Robust and highly capable primary 4K camera with maximum image quality and flexibility

FEATURES

OUTSTANDING IMAGE QUALITY

The C700 supports various Log curves, colour spaces and industry standards, maximising the image quality.

Canon Canon EOS C700 Camera

4.5K CMOS SENSOR

Canon’s Super 35mm sensor records outstanding 4K footage internally with 15-stops of dynamic range or full 4.5K RAW to the optional CODEX CDX-36150 recorder.

Canon Canon EOS C700 Camera

MULTIPLE RECORDING FORMATS WITH HIGH FRAME RATES

Record high frame rate RAW files with an optional CODEX CDX-36150 recorder, or record internally to ProRes or XF-AVC formats for a faster workflow.

Canon Canon EOS C700 Camera

MULTIPLE CONFIGURATIONS

New Cinema EOS design that features intuitive controls and built-in cheese plate for attachment of optional professional accessories, allowing multiple configurations to suit the required shoot.

Canon Canon EOS C700 Camera
Canon Canon EOS C700 Camera

ACCURATE AND RELIABLE AUTOFOCUS

Canon’s Dual Pixel CMOS AF system allows users to reliably and easily maintain sharp focus on subjects as they move throughout the frame, and includes a function to aid manual focusing.

Canon Canon EOS C700 Camera

OPERATIONAL FEATURES

Built-in ND filters, IP streaming capability and optional accessories for camera control allow for flexible camera operation.

Canon Canon EOS C700 Camera

GLOBAL SHUTTER MODEL AVAILABLE

Canon’s 4.2K Global Shutter sensor model records 4K/50P with no rolling shutter effect and up to 14-stops of dynamic range, making it ideal for shooting sports and events.

INFORMATION

BRAND

Canon

PRODUCT TYPE

Camera

LENS MOUNT

- B4 mount lens via adapter accessory (EF orPL)
- Canon EF Mount with Cinema Lock/ PL Mount (Cooke/i Technology compatible) depending on version

TOTAL PIXELS PER SENSOR

Approx. 11.54 megapixels (4622 x 2496)

EFFECTIVE PIXELS PER SENSOR

- 4096 x 2160/2048 x 1080: Approx. 8.85 Mp
- 3840 x 2160/1920 x 1080:Approx 8.29 Mp

DYNAMIC RANGE

- Canon Log 2/Canon Log 3: 1600% (ISO 800 or higher)
- With Canon Log/Wide DR: 800% (ISO 400 or higher)

SENSOR

Super 35mm type CMOS

IMAGE PROCESSOR TYPE

Triple DIGIC DV 5

Canon Canon EOS C700 Camera

LUXURY YACHT ADVERT FILMED ON THE EOS C700.

Check out this C700-shot advert for luxury river yacht company Woods’ Silver Fleet.

WHITE BALANCE SHIFT

YES. -9 to +9 (Daylight and Tungsten only)

15-STOPS DYNAMIC RANGE

Log 2 enables maximum dynamic range

ND FILTER

Up to 10 stops via built in ND filter system

SYSTEM

RGB primary colour filter (Beyer array)

USE

Photography

COOKE/I TECHNOLOGY SUPPORT

Yes (PL Mount only)

LENS MAGNIFICATION FACTOR (FOR EF MOUNT LENSES, INCLUDING CINEMA PRIMES)

- 4096 x 2160 or 2048 x 1080: focal length x approx. 1.460
- 3840 x 2160 or 1920 x 1080: focal length x approx. 1.534
- PL Mount version: No magnification factor for Canon Cinema Zooms
- B4 adapter attached: focal length x approx 1.3 (1.2947) (Full HD/1920 x 1080)

Canon Canon EOS C700 Camera

FOCUS CONTROL

-P
L Mount : Only Cine Servo lenses
-EF Mount :Via lens, wireless control or wired remote (dependent on lens used)

CHANGEABLE LENS MOUNT

Yes, via Service Centre. Ef to PL or PL to EF options.

