Bang Olufsen Beosound Stage Soundbar
BEOSOUND STAGE SOUNDBAR
BEOSOUND STAGE SOUNDBAR
Powerful Dolby Atmos soundbar
Powerful soundbar that brings Bang & Olufsen sound to your own TV without the need of a subwoofer.
FEATURES
POWERFUL SURROUND SOUND
Take the TV experience to a different level with Beosound Stage, a beautifully crafted soundbar that sounds as good as it looks. Beosound Stage enhances viewing pleasure with a combination of the latest in audio technology and seamless design – as well as being powerful enough to avoid the need for a separate subwoofer.
CRAFTED SOUND. SEAMLESS CONTINUITY.
With our first soundbar, we give everyone a chance to experience Bang & Olufsen sound in their own living room as Beosound Stage works with any TV supporting HDMI ARC. With four woofers in the eleven-driver setup, no additional subwoofer is needed.
MULTIPURPOSE. MULTIROOM.
Beosound Stage works as a home speaker system in its own right when you turn the TV off. The integrated audio streaming technologies Chromecast built-in, Apple AirPlay and Bluetooth streaming give Beosound Stage full multiroom functionality for beautiful music in every room of your home.
SCANDINAVIAN SIMPLICITY
The control buttons integrate seamlessly, a visual continuation of the infinite frame. A deliberate gap between the frame and the fabric cover highlights the contrast from the aluminium to the warm fabric. Beosound Stage brings expressive minimalism to any interior – while maximizing the TV experience.
INFORMATION
BRAND
Bang Olufsen
PRODUCT TYPE
Subwoofer
RECOMMENDED ROOM SIZE
- 10 - 50 m²
- 100-600 ft²
WI-FI
Wi-fi/WLAN 802.11 b/g/n/ac (2.4 GHz & 5 GHz)
DIMENSIONS
- Height : 17 cm
- Width : 110 cm
- Depth : 7.7 cm
SPEAKER CONFIGURATION
- 3 x ¾" Tweeter
- 4 x 4" Woofer
- 4 x 1 ½" Full-range
AMPLIFIER
- 3 x 50 W Class D for Tweeter
- 4 x 50 W Cass D for Woofer
- 4 x 50 W Class D for Full-range
DESIGNER
Norm Architects
WEIGHT
8 kg
STREAMING SERVICES
- Airplay 2
- Chromecast Built-in
- BeoLink Multiroom
- Spotify Connect
VOLTAGE
100-240 V
FREQUENCY
32 - 22.000 Hz
ADVANCED SOUND FEATURES
- Dolby Atmos
- Dolby TrueHD
- Thermal Protection
- Acoustic Placement Settings
- Adaptive Bass Linearization
INPUTS AND OUTPUTS
- 2x Ethernet 10/100Mb
- 1x Line-in 3.5 mm stereo mini-jack
- HDMI (HDMI 2.0, HDCP 2.2) with EARC and ARC support
- HDMI in (HDMI 2.0, HDCP 2.2 with support of 4K HDR 50/60hz)
- Vlan connection with lg c9 series tv for integrated control via beoremote one
SOUND PRESSURE LEVEL @1M
Maximum 100 dB SPL
POWER CONSUMPTION
Typical 80 watts
POWER CABLE
50/60Hz Power cable
INTEGRATED MUSIC SERVICES
Tunein Internet Radio
TECHNICAL DRAWING
11 Speaker Drivers
CUSTOMIZABLE SOUND EQ
Presets available and fully customisable through the Bang & Olufsen App
AVAILABLE COLORS
Four
DOWNLOAD
↓ Data Sheet
SPEAKERS TYPE
-11 power amplifiers -4 x 50 watts amplifiers for the bass drivers -4 x 50 watts for the full-range drivers -3 x 50 watts for the tweeters
PLACEMENT
Wall or table/shelf
USE
Entertainment
DRIVERS
- 4 4" woofer drivers
- 4 1.5" mid-range drivers
- 3 3/4" tweeter drivers
INCLUDED IN THE BOX
-HDMI cable & Mains cable -Beosound Stage including fabric front cover -2 pcs of collar/holders for wall mount solution -2 pcs of felt for adjusting flush mount on wall -Drilling template for wall mounting -2 pcs of cable holders/bridges -Tool for removing fabric cover
BASS CAPABILITY
86 dB SPL
FRAME
- Aluminium & Smoked Oak
MATERIAL
-Front Covers : Black fabric or grey/warm taupe fabric by kvadrat
-Frame : Natural aluminium, bronze tone aluminium, smoked oak wood
DESIGN
Exclusive and functional materials combine Scandinavian simplicity with state of the art audio technology. An endless frame of long line standing aluminium or smoked oak surrounds the textile of the speaker front.
REMOTE CONTROLS
-Bang & Olufsen App -Beoremote One BT with LG OLED C9 TVs -TV remote (volume-mute-on-standby)control commands via HDMI ARC
COLORS
ALL COLORS
-Natural -Gold Tone -Black Anthracite -Smoked Oak
DETAIL
FIND YOUR OWN MOOD
Through the Bang & Olufsen App, once you register the product, you can choose among different "listening modes" according to what you are listening or watching on tv. Hear every voice, action or music clearly.
DOLBY ATMOS SOUND
Beosound Stage offers a 3 channel sound system with a superior centre channel for optimized speech reproduction. The viewing experience is enhanced even further with Dolby Atmos, a function where sound moves around you in a three dimensional space. Beosound Stage includes eleven speaker drivers each driven by its own amplifier and the result is a three-channel, fully active, DSP based loudspeaker solution delivering a superbly deep and rich performance.
EASY TO SETUP
The basic TV sound setup of Beosound Stage only requires you to connect the included HDMI cable between Beosound Stage and the HDMI ARC connection of your TV. Then, select correct speaker/sound output in your TV menu.
