Xmg Xmg Focus 16 Laptop

XMG FOCUS 16 LAPTOP

XMG FOCUS 16 LAPTOP

The essence of gaming

Xmg Xmg Focus 16 Laptop

Even more power and a high-resolution WQHD display in 16:10 format: With a high-end CPU from Intel and cutting-edge NVIDIA graphics cards, the XMG FOCUS 16 delivers strong performance for gaming and demanding multimedia tasks.

The long list of optimisations includes an upgrade to Intel’s 24-core Core i9-13900HX processor, powerful graphics cards up to the GeForce RTX 4070 and a fundamentally redesigned cooling system for improved performance deployment.

In view of this equipment, the FOCUS 16 covers a wide range of applications; in addition, a 35 % larger 73Wh battery ensures significantly longer runtimes. The all-round robust laptop chassis is completed with timeless design and an aluminium display lid.

FEATURES

Xmg Xmg Focus 16 Laptop

WI-FI 6E

Wi-Fi 6E puts you in the wireless fast lane! Unlike older standards, your wireless network communication no longer runs exclusively in the congested 2.4 GHz and 5 GHz frequency bands. Thanks to additional 6 GHz technology, you can take advantage of a significantly higher data throughput, a more stable wireless connection and reduced latency.

Xmg Xmg Focus 16 Laptop

THUNDERBOLT 4

Thunderbolt 4 is much more than a high-speed interface for data exchange with the fastest external SSDs. With its integrated DisplayPort stream coupled to the efficient iGPU, the slot allows you to output images to two 4K-capable external monitors or even connect the most powerful, multifunctional docking stations: This way, you can connect your laptop to your desk or your work environment in a flash and with just one cable – including multi-monitor setups, network connection, printer, mouse and keyboard.

Xmg Xmg Focus 16 Laptop

UP TO 2 SSDS & 64 GB RAM

Generous memory

Thanks to its flexible memory options, the XMG FOCUS 16 can be perfectly tailored to your personal requirements. The laptop has two SO-DIMM slots for a maximum of 64 GB DDR5 memory. It also offers space for two NVMe SSDs with lightning-fast PCI Express 4.0 connection. Subsequent upgrading of the storage components is easilly possible, because the inside of the chassis is easily accessible.

Xmg Xmg Focus 16 Laptop

OPTIMAL HEADPHONE SOUND

Powerful soundscapes

To give you the best possible sound on your headphones and the most immersive gaming experience possible, the XMG FOCUS 16 uses Creative Sound Blaster technology to customise sound. With the Sound Blaster Studio app, you can access optimised sound profiles for gaming, movies or music, adjust the sound separately for speakers and headset to your individual taste, and get features to enhance voice transmissions.

INTEL CORE I9-13900HX

CPU power with 24 cores

Equipped with Intel’s Core i9-13900HX, the XMG FOCUS 16 offers you outstanding CPU performance. With 24 cores, 32 threads, a whopping 36 MB cache and a boost clock of up to 5.4 GHz, the processor delivers impressive single and multi-core performance.

The high-end CPU from the HX series stands out more clearly than ever before from the conventional H series with only up to 14 cores, being much more than just a refresh to the latest generation.

Xmg Xmg Focus 16 Laptop

NVIDIA GEFORCE RTX 40

Maximum performance with DLSS 3

NVIDIA’s GeForce RTX 40 graphics cards ignite an explosion of innovation, delivering significantly more FPS in your games across all performance classes. The top configuration variant of the XMG FOCUS 16 uses the very powerful RTX 4070, although an RTX 4060 or RTX 4050 already provide a lot of performance – in each case in the maximum configuration with 140 watts of graphics power.

You can fire up the turbo with DLSS 3 as an exclusive feature of the RTX 40 series: The AI technology generates additional, high-quality frames so that your gaming experience remains exceptionally smooth even at high resolutions and with activated ray tracing effects.

Xmg Xmg Focus 16 Laptop

MUX-SWITCH &

Advanced Optimus

Advanced Optimus switches the connection of the laptop display between the powerful NVIDIA graphics chip and the efficient, integrated GPU of the processor completely automatic and during operation.

When gaming, you benefit from the direct connection to the dGPU through higher performance and minimised input lag. Switching to the iGPU, on the other hand, allows for more efficient operation and thus longer battery runtimes. In addition to automatic switching via Advanced Optimus, you can also adjust the connection manually via a MUX switch.

Xmg Xmg Focus 16 Laptop

ALL PORTS ON BOARD

Ultra-flexible and equipped with the latest technology: With two USB-A and two USB-C ports, Mini DisplayPort and HDMI, Gigabit Ethernet and Wi-Fi 6E as well as a microSD card reader, the XMG FOCUS 16 is well equipped in terms of connections. Since one of the two USB-C ports provides Thunderbolt 4, you can connect up to three external monitors natively.

