It's never been easier to shoot and share creative, professional-looking photos. The EOS M200 is a smart, connected, lightweight camera that will unlock your creativity and take your photography further.

INFORMATION

BRAND

Canon

PRODUCT TYPE

Camera

BODY MATERIALS

Polycarbonate

OPERATING ENVIRONMENT

0 – 40 °C, 85% or Less Humidity

24.1 MEGAPIXEL

APS-C Sized Sensor

TIME-LAPSE MOVIES

Record Movement On A Different Timescale

4K VIDEO

With 120fps HD

180-DEGREE

Tilt-out Touchscreen

CREATIVE ASSIST

Makes professional-looking photos easy

TIME-LAPSE MOVIES

Record movement on a different timescale

SENSOR CLEANING

Eos Integrated Cleaning System

Canon Canon EOS M200 Cameras

TYPE

22.3 x 14.9mm CMOS

TOTAL PIXELS

Approx 25.8 Megapixels

ASPECT RATIO

3:2

EFFECTIVE PIXELS

Approx. 24.1 megapixels

IMAGE STABILISATION

- Optical Image Stabilizer on compatible lens
- Movie: In-camera Digital IS available. Further stabilisation enhancements from lenses compatible with Dynamic IS

LOW-PASS FILTER

Built-in/Fixed

COLOUR FILTER TYPE

Primary Colour

Canon Canon EOS M200 Cameras

IMAGE PROCESSOR TYPE

DIGIC 8

AF ASSIST BEAM

Via LED Assist Beam

AF POINT SELECTION

- Zone AF
- Spot AF
- 1-point AF
- Face + Tracking (Eye Detection AF available)

LENS MOUNT

EF-M (EF and EF-S lenses compatible via Mount adapter EF-EOS M)

FOCAL LENGTH

Equivalent to 1.6x the focal length of the lens

AF MODES

One-Shot AF and Servo AF

SELECTED AF POINT DISPLAY

Indicated on LCD monitor

TYPE

-Dual Pixel CMOS AF System. Phase detection pixels built onto imaging sensor2  -Contrast detection method is used during 4K Movie and 4K Timelapse Movie

AF WORKING RANGE

EV -4 - 18 (room temperature, f/1.4, ISO 100, One-Shot AF), Movie: EV -2 - 18 (room temperature, f/1.4, ISO 100, One-Shot AF, 29.97fps/25fps)

AF SYSTEM / POINTS

-Max 25 frames in Zone AF3
-Maximum 143 points depending on lens. -Freely position 1 AF point/ 1 AF Zone via manual selection (area available lens dependent)

MANUAL FOCUS

- MF Peaking available
- With EF-M lenses - Select via menu
- Magnify image available during MF (5x or 1 0x)
- With EF & EF-S lenses - Select via AF/MF switch on lens
- AF+MF available (Manual focus adjustment after One-Shot AF)

Canon Canon EOS M200 Cameras

EXPOSURE COMPENSATION

+/-3 EV in 1/3 stop increments

AF LOCK

Locked when shutter button is pressed half way or AE Lock Button

METERING RANGE

-Movie: EV 0 - 20 (at 23 °C, ISO 100) -Still image: EV -1 - 20 (at 23 °C, ISO 100)

AF WORKING RANGE

EV -4 - 18 (room temperature, f/1.4, ISO 100, One-Shot AF), Movie: EV -2 - 18 (room temperature, f/1.4, ISO 100, One-Shot AF, 29.97fps/25fps)

BUILT-IN FLASH COVERAGE

Maximum coverage at approx. 15mm (35mm equivalent: approx. 24mm)

BUILT-IN FLASH GN

5

MODES

Auto (E-TTL II)

BUILT-IN FLASH RECYCLE TIME

Approx. 4 seconds4

RED-EYE REDUCTION

Provided

X-SYNC

1/200 sec

FLASH EXPOSURE LOCK

Yes

Canon Canon EOS M200 Cameras

FLASH EXPOSURE COMPENSATION

+/- 2 EV in 1/3 Increments

COVERAGE

Approx. 100% (horizontally and vertically)

