Monogram Monogram 48" Dual-Fuel Professional Range with 4 Burners, Grill, and Griddle ZDP484NGTSS

MONOGRAM 48" DUAL-FUEL PROFESSIONAL RANGE WITH 4 BURNERS, GRILL, AND GRIDDLE

Monogram Monogram 48\

MONOGRAM 48" DUAL-FUEL PROFESSIONAL RANGE WITH 4 BURNERS, GRILL, AND GRIDDLE

ZDP484NGTSS

FEATURES

BUILT-IN WIFI, POWERED BY SMARTHQ™ APP

Perfectly in sync with your busy lifestyle, connect, control, and manage your oven from anywhere with your smartphone or tablet.

Monogram Monogram 48\

BETTER WHEN CONNECTED

Downloadable upgrades ensure your oven is always enhanced with the latest features, like Air Fry and Precision Cooking Modes

Monogram Monogram 48\

INDUSTRY EXCLUSIVE—TRUETEMP™ BURNER

This powerful 21,000 BTU gas burner offers a precision temperature-management system that works with Hestan Cue™ cookware for a consistently delicious cooking experience.Hestan Cue cookware comes free if you register and connect your appliance through the SmartHQ app

VERSATILE GAS BURNER CONFIGURATION

Delivering exceptional cooking flexibility, the 21,000 and 23,000-BTU multi-ring brass burners and dual-stack burners offer a range of heat settings, from gentle simmer to intense flame

Monogram Monogram 48\

SOLID BRASS BURNERS

Monogram burners are constructed of 100% brass, embracing the natural thermal properties of this premium quality material. As they are exposed to heat, a natural patina will build up to protect the burners from corrosion and ensure that your brass burners will withstand even the highest temperatures

Monogram Monogram 48\

3-PIECE GRATES WITH REVERSIBLE WOK FEATURE

Reversible grates are easy to clean and complement different culinary techniques, with a flat side for traditional cooking and contoured side that perfectly holds round-bottom woks

Monogram Monogram 48\

HOT AIR FRY

A must-have for health-conscious cooks, the Hot Air Fry mode crisps food to crunchy perfection, without using oils or butter

INFORMATION

BRAND

Monogram

PRODUCT TYPE

Burner

GRIDDLE

18,000-BTU Stainless Steel and Aluminum Clad Thermostatically Controlled

CONTROL TYPE

7" Full-Color Touch LCD Screen Digital Temperature Display with Timer Display (Both Ovens)

WIFI CONNECT

Built-In

INDICATOR LIGHTS

Burner "On"

Monogram Monogram 48\

IGNITION SYSTEM

Electronic w/Auto Reignition

FUEL TYPE

Dual Fuel (with natural gas)

Monogram Monogram 48\

CABINET WIDTH

48 in

HEIGHT TO COOKING SURFACE

35 1/4 to 36 3/4

LIGHTING

Customizable LED Bullnose and Knob Accent Lighting

DIMENSION

- Overall Depth : 27 1/2 in
- Overall Height : 8 1/2 in
- Overall Width : 47 7/8 in

Monogram Monogram 48\

COOKING SYSTEM

Reverse Air Convection True European Convection

SHORT DESCRIPTION

48" Pro Range - Dual Fuel with 4 Burners, Grill and Griddle

CONNECTED CAPABILITIES

Amazon Alexa Bluetooth Fresco Hestan Cue IFTTT Innit Sonos The Google Assistant

COOKING TECHNOLOGY

Convection

WEIGHT

576 lb

OVEN COOKING MODES

Convection Bake Multi-Rack (Both Ovens) Convection Broil Hi/Lo (Both Ovens) Convection Roast (Both Ovens) No-Preheat Air Frying (Both Ovens) Precision Cooking Modes Proof (Both Ovens) Scan-to-Cook Warming (Both Ovens)

INTERIOR OVEN LIGHT

3 Halogen Lamps (Everyday Oven) 6 Halogen Lamps (Caterer Oven)

GRILL

14,000-BTU Cast-Iron Reversible Grill Grate

HEIGHT WITH LEGS RETRACTED

35 1/4 in

CLEANING TIME

3-5 Hours (Both Ovens)

COOKTOP SURFACE

Porcelain-Enamel

OVEN CONTROL FEATURES

12-Hour Shut-Off Capability Audible Preheat Signal Auto Recipe Conversion Automatic Oven Meat Probe (Both Ovens) Certified Sabbath Mode Chef Connect Cook Time C° or F° Programmable Delay Clean Option (Both Ovens) Probe Mode Proof Mode (Both Ovens) Remote Enabled Self & Steam Clean Modes Timer WiFi Connect

OVEN FEATURES

4-Pass Bake Element (Everyday Oven) 4-Pass Broil Element (Everyday Oven) 8-Pass Bake Element 8-Pass Broil Element Hidden Bake

COOKTOP BURNER GRATE FEATURES

Continuous Grates Porcelainized Cast Iron 3-Piece Reversible (Flat/Wok) Grates

COOKTOP BURNER TYPE

2 Sealed, Dual Flame Stacked 2 Sealed, Dual Flame Stacked (Removable Brass Accents) Front Right TrueTemp™ Burner

SELF-CLEAN OVEN DOOR LOCK

Automatic

140 DEG. SIMMER BURNER

All Burners - Adjustable

APPEARANCE

- Toe kick : Included
- Design Style : Statement Collection
- Color Appearance : Stainless Steel
- Oven Door Features : Soft Close Door
- Oven Door Features : Soft Close Door- Control Knobs : Diecast Metallic (Included) Stainless Steel with Brass Accents

OVEN RACK FEATURES

3 Self-Clean Oven Racks (Caterer Oven), 2 Self-Clean Oven Racks (Everyday Oven) 4 Rack Positions (Everyday Oven) 5 Rack Positions (Caterer Oven) Full-Extension

OVEN CLEANING TYPE

Self-Clean (Both Ovens) Steam Clean (Both Ovens)

REMOVABLE GREASE TROUGH

(2) Beneath Grill and Griddle

COOKTOP TYPE

4 Burners Griddle Grill

STAINLESS STEEL GRILL  COVERS

2

CONVECTION ROASTING RACK

Yes

Monogram Monogram 48\

ADJUSTABLE CERAMIC IR GRILL

Yes

BROILER PAN AND GRID

2

WARRANTY

-Labor Warranty : Limited 2-year entire appliance
-Warranty Notes : See written warranty for full details
-Parts Warranty : Limited 2-year entire appliance Limited 5-year gas surface burners

ADJUSTABLE CERAMIC IR GRILL

Yes

BROILER PAN AND GRID

2

Monogram Monogram 48\

TOTAL CAPACITY (CUBIC FEET)

8.25 cu ft

EXTRA LOW SIMMER

All Burners - Adjustable

OVEN RACK POSITIONS (SINGLE OR UPPER/LOWER)

5 / 4

HEIGHT W/LEGS EXTENDED - MAXIMUM HEIGHT

36 3/4 in

CAPACITY (CU. FT.)

5.75 Caterer Oven / 2.5 Everyday Oven
