Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw

WOOD BURNING STEEL STOVE BJORN Ø 150 8KW

Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw

WOOD BURNING STEEL STOVE BJORN Ø 150 8KW

The BJORN stove is distinguished by a generous panoramic GLASS window with an aesthetically pleasing black décor, which provides a perfect view of the flames.

This not only gives it an elegant look, but also makes it an attractive decorative element.

INFORMATION

BRAND

Kratki

PRODUCT TYPE

Stove

COLLECTION

Bjorn

Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw

PHYSICAL PARAMETERS

- Width : 76.1 cm
- Depth : 46 cm
- Height : 105.2 cm

DETAILS

BJORN is ideal for those looking for a stylish finish that fits into a variety of interior designs, whether traditional, minimalist or modern. It adds charm to any room it is placed in.

RATED OUTPUT (KW)

8

MATERIALS

Steel

WE ARE CONFIDENT IN THE QUALITY OF OUR EQUIPMENT

The stove meets the requirements of the ECODESIGN.

In addition, it has been designed to meet the strict Flamme Verte environmental standards, guaranteeing high efficiency, clean combustion and reduced emissions. So you can enjoy a cosy atmosphere in your home while minimising your impact on the environment.

Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw

ENERGY CLASS

A

WEIGHT

163 kg

EAN

- Black : 5903751232100
- White : 5903751231813

ENERGY EFFICIENCY INDEX (EEI)

103.7

TECHNICAL DRAWING

Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw

TYPE OF FUEL

Seasoned Deciduous Wood (Humidity ≤20%)

FRONT TYPE

Steel Front With Bent Painted Glass

INSTALLATION

Easier stove installation thanks to the ø200mm hole in the base -Meets the criteria of the ecodesign and flamme verte

DESIGN FEATURES

- Ashpan
- Decorative Glass
- Air intake - built In
- Combustion Chamber Lining

HEATING POWER RANGE (KW)

5-11

HEATING EFFICIENCY (%)

78.4

CERTIFICATIONS / COMPLIANCE

Meets requirements : Ecodesign, 7* Flamme Verte, Designed for recuperation, KRATKI PRO

SELF CLOSURE

No

DOOR OPENING DIRECTION

Left

DIAMETER

- Flue Outlet : 150 mm
- Air Intake : 125 mm

COLORS

- Black
- White

Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw
Black
Kratki Wood Burning Steel Stove Bjorn Ø 150 8kw
White

ENERGETIC EFFICIENCY

- Emisja CO (mg/m3) : 1468
- Emisja NOx (mg/Nm3) : 76
- Emisja OGC (mg/Nm3) : 100
- Dust emission (mg/Nm3) : 40
- Flue gases mass flow rate (g/s) : 8
- Seasonal Heating efficiency (%) : 68.4
- CO emissions (at 13% O 2 ) ≤ given in % : 0.117
- Moc cieplna do ogrzewania pomieszczeń (kW) : 8

EXHAUST GAS TEMPERATURE (℃)

255

MAX LENGTH OF LOGS (CM)

50

ADVANTAGES

-Intuitive air control -Cast iron grate and steel ash pan -Designed for homes with recuperation -Clean glass system to keep the glass clean -Heat-resistant glazing with a temperature resistance of up to 600°c -Adjustable feet to compensate for uneven floor surfaces and level the stove -Comfortable door opening thanks to a modern and durable mechanism

-A handle in the form of a railing provides a comfortable grip over its entire length -The generous glass panoramic glass with aesthetically pleasing black décor gives the stove an elegant appearance -Longer temperature maintenance due to lining of the combustion chamber with termotec accumulation material -Deepened combustion chamber accommodates more wood and prevents ash from spilling into the room when refuelling -The triple system of airing the combustion chamber contributes to the high efficiency of the combustion process

-A triple system of combustion chamber aeration contributes to the high efficiency of the combustion process, the extension of the combustion flow through a system of two deflectors and a flue outlet screen contributes to lowering the temperature of the fumes, which translates into greater effectiveness of the combustion process and lower chimney losses -Inspection doors open on the push-to-open principle -Air intake via an external spigot (can be connected from behind or underneath) with a diameter of ø 125, -The stove is coated with a specially designed paint mixture with increased scratch resistance and uniform and smooth texture -Possibilitý to connect the flue outlet either from the top or the back of the unit
