Austroflamm Clou compact Stove
CLOU COMPACT STOVE
CLOU COMPACT STOVE
There has been an addition to the clou family, which is one more model richer with the clou compact. With small dimensions and somewhat lower heat output, but no less original, the Clou Compact yields to its big brother in nothing.
INFORMATION
BRAND
Austroflamm
PRODUCT TYPE
Stove
COLLECTION
Clou
MATERIAL
Steel
SIDE PANEL VERSION
Steel
BALANCED FLUE - DIBT (GERMAN INSTITUTE FOR STRUCTURAL ENGINEERING)
Yes
DIMENSIONS FIREBO
- Width : 349 mm
- Height : 328 mm
- Depth : 225 mm
WEIGHT STM
114 kg
FLUE PIPE OUTLET
130 mm
SAFETY DISTANCES TO COMBUSTIBLE MATERIAL
- Front : 1000 mm
- Side : 250 mm
- Rear : 150 mm
DIMENSIONS A, B, C, D
- A : 15166 mm
- B : 880 mm
- C : 574 mm
- D : 189 mm
DIMENSIONS
- Height : 1047 mm
- Width : 520 mm
- Depth : 380 mm
FLUE PIPE CONNECTION, MIDDLE
880 mm
RECOMMENDED FUELS
Billet wood
TESTING
-Certificate/Green flame green : 7 *
-Federal Emission Control Ordinance Level : 1+2
TECHNICAL DRAWING
RECOMMENDED FUELS
Billet Wood
AIR REGULATION
Single-handed air regulation
DATA FOR THE CHIMNEY SWEEP
- Total flue gas flow, closed [g/s] : 5.43
- Flue gas temperature, closed : 322
- Minimum feed pressure at nominal heat efficiency, closed [Pa] : 13
- at 0.8 times nominal heat efficiency [Pa] : 10
HEAT OUTPUT
- Min. Heat Output : 3.5kw
- Max. Heat Output : 8 kw
ENERGY EFFICIENCY CLASS
A
NOMINAL HEAT EFFICIENCY
6.0 kw
ROOM HEATING CAPACITY (DEPENDING ON THE BUILDING INSULATION)
65 - 165 m³
GLASS SHAPE
Round
CURVED GLASS
Flat
