Jvc KW-M56BT Monitor with Receiver

KW-M56BT MONITOR WITH RECEIVER

Jvc KW-M56BT Monitor with Receiver

KW-M56BT MONITOR WITH RECEIVER

Digital Media Receiver featuring 6.8" Capacitive Touch Monitor, Apple CarPlay, Android Auto, USB Mirroring for Android Phones , Bluetooth®,  13-Band EQ, Short Chassis

features

SMARTPHONE INTEGRATION

JVC multimedia receivers interface your smartphone with your car to enrich your driving experience. Enjoy your favorite apps and view content on a big screen, in comfort and safety.

Jvc KW-M56BT Monitor with Receiver

APPLE CARPLAY™ – CONNECT VIA USB

A smarter, safer and more fun way to use your iPhone in the car. Apple CarPlay gives iPhone users an intuitive way to make calls, use Maps, and listen to music with just a word or a touch. With the latest iOS version (iOS 13.0 and higher), 3rd party navigation apps like Google Maps™ and Waze™ are supported.

Jvc KW-M56BT Monitor with Receiver

ANDROID AUTO™ – CONNECT VIA USB

Android Auto was designed with safety in mind. With a simple and intuitive interface and powerful voice actions, it’s designed to minimize distraction so that you can stay focused on the road. With the latest ANDROID OS version (PIE and higher), Google Maps™ and Waze™ are also supported.

Jvc KW-M56BT Monitor with Receiver
Jvc KW-M56BT Monitor with Receiver

MIRRORING FOR ANDROID PHONE – CONNECT VIA USB

By installing the “Mirroring OA for JVC” app, your Android phone is seamlessly displayed on the receiver's screen via USB. You can enjoy a variety of apps such as Waze, YouTube, and Instagram. Touch control is possible from both screen and smartphone.

INFORMATION

AUDIO

-Bass Boost : Yes
-Time Alignment : Yes
-High-Resolution Audio : Yes
-EQ : Yes (13-Band Graphic EQ)
-High-Pass Filter/Low-Pass Filter : Yes

-Preset EQ : Yes (7Preset + 3user)
-Maximum Power Output (Front & Rear) : 50Wx4
-Full Bandwidth Power (Front & Rear) : 22W x 4 (Full Bandwidth Power, at less than 1% THD)

BRAND

Jvc

PRODUCT TYPE

Car Audio

COLLECTION

KW-M56BT

BACK UP MEMORY

Yes

ISO CONNECTOR

Yes

WEIGHT

2.8 lbs. (1.3kg) Including Sleeve and Trim plate

BLUETOOTH CONTROL

-5 BT-Audio Connection : Yes
-2 Phones Full-Time Connection : Yes
-Built-in Bluetooth[1] : Yes (Wired-Mic included)
-Audio Streaming & Control (A2DP, AVRCP) : Yes
-Hands Free Call : Yes (HFP1.6 Wideband Speech)

-Phone Book Access Profile (PBAP) : Yes
-Alphabetical Search for Phone Book : Yes
-Auto Pairing for iPhone/Android : Yes
-Voice Dialing (voice recognition compatible mobile phone required) : Yes

UNIT WEIGHT IN INDIVIDUAL PACKAGE

1.8kg

INSTALLATION SIZE

7" x 3-15/16" x 2-15/16" (178 x 100 x 75 mm)

MEDIA PLAYBACK (USB)

- H.264 Compatible
- WMV Compatible
- MPEG 1/2 Compatible
- MPEG 4 Compatible
- AVI/MKV Compatible

- MP3 Compatible with Tag
- WMA Compatible with Tag
- WAV Compatible with Tag
- AAC Compatible with Tag
- FLAC Compatible with Tag

ANDROID CONTROL

- Android Auto[2] : Yes (via USB)
- Android Music Playback : Yes (via Bluetooth(R))

INPUTS AND OUTPUTS

- Video Out : RCA
- AV Input : Mini Jack
- Rear view camera Input : Yes
- Line Output Terminals : 2Preouts (Terminal) + Sub WF (Cable)

