Jvc CS-DR421 Speakers
CS-DF6920 SPEAKERS
CS-DF6920 SPEAKERS
Drvn DR Series Speakers
10cm (4”) 2-Way Coaxial Speakers / 220W Max Power
INFORMATION
BRAND
Jvc
PRODUCT TYPE
Speaker
PRODUCTION
Made in Japan
MAGNET
- Woofer : Ferrite
- Tweeter : Neodimium
DIAPHRAGM
- Woofer : Carbon Mica Cone
- Tweeter : Poly-Ether Imide
COLLECTION
CS
COLOR
Black
SIZE
10 cm (4'')
SURROUND
Hybrid Surround (Rubber & Cloth)
TWEETER TYPE
Balanced
TWEETER SIZE
2.5 cm (1'')
POWER HANDLING CAPACITY
- Peak power : 220W
- RMS power : 35W
IMPEDANCE
4 ohms
MOUNTING DEPTH
45.5 mm (1-13/16")
SOUND PRESSURE LEVEL
88dB
WEIGHT
- With Grille : 0.40kg (0.89lbs)
- Without Grille : 0.36kg (0.80lbs)
MAGNET MASS
127g (4.5oz)
FREQUENCY RESPONSE
114 - 23.000Hz
CARBON MICA CONE
Robust and lightweight carbon mica material provides highly responsive, clear and undistorted reproduction.
SMALL DESIGN TWEETER COVER
Newly developed small cover significantly reduces areas that interfere with the woofer cone. High-quality sound is assured.
HYBRID SURROUND
Rubber Coated Cloth with increased mobility enables high efficiency and improved follow-up to audio signals.
DETAIL
HIGH OUTPUT
Combines high output sound and toughness to withstand the powerful drive. Easily upgrades from factory-installed original speakers.
BALANCED NEODYMIM TWEETER
It provides detailed high range and smooth mid range.
GREAT FACTORY REPLACEMENT
Installable vehicle types are greatly increased thanks to its shorter height.
WIDE OPENING GRILL
Grill’s opening ratio is 30% wider than the conventional model, enabling increased durability and clear sound.
