Norsk Kleber Kube Stove
KUBE STOVE
KUBE STOVE
The Kube stove has classic clean lines, with a number of elegant features, such as the side windows that fit neatly in the stones without a steel frame.
The Kube stove is available with or without side windows, as well as in different heights. Like all our stoves, the door is made of high-quality cast iron, which makes it robust and durable.
INFORMATION
BRAND
Norsk Kleber
PRODUCT TYPE
Stove
MODELS
- Kube 3-2
- Kube 4
- Kube 5
OUTPUT
- Kube 3 : 4–8 kW
- Kube 4 : 5–10 kW
- Kube 5 : 5–10 kW
WEIGHT
- Kube 3 : 400 kg
- Kube 4 : 480 kg
- Kube 5 : 535 kg
SIDE SCREEN PLATE
A side screen plate is not standard and must be ordered separately.
LOG LENGTH
35 cm
SIDE WINDOW
The Kube stove is available with or without side windows, as well as in different heights. Like all our stoves, the door is made of high-quality cast iron.
OSCAR / KUBE STRAIGHT WALL 80 X 90 CM
Kube Straight wall plate 80/90 cm. Also suitable for Oscar and Marcello
- Art.no. 01-82-24 , black granite
- Art.nr. 01-82-32 , gray marble
CONNECTED
A fresh-air duct can be connected to the stove (Ø=100).
KUBE MODELS
Our Kube models are available with a grey or black door
DETAIL
All of our Kube models are available with a grey or black door that matches the colour on the edges of the side windows. These side windows also have a double layer in order to ensure good combustion and to limit the heat radiation through the windows. Below you can see the Kube 3, which is our smallest model in this series.
DETAIL
| DISTANCE | COMBUSTIBLES | FIREWALL |
|---|---|---|
| w/ side windows, side | 60 cm | 30 cm |
| w/ side windows, back | 15 cm | 10 cm |
| w/o side windows, side | 45 cm | 25 cm |
| w/o side windows: When a screen plate is fitted, the distance can be reduced to | 15 cm | 10 cm |
| w/o side windows, back | 15 cm | 10 cm |
DIMENSIONS
KUBE 3-2
Our smallest model in the series is pictured here with side windows
KUBE 3-2
- Height : 121 cm
- Width : 52 cm
- Depth : 44 cm
- Height To Centre Of Flue Outlet : 106.3 cm
KUBE 4
The Kube 4 has a lot of stone above the combustion chamber and slightly less below
KUBE 4
- Height : 147 cm
- Width : 52 cm
- Depth : 44 cm
- Height To Centre Of Flue Outlet : 132.3 cm
KUBE 5
The Kube 5 has a high combustion chamber, giving a perfect view of the flames from anywhere in the room
KUBE 5
- Height : 166 cm
- Width : 52 cm
- Depth : 44 cm
- Height To Centre Of Flue Outlet : 151.3 cm