PERIPHERAL ILLUMINATION CORRECTION

YES (dependent on lens used)

ANAMORPHIC LENS SUPPORT

Yes

IMAGE STABILIZATION SYSTEM

Depends on lens used

MISCELLANEOUS

Operating Temperature range

- Approx. 0°C to 40°C, 85% (relative humidity)
- Approx. -5°C to 45°C, 60% (relative humidity)

RECORDING

RELAY RECORDING

Yes

SCAN REVERSE

Yes

HD->SD CONVERSION

No

PRE RECORD (CACHE RECORD)

No

INTERVAL RECORD

No

FRAME RECORD

No

RAW RECORDING OPTIONS

-C
apture Drive, CDX-36150: 4096 x 2160, 12bit/10bit, Canon Log 2 applied 4.5K up to 100fps, 4.5K cinescope up to 120FPS, Crop 2K max 240 fps ProRes 422HQ, 4K /QFHD 10bit. 2K / FHD: ProRes 422 HQ 10 bit 120 fps, ProRes 4444 XQ 12 bit 60 fps, ProRes 4444 12 bit 60 fps -External device via 3G-SDI: 4096 x 2160, 12bit/10bit, Canon Log 2 applied

PHOTO RECORDING SIZE

Approx. 930 KB at 2048x1080; Approx 880 KB at 1920x1080

RECORDING FRAME RATE

4K RAW: up to 60P (up to 120P to CDX-361502). Max 240P (2K Cropped)

XF-AVC PROXY RECORDING BIT RATE/ SAMPLING (50HZ MODE) TO SD CARD

- Bit Rate: 24/35Mbps Long GOP
- 2048x1080 YCC420 8 bit/1920x1080 YCC420 8 bit

PHOTO STORAGE MEDIA

SD/SDHC memory card

SLOW/FAST MOTION

Yes. 1 - 240 FPS depending on setting

XF-AVC RECORDING BIT RATE/ SAMPLING (50HZ MODE) TO CFAST 2.0™ CARD

-4
096x2160/3840x2160: YCC422 10 bit, 2048x1080/1920x1080: RGB444 12 bit RGB444 10 bit , YCC422 10 bit , 1920x1080: YCC422 10 bit 50Mbps Long GOP -4096 x2160/3840x2160: YCC422 10 bit 2048 x1080/1920x1080: RGB444 12 bit, RGB444 10 bit , YCC422 10 bit -Bit rates (dependnding on recording mode) : 810/440/410/310/225/210/170/160/ 90Mbps Intra-frame 50 Mbps Long GOP

RECORDING FORMATS

Canon RAW .RMF, XF-AVC Intra, XF-AVC Long GOP. XF-AVC Proxy ProRes, Apple Quick File Format 4444XQ/4444/422HQ/422

INTERNAL RECORDING

Cfast 2.0™ card x 2 for xf-avc or pro res recording, sd card for xf-avc proxy recording sd card also used for photo storage (1920 x 1080) and firmware update, including firmware updates for codex cdx-36150

RECORDING TIME (64GB CFAST 2.0™CARD)

-X
F-AVC Long GOP 50Mbps : 165 Mins -XF-AVC - Intra : 810 Mbps, 10 Mins 160 Mbps, 50 Mins. -ProRes : 4K,ProRes422HQ 10Mins. 2K ProRes4444 25 Mins (25.00P)

PRORES RECORDING BIT RATE/ SAMPLING (50HZ MODE)

-B
it rates : ProRes4444/ ProRes422HQ /ProRes422
-Codex cdx-36150 : 4k/qfhd: prores 422 hq 10 bit 60 fps 2k/fhd: prores 422 hq 10 bit 120 fps, prores 4444 xq 12 bit 60 fps, prores 4444 12 bit 60 fps,crop 2k/fhd: prores 422 hq 10 bit 240 fps
-CFast 2.0™ Card : 4096x2160 YCC422 10bit/3840x2160 YCC422 10bit, 2048x1080 YCC422 10bit/1920x1080 YCC422 10bit, 2048x1080 RGB444 12bit/1920x1080 RGB444 12bit

SYSTEM

COLOUR BARS

SMPTE, EBU and ARIB color bars available. See the menu.

