjustable colour temperature of 2,700 to 6,500 kelvin -Automatic afterrun function for long recirculation filter life -Energy saving function. The maximum power stage (P) automatically switches back to energy-saving stage 3 after a defined runtime.

TIMELESSLY MODERN

The clear optics and perfect impression result from the perfectly worked shatterproof glass of the front panel. The clean, seamless visual effect is enhanced by the fact that the control panel, which is completely behind the glass, is invisible when the hood is switched off. Only the on/off depression remains visible. This elegant built-in hood can also be installed in a top cupboard that is shorter than normal to achieve a clean line for the bottom edge of the top cupboards. Thanks to its slim form, enough space remains in the top cupboard for a spice rack.

Berbel Glassline Hoods
White Glass Decoration
Berbel Glassline Hoods
Black Glass Decoration
Berbel Glassline Hoods
Light

PLANNING INFORMATION

-Installation for cabinets with a side panel depth of 290 mm -Power supply of 230 V (power socket) must be planned
-Recommended worktop depth: max. 600 mm -For use BUF 125, the required installation height is 540 mm, for exhaust air at least 345 mm -Not suitable for use of external or intermediate fan (BackFlow technology without function)  -For mounting in 80 or 90 cm wall units, please order assembly aid -With an installation depth of 195 mm the fan box can be installed behind the spice rack -With recirculation, plan at least 100 mm space between wall unit and ceiling

Berbel Glassline Hoods

-Pipe connection Ø 125 mm, ideal for narrow exhaust air paths. For narrow exhaust air paths, e.g. Ø 100 mm, we recommend the berbel hybrid filter as a pressure relief valv
-For required installation dimensions, please refer to the product pages and/or the operating and assembly instructions!

MODES

RECIRCULATION

Recirculation mode is the most energy-saving operating mode. The air is cleaned by an odour filter and directed back into the room. The room temperature is not altered. It is also simple to implement, because wall penetrations and exhaust channels are not required. Due to their large volume, are especially efficient at odour-binding and absorb up to 95% of bad smells.

A further advantage of the berbel recirculation filter: only the proactive carbon needs to be changed – not the entire filter – and it only needs to be replaced every two to three years depending on how hard the filter has to work. The berbel refill pack is available for a cost-effective and environmentally friendly replacement.

Berbel Glassline Hoods

HYBRID

Combine the benefits of both exhaust air mode and recirculation mode. With the berbel EcoSwitch you can respond flexibly to your needs depending on cooking and weather conditions by using the EcoSwitch button on your berbel extractor hood to switch between energy-saving recirculation mode in winter and particularly effective exhaust air mode whenever you need: for instance during fast browning or throughout the summer months.

In addition to the berbel extractor hood with EcoSwitch you need the following system components for this:
- Berbel wall box
- optimised flow for extraction
- Berbel hybrid filter

Berbel Glassline Hoods

EXHAUST AIR

Exhaust air directed outside the building is particularly effective when it comes to the removal of odours, fumes and the moisture that results from cooking. It is advisable to use a berbel automatic wall sleeve to minimise heat loss. This seals and insulates the pipe outlet on the facade when the extractor hood is switched off.

The planning of the exhaust air flow path should be optimised, since this positively influences the efficiency and smooth running of the hood. The appropriate duct material for this can be found in the exhaust air accessories section.
