Marshall SC20H Amplifier

SC20H AMPLIFIER

SC20H AMPLIFIER

Get the unmistakable JCM®800 roar without upsetting the neighbours with the SC20H. This 20W head captures the spirit of the JCM800 range at a smaller size. Perfect for playing in the studio, or at home with the power reduction option set to 5W, make sure to pair the SC20H with one of our Studio cabinets for a small but perfectly formed Marshall rig.

Marshall SC20H Amplifier

FEATURES

Marshall SC20H Amplifier

UK-MADE AND ALL-VALVE

The SC20H is made in the very same factory as the JCM800s have been since they were first introduced in the 80s. The instantly recognisable tone is driven by two ECC83 preamp valves, an ECC83 phase splitter and two EL34 valves in the power amp.

Marshall SC20H Amplifier

SINGLE CHANNEL SIMPLICITY

Choose either the high input or low input to suit your guitar and style. Ride the preamp volume to take you from warm cleans to barky overdrive and take that iconic Marshall tone anywhere. Just like the older JCM800s, the Studio Classic® features a master volume control for those that want to ramp up the sound. There’s also an effects loop for easily personalising your sound.

Marshall SC20H Amplifier

NO CREW REQUIRED

The SC20H is significantly smaller and lighter than its 100W counterparts, making it easy to transport. Complete the setup with the compact SC112 or SC212 cabinets.

Marshall SC20H Amplifier

POWER REDUCTION

Choose between 20W and 5W power output at the flick of a switch. Perfect for jumping from the rehearsal room to the living room and back again.

INFORMATION

BRAND

Marshall

PRODUCT TYPE

Speaker

OUTPUT WATTAGE

20W (with power reduction option to 5W)

MODEL

SC20H

RANGE

Studio

CONTROLS

- Presence
- Bass
- Middle
- Treble
- Master volume
- Preamp volume

Marshall SC20H Amplifier

DIMENSIONS

- Width : 510mm / 20.1""
- Height : 240mm / 9.4"
- Depth : 240mm / 9.4"

OUTPUTS

5 x 1/4” jack sockets, selectable 16Ω / 8Ω / 4Ω load

EFFECTS

None

EFFECTS LOOP

Yes, Series, Send/Return

INPUTS

2 x 1/4" jack instrument inputs (high/low sensitivity)

Marshall SC20H Amplifier

CABLE

Detachable power cable included, speaker cable included

SPEAKER CONFIGURATION

1x10

SPEAKER MODEL

Celestion VT-Junior (16Ω, 50W)

PREAMP VALVES

2 x ECC83, 1 x ECC83 (phase splitter)

https://www.archiproducts.com/en/productsPRODUCTION

Made in United Kingdom

WEIGHT

9.4 kg / 20.7 lbs

POWER AMP VALVES

2 x EL34