SECOND CURTAIN SYNCHRONISATION

Yes

HOTSHOE / PC TERMINAL

No/No

EXTERNAL FLASH COMPATIBILITY

None

PICTBRIDGE

Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

PC & MACINTOSH

For individual software see service and support sections

CANON PRINTERS

Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

METERING MODES

Real-time metering from the image sensor

- Evaluative metering (384 zones)
- Center weighted average metering
- Spot metering (approx. 2.9% of Live View Screen)
- Partial metering at center (approx. 5.8% of Live View Screen)

ISO SENSITIVITY

-100 - 25600 in 1/3 stop increments. Max in Auto can be set from 400 - 25600 -4K Movie: 100 - 6400 in 1/3-stop increments. Full HD and HD Movie: ISO 100 -12800 in 1/3-stop increments. ISO can be expanded to 25600

COMPUTER

Hi-Speed USB (Micro USB)

DIRECT PRINT TYPE

SD, SDHC, SDXC (UHS-I compatible)

OTHER

-HDMI (Micro - Type-D connector) -Wireless LAN (IEEE802.11b/g/n), (2.4 GHz only, 1-11 ch),7 -Bluetooth® (Specification version 4.1, Bluetooth low energy technology)8 9

Canon Canon EOS M200 Cameras

BATTERY LIFE

-Eco Mode: Approx. 485 shots -Movie Recording: Approx. 90 mins -Approx. 315 shots (conforms to CIPA)11 -Playback time when playing back a slideshow of still images: Approx. 4 hrs 55mins

IMAGE PROCESSING

Digital Photo Professional, DPP Express for iPad

BATTERIES

1 x Rechargeable Li-ion Battery LP-E12

OTHER

Picture Style Editor, EOS Utility, Image Transfer Utility 2 Camera Connect app available on iOS and Android devices8

POWER SUPPLY & BATTERY CHARGERS

- Battery charger LC-E12
- Compact Power Adapter CA-PS700 DC Coupler DR-E12

POWER SAVING

-ECO mode -Display off (15, 30 sec or 1, 3, 5, 10, 30 mins) -Auto Power Down (30 sec or 1, 3, 5, 10 mins, Disable)

Canon Canon EOS M200 Cameras

LENSES

-EF-M lenses -All EF and EF-S lenses compatible via Mount adapter EF-EOS M

OTHER

- Interface Cable IFC-600PCU
- Mount Adapter EF-EOSM

shutter AND SHOOTING FUNCTIONS

COVERAGE

Approx 100%

CUSTOM WHITE BALANCE

Yes, 1 Setting

SPEED

30 - 1/4000 sec (1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

BRIGHTNESS ADJUSTMENT

Adjustable To One Of Seven Levels

TYPE

-Vertical-travel mechanical focal-plane shutter, electronically controlled at all speeds -Auto white balance with the imaging sensor -7.5 cm (3.0”) Touchscreen LCD (TFT). 3:2 aspect ratio. Approx. 1,040,000 dots. Electrostatic capacitive type. Tilting approx 180° upward

INTERVAL RECORD

No

FRAME RECORD

No

IMAGE PROCESSING

-Highlight Tone Priority (standard and enhanced) -Auto Lighting Optimizer (4 settings) -Long exposure noise reduction -High ISO speed noise reduction (4 settings + Multi Shot NR) -Lens peripheral illumination correction -Chromatic aberration correction -Diffraction correction -Digital Lens Optimizer -Creative Assist: Presets  -Background Blur (5 settings) -Brightness (19 levels) -Contrast (9 levels) -Saturation (9 levels) -Color Tone 1 & 2 (19 levels) -Monochrome (Off/Black and white/Sepia/Blue/Purple/Green)

PICTURE STYLES

- Auto
- Standard
- Portrait
- Landscape
- Fine Detail
- Neutral
- Faithful
- Monochrome
- User Defined (x3)

