Pro-Ject Juke Box E1 Record Player w/ Receiver

UKE BOX E1 RECORD PLAYER W/ RECEIVER

Pro-Ject Juke Box E1 Record Player w/ Receiver

UKE BOX E1 RECORD PLAYER W/ RECEIVER

A Turntable, Phono Preamp, Line Preamp, Power Amp & Bluetooth Receiver in One Chassis

Juke Box E1 is record player, phono stage, Bluetooth receiver, line preamplifier and power amplifier in one chassis, requiring only a pair of speakers and cables to complete the system.

If you thought that a starter turntable system is complicated to set up, Juke Box E1 will show you otherwise. This great-sounding belt-drive deck comes with the Ortofon OM 5E cartridge mounted & aligned, the tracking force & anti-skate set.

Pro-Ject Juke Box E1 Record Player w/ Receiver

INFORMATION

BRAND

Pro-Ject

PRODUCT TYPE

Vinyl Player

PRODUCTION

Made in United States

COLLECTION

Juke

USE

Entertainment

Pro-Ject Juke Box E1 Record Player w/ Receiver

FEATURES

-Reworked tonearm & headshell design -Anti-resonant ABS polymer main platter -Damped DC moto -Electronic speed change -Instant playback with super-easy setup -Bluetooth, 1 line input, 1 line output -High-contrast display -Gold-plated sockets -Pre-adjusted tracking force & anti-skating
-Pre-mounted Ortofon OM 5E cartridge -Belt drive with silicone belt
-Special feet for effective decoupling -Acrylic dust cover included -IR remote control included -Handmade in Europe

WOW & FLUTTER

- 33: 0,25%
- 45: 0,23%

POWER OUTPUT

2 x 50W (4 ohms)

POWER CONSUMPTION

110W max

 SPEED VARIANCE

- 0.7% (33rpm)
- 0.6% (45rpm)

WEIGHT

5 kg

OVERHANG

22.0 mm

Pro-Ject Juke Box E1 Record Player w/ Receiver

DIMENSIONS

- Width : 415 mm
- Height : 118 mm
- Depth : 334 mm

DETAIL

These are the trickiest parts of turntable setup & we’ve taken care of them for you. An acrylic dust cover is also included. Available in high-gloss black, red or white.

INPUTS

BT, 1x line (analog)

SPEED

33, 45 (electronic speed change)

PRINCIPLE

Belt Drive

OUTPUTS

Speaker, line out (fixed), phono out

TONEARM

8.6″ aluminum

PLATTER

300mm anti-resonant ABS polymer

SOUND ADJUSTMENTS

With the supplied remote control you can not only switch inputs, power off/on and adjust the volume. You can also fine-tune as you listen. Press the ‘Loudness’ button to use a default preset or adjust the treble & bass to your liking.

INCLUDED

- Power supply
- Dust cover
- Remote

EFFECTIVE ARM LENGTH

218.5mm

AVAILABLE COLORS

Three

Pro-Ject Juke Box E1 Record Player w/ Receiver

EFFECTIVE TONEARM MASS

7.0 g

HANDMADE IN EUROPE

The stylish CNC-machined composite fiber plinth is carefully manufactured to ensure there are no resonant hollow spaces inside. The lightweight and low friction 8.6″ aluminum tonearm is optimized for the high-quality Ortofon OM 5E cartridge and will allow it to perform its very best. The new ABS polymer main platter is strengthened with purpose-designed ridges in order to create an ideal, anti-resonant platform for your vinyl. To protect your Juke Box E1 from dust, we also include an elegant acrylic dust cover with adjustable hinges.

COLORS

Pro-Ject Juke Box E1 Record Player w/ Receiver
Piano-Black
Pro-Ject Juke Box E1 Record Player w/ Receiver
Gloss Red
Pro-Ject Juke Box E1 Record Player w/ Receiver
Gloss White

JUST ADD SPEAKERS

With its range of analog and digital inputs, Juke Box E1 is one of the most versatile offerings on the market. A turntable, a preamplifier, a power amplifier and a BT receiver are at the ready for you. The line output even lets you relay the signal to a 2nd amplifier allowing playback through a headphone amp or a 2nd system entirely. The built-in high-contrast display shows you volume and the selected input. The 32-step digital potentiometer helps you achieve the desired volume. Pressing the volume knob also changes the input. For further convenience, an infrared remote control is included!
