Monogram Monogram 48" Professional Gas Rangetop With 6 Burners And Griddle
MONOGRAM 48" PROFESSIONAL GAS RANGETOP WITH 6 BURNERS AND GRIDDLE
MONOGRAM 48" PROFESSIONAL GAS RANGETOP WITH 6 BURNERS AND GRIDDLE
ZGU486NDTSS
FEATURES
VERSATILE GAS BURNER CONFIGURATION
Delivering exceptional cooking flexibility, the two 23,000-BTU multi-ring brass burners and dual-stack burners offer a range of heat settings, from gentle simmer to intense flame
3-PIECE GRATES WITH REVERSIBLE WOK FEATURE
Reversible grates are easy to clean and complement different culinary techniques, with a flat side for traditional cooking and contoured side that perfectly holds round-bottom woks
RING-LIT KNOBS
Delivering a modern approach to accent lighting, the rings illuminate to indicate when a burner is in use
SOLID BRASS BLADES ON PRECISION MACHINED KNOBS
With an unmatched attention to detail, all knobs on the new Monogram Pro ranges and range tops come with solid brass accents
SOLID BRASS BURNERS
Monogram burners are constructed of 100% brass, embracing the natural thermal properties of this premium quality material. As they are exposed to heat, a natural patina will build up to protect the burners from corrosion and ensure that your brass burners will withstand even the highest temperatures
SEAMLESS STAINLESS TOP FRAME
Meticulously crafted from one piece of stainless steel that covers the cooktop and control panel, this seamless and stylish surface is easy to clean and beautiful to look at
STAINLESS AND ALUMINUM-CLAD GRIDDLE INCLUDED
This versatile griddle delivers 18,000 BTUs of cooking power, allowing fast and consistent heating across the entire cooking surface
INFORMATION
BRAND
Monogram
PRODUCT TYPE
Burner
GRIDDLE
18,000-BTU Stainless Steel and Aluminum Clad Thermostatically Controlled
COOKTOP BURNER GRATE FEATURES
Porcelainized Cast Iron 3-Piece Reversible (Flat/Wok) Grates
CONTROL LOCATION
Upfront
IGNITION SYSTEM
Electronic
FUEL TYPE
Natural Gas (factory set)
AUTOMATIC RE-IGNITION
Yes
140 DEG. SIMMER BURNER
All Burners - Adjustabl
REMOVABLE DRIP TRAY LINERS
(1) Beneath Griddle
CABINET WIDTH
48 in
WEIGHT
171 lb
DIMENSION
- Overall Depth : 27 1/2 in
- Overall Height : 8 1/2 in
- Overall Width : 47 7/8 in
APPROXIMATE SHIPPING WEIGHT
227 lb
SHORT DESCRIPTION
48" Pro Rangetop with Griddle
APPEARANCE
-Installation : Side-by-Side
-Design Style : Statement Collection
-Color Appearance : Stainless Steel
-Control Knobs : Diecast Metallic (Included) Stainless Steel with Brass Accents
WARRANTY
-Labor Warranty : Limited 2-year entire appliance
-Warranty Notes : See written warranty for full details
-Parts Warranty : Limited 2-year entire appliance Limited 5-year gas surface burners
BURNER INDICATOR LIGHT
Yes
EXTRA LOW SIMMER
All Burners - Adjustable
CONFIGURATION
6 Burners; Griddle
STAINLESS STEEL GRILL / GRIDDLE COVERS
1
POWER / RATINGS
- Volts/Hertz/Amps : 120v; 60Hz; 15A
- Griddle BTU Rating (000's/BTU) - LP Gas : 16.0
- Griddle BTU Rating (000's/BTU) - Natural Gas : 18.0
- Top Burner BTU Rating - LP (000's BTU's) : (2) 21.0; (2) 12.0
- Top Burner BTU Rating - Nat. Gas (000's BTU's) : (2) 23.0; (2) 15.0
COOKTOP BURNER GRATE FEATURES
Porcelainized Cast Iron 3-Piece Reversible (Flat/Wok) Grates
COOKTOP BURNER TYPE
2 Sealed, Dual Flame Stacked (Removable Brass Accents) 2 Sealed, Dual Ring
ACCESSORIES
-High Altitude Kit : WB28K10553
-Conversion Kit : Included - Nat. Gas to LP
-Factory-installed island backguard : Yes
-48" Monogram Knob Kit : ZXPR48KKTSS (SS, qty. 11)
-Optional Grill Accessory (Cast Iron) : UXPRRGG
-Optional Backguard : 12" stainless steel backsplash (UX12BS48PSS) 30"-36" adjustable stainless steel backsplash with warming shelf (UXADJB48PSS)