- Pre-output Level/Impedance : 2.0V / 10k ohms
- Subwoofer Output with Level/Frequency Control : Yes

WIRELESS REMOTE CONTROL

Ready (RM-RK258 required)

STEERING REMOTE CONTROL READY

Yes

RADIO TUNER

 - SiriusXM Ready : Yes
- Auto Memory Entry : Yes
- AM Frequency Rang 530-1.700kHz
- Preset Stations : 20(FM:15ch, AM:5ch)
- Radio Broadcast Data System (RBDS)
- FM Frequency Rang : 87.9 - 107.9MHz

MONITOR

- Dimmer : Yes
- Customizable GUI : Yes
- Touch Panel : Capacitive
- Gesture Touch Control : Yes
- Multilingual Display : Yes[4]
- Key Illumination Color : Yes
- Screen Size : 6.8"W VGA Screen

BLUETOOTH CONTROL

- 5 BT-Audio Connection : Yes
- Phones Full-Time Connection : Yes
- Alphabetical Search for Phone Book : Yes
- Auto Pairing for iPhone/Android : Yes
- Phone Book Access Profile (PBAP) : Yes

- Audio Streaming & Control (A2DP, AVRCP) : Yes
- Hands Free Call : Yes (HFP1.7 Wideband Speech)
- Built-in Bluetooth[1] : Yes (Version 4.1, Wired-Mic included)
- Voice Dialing (voice recognition compatible mobile phone required : Yes

USB

- USB Port : x1 (High Speed)
- Position : Rear
- USB Power Supply : Yes (1.5A High Current Charging)

BLUETOOTH® WIRELESS TECHNOLOGY

CAPACITIVE TOUCHSCREEN

The Capacitive touch screen provides high clarity and uses a superior touch control, requiring lighter contact with greater accuracy.

Jvc KW-M56BT Monitor with Receiver

HIGH CURRENT 1.5A CHARGING

Rapidly charge your smartphone using the USB port, with up to a maximum of 1.5A. *Compatibility depends on the smartphone.

STREAMING MUSIC

Listen to popular music applications and music stored on your device with basic audio controls.

STEERING WHEEL REMOTE CONTROL READY

Factory steering wheel control functions can be retained with a third-party adapter (sold separately).

SIRIUSXM READY

Ready for SiriusXM Radio. You can listen to over 100 Channels of music, sports, and entertainment.

CAPACITIVE TOUCHSCREEN

The Capacitive touch screen provides high clarity and uses a superior touch control, requiring lighter contact with greater accuracy.

SOUND OPTIMIZATION

Jvc KW-M56BT Monitor with Receiver

TIME ALIGNMENT

By selecting the speaker type and the distance to the center of the listening position, the receiver will automatically adjust the timing of the sound output from each of the speakers so that the sound from each of the speakers will arrive exactly at the same time to the listening position.

Jvc KW-M56BT Monitor with Receiver

13-BAND EQUALIZER

Use the 13-Band Equalizer to manually adjust the sound to your taste.

DETAIL

SHORT CHASSIS

The reduced depth of the chassis contributes to a weight reduction and facilitates easier installation.

Jvc KW-M56BT Monitor with Receiver

VARIOUS FORMATS COMPATIBLE

Supports a variety of file formats for audio and video playback.

Jvc KW-M56BT Monitor with Receiver
Jvc KW-M56BT Monitor with Receiver

REAR VIEW CAMERA READY

The Rear View Camera input allows you to connect an optional rear view camera (sold separately). Rear view cameras allow you to safely back up your vehicle, monitor towing, and more.

Jvc KW-M56BT Monitor with Receiver

WATERPROOF DESIGN

-1/4" color CMOS sensor with effective 380,000 pixels -Flexible mounting bracket included -Camera dimensions (WxHxD): 23.4mm x 23.4mm x 23.9mm -Weight: 21g (Camera only)

Jvc KW-M56BT Monitor with Receiver

GESTURE TOUCH CONTROL

Just touch and move your finger over the screen for various operations corresponding to your finger movements. Intuitive control provides safer operation for in-car entertainment.