MODES

Scene Intelligent Auto, Hybrid Auto, Creative Assist, SCN(Self-Portrait, Portrait, Smooth Skin, Landscape, Sports, Close-up, Food, Night Portrait, Handheld Night Scene, HDR Backlight Control), Creative Filters (Grainy B/W, Soft Focus, Fish-eye Effect, Water painting effect, Toy camera effect, Miniature effect , HDR Art standard, vivid, bold, embossed), Program AE , Shutter priority AE, Aperture priority AE, Manual exposure, Movie (Movie auto exposure, Movie manual exposure, Time-lapse movie)

DRIVE MODES

-Single, -Continuous,  -Self timer (2s, 10s, Continuous)

CONTINUOUS SHOOTING

-One shot AF: Approx. 6.1 shots/sec5 -With Servo AF: Approx. 4 shots/sec6

SETTINGS

Auto (Ambience Priority), Auto (White Priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature (100 Kelvin increments)

White balance compensation: -Blue/Amber +/-9 levels -Magenta/ Green +/-9 levels

DISPLAY OPTIONS

Customisable and toggle via INFO. Button

-Liveview image with basic info
-Liveview image with full info
-Liveview image with exposure info -Customisable settings:  Grid overlay (x3 formats), Histogram (Brightness/ RGB), Multi aspect ratios, Hints and Tips

FILE TYPE

RAW+JPEG SIMULTANEOUS RECORDING

Yes, RAW + various JPEG compression possible

MOVIE TYPE

MP4 [Video: MPEG-4 AVC/H.264, Audio: MPEG-4 AAC]

STILL IMAGE TYPE

-RAW: RAW (CR3 14-bit) -Digital Print Order Format [DPOF] Version 1.1 compliant -JPEG: Fine, Normal (Exif 2.31 compliant) / Design rule for Camera File system (2.0)

IMAGE SIZE

-RAW: (3:2) 6000 x 4000, (4:3) 5328 x 4000, (16:9) 6000 x 3368, (1:1) 4000 x 4000
-JPEG 3:2: (L) 6000 x 4000, (M) 3984 x 2656, (S1) 2976 x 1984, (S2) 2400 x 1600
-JPEG 4:3: (L) 5328 x 4000, (M) 3552 x 2664, (S1) 2656 x 1992, (S2) 2112 x 1600
-JPEG 16:9: (L) 6000 x 3368, (M) 3984 x 2240, (S1) 2976 x 1680 (S2) 2400 x 1344
-JPEG 1:1: (L) 4000 x 4000, (M) 2656 x 2656, (S1) 1984 x 1984, (S2) 1600 x 1600

HIGHLIGHT ALERT

Yes

HISTOGRAM

Brightness/ RGB

MOVIE SIZE

-4K - 3840 x 2160 (23.98, 25 fps) -HD - 1280 x 720 (119.9, 100, 59.94, 50 fps) -Full HD - 1920 x 1080 (59.94, 50, 29.97, 25fps)

Canon Canon EOS M200 Cameras

MENU CATEGORIES

- Shooting Menu (x8)
- Playback Menu (x4)
- Connectivity Menu (x2)
- Setup Menu (x5)
- Display Menu
- My Menu

MOVIE LENGTH

Max Duration 29min 59sec, Max File Size 4gb

MOVIE TYPE

MP4 [Video: MPEG-4 AVC/H.264, Audio: MPEG-4 AAC]

FIRMWARE UPDATE

Firmware Update Possible By The User.

PLAYBACK ZOOM

15 steps plus smooth pinch-to-zoom

DISPLAY FORMATS

-Single image
-Index display (4/9/36/100 images) -Single image with information (toggle options)
-Jump Display (1/10/custom number image, by shot date, by rating, by folder, by movies only, protected only)

CUSTOM FUNCTIONS

6 Custom Functions

FIRMWARE UPDATE

Firmware Update Possible By The User.

SLIDE SHOW

-Repeat: On/Off -Playback time: 1/2/3/5/10/30 seconds
-Transition Effects: Off, Slide in 1-2, Fade 1-3

MENU LANGUAGES


English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Vietnamese, Indonesian, Hindi, Japanese

IMAGE ERASE/PROTECTION

-Erase: Single image, Selected images, Selected range, All images -Protection: Selected images, Selected range, All images. Unprotect all images