USB

No

COMPONENT OUT

No

PEAKING

Peaking 1, Peaking 2 (Colour, Gain, Frequency customisable)

AV TERMINAL

No

SDI OUTPUT

BNC jack (4 lines, output only)

WAVE FORM MONITOR

- Line Display/Line and Spot/Line Select/Field Display/RGBDisplay/YPrPb
- Yes. Via MON.1/2, VIDEO or HDMI Terminals (Not available from SDI Out 1 -4)

ZEBRA

- Level 1; Level 2; Both
- Output via HD-SDI or HDMI

FALSE COLOUR DISPLAY (EXPOSURE INDICATION)

Yes. Via MON.1/2, VIDEO or HDMI Terminals (Not available from SDI Out 1 -4)

MARKERS

On/Off (Aspect ratio, Aspect marker, Safety Zone Area, Safety Zone, Grid, Horizontal, Centre)

TIME CODE

BNC jack (input/output)

HDMI

HDMI connector (type A) (output only)

GENLOCK

BNC jack (input only/also serves as SYNC OUT connector)

SYNCH

BNC jack (output only/also serves as GENLOCK connector)

CONTROL DISPLAY

3.0-inch (7.66cm on the diagonal) colour liquid crystal, approx. 1.036 million dots

EVF

- Built- In EVF : No
- Optional EVF Accessory : Yes. OLED Electronic ViewFinder, EVF-V70

OUTPUT

- Headphone output : 3.5 mm stereo mini jack (output only)
- Video monitor output : MON.1/MON.2: BNC jack , output only

DC INPUT

XLR 4-pin jack

WIRELESS CONTROL TERMINAL

Yes, for WFT-E6B.WFT-E8

MISC

- Tally lamp : Yes
- Custom Dial : Yes

CTRL TERMINAL

Canon’s proprietary specifications, LEMO 7-pin jack

VIDEO CONNECTOR (FOR EVF)

Canon’s proprietary specifications (special 13-pin jack, output only)

ETHERNET TERMINAL

Ethernet connector (RJ45) (supports 1000 BASE-T)

AUDIO IN

XLR 3-pin connector x2 , 3.5 mm stereo mini jack (input only)

REMOTE CONTROL TERMINAL

- Remote B connector round 8-pin jack (for rs-422)
- Remote A connector 2.5 mm stereo mini-mini jack (input only)

SHOOTING FUNCTIONS

EXPOSURE LOCK

No

AUTO GAIN CONTROL SETTING

Yes

AUTO FOCUS SYSTEM (EF VERSION ONLY)

- Contrast AF
- Dual Pixel CMOS AF

FACE DETECTION AF (EF VERSION ONLY)

Face Priority or Face Only.

STORAGE MEDIUM

SD/SDHC memory card (all customisation data and metadata), up to 20 Custom Pictures per card

MASTER PEDESTAL

-50 to +50

NOISE REDUCTION

Off, On (1 to 12)

CLIP 100% IRE

Limits output to 100% after setup adjustment

LOW KEY SATURATION

-50 to +50 adjusts colour level in low brightness area

KNEE

Adjusts over exposure characteristic, start, slope, saturation

AUTO

Yes

SETUP LEVEL

-50 to +50 On/Off

EXPOSURE COMPENSATION

Yes

AUTO EXPOSURE MODE

Auto Iris

ISO SENSITIVITY

-1
-Stop Display : [100], 160(*), 200, 400, 800, 1600, 3200, 6400, 12800, 25600, [51200,102400] -[---] Displayed when ISO speed expansion is ON. -(*) Displayed when ISO speed expansion is OFF -1/3 Stop Display: [100,125], 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000, 25600, [32000,40000,51200,64000, 80000,102400], [---] When ISO speed expansion is ON.

FOCUS GUIDE

-P
L Version : Compatible Canon Cine Servo lenses
-EF version: All compatible Canon EF lenses, Canon Cine Servo Lenses

PUSH AUTO IRIS

Yes EF model all compatible lenses, PL Version compatible Canon Cine Servo lenses only

EXPOSURE METERING

Manual exposure determined by shutter setting, iris setting, ISO/gain setting and ND filter setting, Push Auto Iris, Auto Iris

MASTER BLACK

-50 to +50 for each channel , R,G,B

BLACK GAMMA

Adjustable Level, Range and Point

AUTO FOCUS MODES (EF VERSION ONLY)

One-Shot AF, Continuous AF and AF-Boosted MF are the available modes. All of these modes take effect when the AF/MF switch of the EF lens is at the AF setting.