In addition, the laptop not only has a high-resolution Full HD webcam, but also separate audio ports for headphones (compatible with combination plug headsets) and microphone. The Mini DisplayPort and HDMI are directly connected to the powerful NVIDIA graphics card, making the FOCUS 16 VR Ready.

Xmg Xmg Focus 16 Laptop

G-SYNC DISPLAY WITH 165 HZ

High resolution in 16:10

The 16-inch IPS display of the XMG FOCUS 16 is one of the highlights of this modern laptop. With 2560 x 1600 pixels, the 16:10 panel displays your games or multimedia content with impressive sharpness and excels with a high brightness of 500 nits.

A 165 Hz fast refresh rate and NVIDIA G-SYNC ensure smooth gaming with a wow effect. The extended resolution, smart format and 95 % coverage of the sRGB colour space also provide the right basis for ambitious image and video editing.

Xmg Xmg Focus 16 Laptop

INFORMATION

BRAND

Xmg

PRODUCT TYPE

Laptop

MEMORY

2x DDR5 SO-DIMM | Dual Channel | max. 64 GB | max. 5600 MHz* | max. 1.1 V

DRIVER

We continuously provide you with the latest driver versions in the download portal of our company headquarters Schenker Technologies GmbH.

DIMENSIONS

- Height : 27.5 mm
- Width : 359.5 mm
- Depth : 263.8 mm

PRODUCT ID

XFO16E23

PRODUCTION

Made in Germany

AUDIO

- Stereo speakers
- Sound Blaster Studio
- Microphone with noise cancelling

      FREQUENCY BANDS

      2.4 GHz and 5 GHz

      CACHE

      36 MB cache

      POWER SUPPLY

      280 watts (181 x 85 x 35 mm | 995 g incl. EU power cable)

      STORAGE

      2x M.2 2280 SSD via PCI Express 4.0 x4 (suppports RAID 0/1)

      KEYBOARD

      Backlit keyboard with full-fledged numeric keypad and full-size arrow keys, 15 colour options

      TOUCHPAD

      Microsoft Precision Touchpad, two integrated buttons | 119 x 71 mm (W x D)

      CHASSIS

      -One-hand opening -PH 0 screw heads -130° display opening angle -Display lid made of aluminium -Display frame, top and bottom case made of plastic

      BATTERY

      -Changeable 73 Wh Li-Poly-battery (internally screwed) -Different battery charging profiles settable in control center or bios (flexicharger)

      PROCESSORS

      -Intel Core i9-13900HX -8 P- & 16 E-cores/32 threads -Up to 5.4 GHz -36 MB cache -55+ W TDP

      COMMUNICATION

      -Realtek Gigabit LAN -Wi-Fi 6E + Bluetooth 5 -Full HD webcam with Temporal Noise Reduction

      USE

      Game

      WEIGHT

      Ca. 2.6 kg

       DISPLAYS

      16.0″ IPS | 2560×1600 px (16:10) | 165 Hz (alternatively 60 Hz settable) | G-SYNC | 500 nits | 95 % sRGB | non-glare

      SECURITY

      - Kensington Lock (left)
      - TPM 2.0 (via dTPM)

      INCLUDED IN BOX

      - Laptop (inkl. Akku)
      - Netzteil
      - Treiber-USB-Stick

      PORTS (CLOCKWISE)

      LEFT

      -Mic-in -Usb-a 2.0 -Usb-a 3.2 gen1 -Headphone-out (compatible with combo jack headsets)

      REAR

      -DC-in -Mini DisplayPort 1.4a (G-SYNC compatible) -HDMI 2.1 (G-SYNC compatible | HDCP 2.3) -USB-C 3.2 Gen2×1 (DisplayPort: no | Power Delivery: no)

      RIGHT

      -RJ45 Port (LAN) -MicroSD card reader -Thunderbolt 4/USB-C 4.0 Gen3×1* (DisplayPort 1.4a: yes | Power Delivery: no)

      GRAPHICS

      -Intel Iris UHD Graphics | 32 Execution Units | integrated (iGPU) -NVIDIA GeForce RTX 4050 | 6 GB GDDR6 | 115 W TGP* (+ 25 W Dynamic Boost) | dedicated (dGPU) -NVIDIA GeForce RTX 4060 | 8 GB GDDR6 | 115 W TGP* (+ 25 W Dynamic Boost) | dedicated (dGPU) -NVIDIA GeForce RTX 4070 | 8 GB GDDR6 | 115 W TGP* (+ 25 W Dynamic Boost) | dedicated (dGPU) -VR Ready -3 external displays directly addressable

      -HDMI, Mini DisplayPort connection : dGPU
      -DP via TB4/USB-C connection : iGPU with NVIDIA Optimus
      -Display connection : iGPU with NVIDIA Optimus or dGPU (via Advanced Optimus/MUX-Switch)
