Ref. HDH

The Harmonia reversible air conditioner features a built-in ionizer and several filters to ensure exceptional air quality all year round. The ionizer gives you a feeling of well-being by producing negative ions in the air, while the filter system retains harmful particles.

FEATURES

REFRIGERANT R32

Harmonia uses R32 refrigerant, a more efficient and environmentally friendly fluid. With Harmonia, you make a sustainable, energy-efficient choice.

Airwell Harmonia Air Conditioner

4D AIRFLOW TECHNOLOGY

Optimum 4D airflow technology distributes air evenly throughout the room. Whatever the configuration of your room, the air circulates in every nook and cranny for an evenly distributed temperature throughout your interior.

Airwell Harmonia Air Conditioner

REMOTE CONTROL

Thanks to its Wi-Fi connectivity, you can control your home’s temperature wherever you are. Using the AirHome smartphone app, you can control the thermostat remotely to set the perfect temperature as soon as you arrive, or turn it off if you’re away.

Airwell Harmonia Air Conditioner

ULTRA-QUIET FUNCTION

The Harmonia air conditioner offers unrivalled performance while operating at no more than 20 decibels. Just imagine! You won’t even notice that the air conditioner is on.

Airwell Harmonia Air Conditioner

STREAMLINED DESIGN AND COMPACT

The Harmonia air conditioner boasts a resolutely modern design in reduced dimensions to remain discreet in your home. It blends soberly into any room in your home. 3 appliance sizes according to power (see technical specifications).

Airwell Harmonia Air Conditioner

INTEGRATED IONIZER FOR GREATER WELL-BEING

Ionization improves air quality beyond compare, by generating negative ions. Negative ions have a positive influence on our emotional and physiological state. They can be found in large numbers in certain natural areas.

Thanks to its built-in ionizer, Harmonia reproduces these beneficial conditions inside your home.

Airwell Harmonia Air Conditioner

AIR FILTRATION

Did you know that the air in your home is more polluted than the air outside ?

For healthy air, Harmonia features several layers of filters: a pre-filter to trap pollen, hair and fur; a catalytic and activated carbon filter to absorb and destroy noxious gases and unpleasant odors; and a Silver Ion filter that destroys bacteria, viruses and spores.

Airwell Harmonia Air Conditioner

INFORMATION

BAND

Airwell

PRODUCT TYPE

Air Conditioner

COOLING

- Refrigerator/PRP : R32/675
- SEER/Energy class : 9.3/A+++
- Rated power (min./max.) : 2.64 (1.02-3.22) kW

HEATING

- Rated power (min./max.) : 2.92 (0.82-3.37) kW
- SCOP/Energy class (temperate climate) : 4.6/A++

TECHNICAL DRAWING

Airwell Harmonia Air Conditioner

USE

- Heating
- Cooling

FUNCTION

4D Airflow Function

ENVIRONMENT

Indoor & Outdoor

TECHNOLOGIES

- Design and compact
- Integrated air ioniser

REF. INDOOR UNIT

HDMB-025-09M22

REF. OUTDOOR UNIT

YDAB-025H-09M22

INDOOR UNIT

- Net weight : 8.6 kg
- Acoustic power : 55 dB (A)
- Unit dimensions (WxHxD) : 802x297x189 mm
- Sound pressure at 1 m (TPV/PV/MV/GV) : 20/24/29/36,5 dB (A)

POWER SUPPLY

-Phase : Single-phase
-Phase/Voltage/Frequency : 1P/220-240V/50Hz

OUTDOOR UNIT

- Net weight : 27.2 kg
- Acoustic power : 59 dB (A)
- Sound pressure at 1 m : 55 dB (A)
- Unit dimensions (WxHxD) : 770x555x300 mm

AVAILABLE IN 6COLORIS ELEGANT

Harmonia is available in 6 colors for perfect integration into any interior décor. 3 integral colors: glacier white, mirage gray and mirror, plus 3 fronts: silver gray, champagne beige and passion red.