- One-Shot AF
- Continuous AF
- AF-Boosted MF

TIME CODE

-S
tart value setting : “00:00:00:00”, Set/Reset selectable
-Count up system : Regen, RecRun, FreeRun, External, Hold (Drop frame available for some frame rates)

COLOUR MATRIX

Phase, Gain and RGB adjustment, in tandem with Gamma selection

GPS INFORMATION (OPTIONAL ACCESSORY)

Latitude/Longitude/Elevation, Coordinated Universal Time (UTC)

WHITE BALANCE

-50 to +50 for R and B colours

COLOUR CORRECTION

Area selection / area revision of two areas

SELECTIVE NOISE REDUCTION

- Off
- Low
- Area
- Middle
- High / Hue
- Chroma
- Luminance.

SKIN DETAIL

- Off
- Low
- Area
- Middle
- Chroma
- High / Hue
- Luminance. 32 steps

SHARPNESS

- Coring
- Limit
- Select
- H Detail Freq.
- HV Detail Balance
- Adjustment for Level
- Knee Aperture and Level dependent sharpness

GAIN SETTING

[-6dB,-3dB], -2dB(*), 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 27dB, 30dB, 33dB, 36dB, 39dB, 42dB, [45dB,48dB,51dB,54dB] [---] Displayed when ISO speed expansion is ON. (*) Displayed when ISO speed expansion is OFF. -When ISO speed expansion is ON: between -2 dB and 54 dB -When ISO speed expansion is OFF: Any value from -2 dB to 42 dB in 0.5 dB increments can be set.

AF FRAME SIZES (EF VERSION ONLY)

-S
electable AF point over 80% (approx.) of sensor -Large; size equivalent to approx. 20% (vertical) x 25% (horizontal) of the image display range -Small; size equivalent to approx. 20% (vertical) x 8% (horizontal) of the image display range

SHUTTER SPEED

- Shutter Angle : 11.25º to 360º depending on frame rate
- Control Modes : Off; Speed; Angle; Clear Scan (CS); Slow Shutter (SLS)
- Slow Shutter (SLS) : 1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/25, 1/30 depending on frame rate
- Shutter speed : 1/1 to 1/2000 depending on frame rate and Shutter Control Mode, 39 setting options
- Clear Scan : 24.00 Hz* to 250.40 Hz, (*) The frequency will differ depending on the frame rate setting.

STORED CONFIGURATIONS (PRESET)

- BT.709 (Wide DR/ BT.709 Gamut/Neutral)
- BT.2020 (Wide DR/BT.2020 Gamut/Neutral)
- Canon Log (Canon Log / BT.709 Gamut/Cinema EOS Original)
- Main Settings Canon Log 3,Canon Log 2, Canon Log, Wide DR, Normal 1(Standard), Normal 2 (x4.0),Normal 3 (BT.709), Normal 4 (x5.0)

- Canon Log 3 : C.Gamut (Canon Log 3/ Cinema Gamut/Neutral)
- Canon Log 3 : BT.2020 (Canon Log 3/ BT.2020 Gamut/Neutral)
- Canon Log 3 : DCI-P3 (Canon Log 3/ DCI-P3 Gamut/Neutral)
- Canon Log 3 : BT.709 (Canon Log 3/ BT.709 Gamut/Neutral)
- Canon Log 2 : C.Gamut (Canon Log 2/ Cinema Gamut/Neutral)
- Canon Log 2 : BT.2020 (Canon Log 2/ BT.2020 Gamut/Neutral)
- Canon Log 2 : DCI-P3 (Canon Log 2/ DCI-P3 Gamut/Neutral)
- Canon Log 2 : BT.709 (Canon Log 2/ BT.709 Gamut/Neutral)
- Colour Space : BT.709 Gamut, BT.2020 Gamut, DCI-P3 Gamut,Cinema Gamut
- Colour Matrix : Neutral, Production Camera, Cinema EOS Original, Video, Off
