Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

SHERPA MONOBLOC S2 E HEAT PUMPS

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

SHERPA MONOBLOC S2 E HEAT PUMPS

Olimpia Splendid's monobloc air-water heat pump, with R32 refrigerant, is characterised by a particularly compact design, which makes it possible to reach even the highest power ratings (up to 16 kW) with single-fan outdoor units. . The controls are of the latest generation: remote touchscreen panel as standard and integrated wi-fi module for management via cloud (with the Comfort Home app). Through cascade management, the units can be connected together (up to 6 units of the same size, with 1 master unit producing DHW) to reach up to 96 kW of system power.

INFORMATION

BRAND

Olimpia Splendid

PRODUCT TYPE

Heat Pumps

DHW PRODUCTION

up to 60°C

PRODUCTION

Made in Italy

POWER AVAILABLE

9 versions with R32 refrigerant single-phase (6-8-10-12-14-16 kW) three-phase power supplies (12-14-16 kW)

STANDARD SUPPLY REMOTE TOUCHSCREEN CONTROL PANEL

Standard supply remote touchscreen control panel (connection cable up to 50 m not included). Integrated Wi-Fi module for controlling the machine via smartphone and table, with relevant app (Comfort Home)

REFRIGERANT GAS

R32*

EXTERNAL

External air probe integrated in the machine.

COMPRESSOR

Twin rotary dc

EXPANSION VALVE

Electronic.

ENERGY EFFICIENCY

Class in heating moderate climate: A+++ (35°C) e A++ (55°C)

OPERATING LIMITS

Up to -25°C, +43°C (see technical manuals for details

 INVERTER

-Pompa di calore aria-acqua inverter -Air-water heat pump inverter

DOMESTIC HOT WATER

Domestic Hot Water storage tank probe: standard supply with the machine. Cascade management: up to 6 units can be connected (of the same size), 1 Master and 5 Slaves (only the Master unit can produce domestic hot water).

DIMENSIONS DRAWING

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps
MM681012141612T14T16T
A104010401040104010401040104010401040
B410410410410410410410410410
C458458458458458458458458458
D523523523523523523523523523
E191191191191191191191191191
F656656656656656656656656656
G646464646464646464
H865865865865865865865865865
I165165165165165165165165165
J279279279279279279279279279
K898989898989898989
Peso netto kg878787106106106120120120

FEATURES

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

DOMESTIC HOT WATER UP TO 60°C

Sherpa supplies Domestic Hot Water with temperatures up to 60°C.

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

COMPACT TECHNOLOGY

Compact unit and reduced dimensions. For all power sizes the machine is equipped with a single fan unit.

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

GAS R32

All power sizes use the R32 refrigerant, characterised by greater efficiency and a greenhouse effect reduced by almost 70% (compared to R410A).

Olimpia Splendid Sherpa Monobloc S2 E Heat Pumps

SMART CONTROL

The heat pump can be controlled remotely with Tablet and Smartphone thanks to the standard Wi-Fi module (to be interfaced with a wireless router connected to the Internet). The COMFORT HOME can be downloaded free of charge from the Google and Apple Stores, which allows control of the machine via the Cloud.
