Jvc CS-DR162 Speakers
CS-DR162 SPEAKERS
CS-DR162 SPEAKERS
Drvn DR Series Speakers
16cm (6-1/2") 2-Way Coaxial Speakers
INFORMATION
BRAND
Jvc
PRODUCT TYPE
Speaker
PRODUCTION
Made in Japan
MAGNET
- Woofer : Ferrite
- Midrange : Neodymium
DIAPHRAGM
- Woofer : PP
- Midrange : Balanced Dome
COLLECTION
CS
COLOR
Black
TECHNICAL DRAWING
SIZE
- Woofer : 16 cm (6-1/2")
- Midrange : 2.5 cm (1")
SURROUND
Cloth
USE
Entertainmnet
POWER HANDLING CAPACITY
- Peak power : 300W
- RMS power : 50W
IMPEDANCE
4 ohms
MOUNTING DEPTH
44 mm (1-3/4")
SOUND PRESSURE LEVEL
88 dB
WEIGHT
- With Grille : 0.64kg (1.4lbs)
- Without Grille : 0.57kg (1.3lbs)
MAGNET MASS
220g (7.8oz)
FREQUENCY RESPONSE
88 - 22.000Hz
HIGH OUPUT & TOUGH
The DR Speaker are designed for JVC head-unit to produce superior directivity, dynamic sound which we call "drvn sound".
HORN RING SOUND ENHANCER
Improves mid - higher frequency sound character and reproduces life-like sound.
PP+MICA CONE
Lightweight PP + Mica Cone Material provides highly responsive, clear and undistorted sound.
FULL COVER GRILL DESIGN
Protects the woofer and tweeter in open installations.
