Cabasse Santorin 38 Subwoofer – Exception Low Frequencies
SANTORIN 38 SUBWOOFER – EXCEPTION LOW FREQUENCIES
SANTORIN 38 SUBWOOFER – EXCEPTION LOW FREQUENCIES
Fitted with the 38cm honeycomb dome woofer from the flagship L’Océan, the Santorin 38 subwoofer takes low frequency reproduction to new levels. The bandwidth is smooth and flat to below 17Hz and the dynamic performance is impressive in its ease at all amplitudes. The set up module measurements are always precise and its acoustic correction improves transparency throughout the entire spectrum. The Santorin 38 brings serious low frequency performance to your music.
INFORMATION
DOWNLOADS
↓ Download Owner’s Manual
↓ Data Sheet
BRAND
Cabasse
PRODUCT TYPE
Speaker
PRODUCTION
Made in France
COLLECTION
Santorin
ADAPTS TO YOUR ROOM
The Cabasse software for acoustical analysis and room correction is integrated in the 500W amplifier. The system comes with a measuring microphone ensuring an automatic adaptation of the subwoofer’s response. Three different manual or automatic set ups can be memorized and then selected with the remote control.
PHASE ADJUSTMENT
0° to 180° in 1° increments
FREQUENCY RESPONSE
17 – 170 Hz (anechoic chamber)
LOW PASS FILTER ADJUSTMENT
From 30 To 200 Hz In 1 Hz Increments
DELAY ADJUSTMENT
In One Foot Increments
WEIGHT
53 kg
WAYS
1
DIMENSIONS
- Height : 51 cm
- Width : 62 cm
- Length : 59 cm
MAX SPL LEVEL
112 dB
NOMINAL POWER
500 W
SPEAKERS
1 x 38 cm 38ND46, honeycomb dome diaphragm
PEAK POWER
1 000 W
USE
Floorstanding subwoofer
38CM HONEYCOMB MEMBRANE
The 360° vertically down-firing 38 cm (15’’) honeycomb woofer of the Santorin 38 allows for an exceptionally smooth bandwidth in your listening room, often even wider than that measured in Cabasse’s anechoic chamber. The 38ND46 was specifically designed for use in a closed box without a bass reflex vent and the resulting acoustic experience is free of any vibration or coloration, even at the lowest frequencies.
