Mitsui Dynamic Line Air Conditioners
DYNAMIC LINE AIR CONDITIONERS
DYNAMIC LINE AIR CONDITIONERS
High-efficiency air conditioning
Maximum comfort and efficiency in all seasons: dedicated to the most demanding customers, the Dynamic line is the flagship of the Mitsui offer. Each split encloses a series of functions that enhance the quality of living, organised in a simple and intuitive interface. Discover below the most innovative technologies at the service of well-being and energy saving.
INFORMATION
COMFORT
With 20db silence, follow me sensor and 3d airflow
BRAND
Mitsui
PRODUCT TYPE
Air Conditioners
WI-FI INCLUDED
Wi-fi Connectivity And Remote Contro
ENERGY EFFICIENCY
Inverter technology with class a+++ and high cop performance.
PRODUCTION
Made in Italy
COLLECTION
Dynamic line
SIMPLIFIED MAINTENANCE
Simple steps provide access to the unit’s internal mechanics and electronics.
PURIFICATION
Air with antibacterial filter, plasma ion generator and self-cleaning filters.
SIMPLIFIED INSTALLATION
Rotating front panel that makes access to the unit easy.
ENVIRONMENT
Indoor
USE
Cooling
EASY CLEANING
Easy accessibility that makes cleaning inside the unit quick and easy.
FEATURES
EFFICIENCY
-A+++ : maximum efficiency at the service of your home.
-High COP (Coefficient Of Performance) : all models in the Dynamic line guarantee excellent heat output per kW in heating mode.
WI-FI INCLUDED
The wi-fi card is already integrated in the terminal and does not require any set-up work. The customer only has to configure his preferred app from his smartphone.
COMFORT
-3D Air Flow : the vertical and horizontal oscillation of the baffles enables even air distribution, or its concentration at the desired point.
-Noiseless : with a sound level of only 20dB, the Dynamic air conditioner guarantees quietness and tranquillity.
-Follow Me : this innovative function causes the air conditioner to modulate its output according to the temperature detected by the sensor inside the remote control. This allows you to move around the house without worrying about changing the climate settings, which will always ensure maximum comfort and minimum energy consumption based on your position.
PURIFICATION
-Anti-Bacterial Filter : the first line of defence against dust, pollen and other impurities. The high-intensity antibacterial filter traps the heaviest particles, preventing external pollutants from entering.
-Plasma Ions : the plasma ion generator captures and eliminates germs, bacteria and bad odours, providing an additional level of protection for the home.
-Filter Self-Cleaning : for a short period after switching off, the air conditioner continues to operate at minimum power, reversing the work cycle: this allows any condensation that may have formed inside to dry out, preventing the formation of mould.
Mono Inverter
9000 BTU/H | A+++
- Refrigerant : R32
- Cooling (EER) : 4.20
- Heating (COP) : 4.40
- Dimensions of Indoor Unit : 805x193x302 mm
- Dimensions of Outdoor Unit : 765x303x555 mm
- Heating (capacity): 10000 (2800-11500) BTU/h
- Cooling (capacity): 9000 (3500-11000) BTU/h
- Indoor Unit Power Supply: 220-240/1/50 V/Ph/Hz
- Outdoor Unit Power Supply : 220-240/1/50 V/Ph/Hz
12000 BTU/H | A+++
- Refrigerant : R32
- Cooling (EER) : 3.40
- Heating (COP) : 3.71
- Dimensions of Indoor Unit : 805x193x302 mm
- Dimensions of Outdoor Unit : 765x303x555 mm
- Cooling (capacity) : 12000 (4700-14700) BTU/h
- Heating (capacity) : 13000 (3640-14950) BTU/h
- Indoor Unit Power Supply : 220-240/1/50 V/Ph/Hz
- Outdoor Unit Power Supply : 220-240/1/50 V/Ph/Hz
18000 BTU/H | A++
- Refrigerant : R32
- Cooling (EER) : 3.40
- Heating (COP) : 3.71
- Dimensions of Indoor Unit : 964x222x325 mm
- Dimensions of Outdoor Unit : 805x330x554 mm
- Heating (capacity): 19000 (4400-20030) BTU/h
- Cooling (capacity): 12000 (4700-14700) BTU/h
- Indoor Unit Power Supply: 220-240/1/50 V/Ph/Hz
- External Unit Power Supply : 220-240/1/50 V/Ph/Hz
24000 BTU/H | A++
- Refrigerant : R32
- Cooling (EER) : 3.01
- Heating (COP) : 3.44
- Dimensions of Indoor Unit : 805x193x302 mm
- Dimensions of Outdoor Unit : 805x330x554 mm
- Heating (capacity): 25000 (5300-28000) BTU/h
- Cooling (capacity): 24000 (7200-28000) BTU/h
- Indoor Unit Power Supply: 220-240/1/50 V/Ph/Hz
- Outdoor Unit Power Supply : 220-240/1/50 V/Ph/Hz
