Monogram 30" Minimalist Double Wall Oven ZTDX1DSSNSS
MONOGRAM 30" MINIMALIST DOUBLE WALL OVEN ZTDX1DSSNSS
FEATURES
LCD CONTROLS
Adjust oven settings with little effort with a Brilliant 7" LCD display that allows you to customize backgrounds and receive weather updates
WIFI POWERED BY SMARTHQ™
Perfectly in sync with a busy lifestyle, Alexa or Google Home can be used to control an array of oven functions from both inside and outside the home
PRECISION COOKING MODES
Master new recipes and perfectly execute favorite dishes using this ultra-smart system that automatically tracks cooking progress, modifies temperatures and adjusts cook times
ALSO INCLUDES
-No-Preheat Air Fry : A must-have for health-conscious cooks, the No-Preheat Air Fry mode crisps food to crunchy perfection, without using oils or butter
-Twin Convection with Direct Air : Achieve beautifully cooked and delicious meals every time with this expertly designed, third heating element and fan combination
-10.0 cubic foot oven capacity (5.0 each oven) : Easily accommodates even the largest meals
-Ten-pass bake element : Covers more surface area for more even baking results
-Ten-pass dual broil element : Evenly browns dishes of all types and sizes
-Self-clean with Steam Clean option : Gives you flexible options for thorough oven cleaning
INFORMATION
BRAND
Monogram
PRODUCT TYPE
Oven
CAPACITY
-Capacity (Cu. Ft.) : 5.0 Upper / 5.0 Lower
-Total Capacity (cubic feet) : 10 cu ft
CONNECTED CAPABILITIES
Amazon Alexa Fresco IFTTT Innit Sonos The Google Assistant
OVEN COOKING MODES
Convection Bake Multi-Rack Convection Broil Hi/Lo Convection Roast Dehydrate Keep Warm No-Preheat Air Frying Precision Cooking Modes Proof Thermal Bake Thermal Broil Hi/Lo
NET WEIGHT
364 lb
APPROXIMATE SHIPPING WEIGHT
390 lb
CABINET WIDTH
30 in
COOKING SYSTEM
Twin Fan, True European Convection with Direct Air (Both Ovens) Variable Speed, Reverse Air Convection (Both Ovens)
OVEN INTERIOR
2 LED Light Columns (Both Ovens) Black Gloss Finish True Hidden Bake Element (Both Ovens)
OVEN CONTROL FEATURES
12-Hour Shut-Off Capability Audible Preheat Signal Auto Recipe Conversion Certified Sabbath Mode Control Lock Capability Cook Time C° or F° Programmable Delay Time Electronic Clock & Kitchen Timer Mis-Wire Detection Proof Mode Remote Enabled Scan-to-cook Temperature Probe Warm Mode
CUTOUT DIMENSIONS
28-5/8 x 50-1/4 x 23-1/2 in
OVEN INTERIOR DIMENSIONS
Lower : 25 x 17-3/8 x 20 1/4
APPEARANCE
- Design Style : Minimalist Collection
- Installation : Flush Appearance Over Warming Drawer Side-by-Side
- Color Appearance : Stainless Steel
- Frameless Oven Door(s) : Stainless Steel Finish/Appearance
OVEN INTERIOR DIMENSIONS
- Upper : 25 x 17-3/8 x 20 1/4
WIFI CONNECT
Built-In
DOWNLOADS
↓ Manual
↓ Quick Specs
↓ Installation Instructions
↓ 2d Cad - Elevation
↓ 2d Cad - Plan
↓ 3d Cad
CONFIGURATION
Double Oven
FUEL TYPE
Electric
WARRANTY
- Labor Warranty : Limited 2-year entire appliance
- Parts Warranty : Limited 2-year entire appliance
- Warranty Notes : See written warranty for full details
OVEN RACK FEATURES
1 Self-Clean Heavy-Duty Rack (Both Ovens) 2 Self-Clean Heavy-Duty, Full Extension Oven Racks (Both Ovens) Ladder-Rack Positions (Both Ovens)
POWER / RATINGS
- KW Rating at 208V : 6.8
- KW Rating at 240V : 9
- Amp Rating at 208V : 40
- Bake Wattage : 2850W
- Broiler Wattage : 4300W; Dual Element
- Convection Wattage : 1300W
KEY FEATURES
- Control Type : 7" Full-Color Touch LCD Screen
- Short Description : 30" Convection Double Wall Oven
- Cooking Technology : Convection
- Cleaning Time : Variable with Delay Clean Option
- Oven Features : 10-Pass Bake Element 10-Pass Dual Broil Element Closed Door Broiling
- Self-Clean Oven Door Lock : Automatic
- Oven Cleaning Type : Self-Clean with Steam Clean Option
- Oven Rack Positions (Single or Upper/Lower) : 6 / 6
