Frigidaire Frigidaire Gallery 27" Double Electric Wall Oven With 15+ Ways To Cook
FRIGIDAIRE GALLERY 27" SINGLE ELECTRIC WALL OVEN WITH 15+ WAYS TO COOK
FRIGIDAIRE GALLERY 27" SINGLE ELECTRIC WALL OVEN WITH 15+ WAYS TO COOK
GCWD2767AF
FEATURES
DELIVER ALL OF THE FLAVOR AND NONE OF THE GUILT WITH AIR FRY
Air Fry allows you to make healthier and delicious meals for the entire family, right in your oven.
START BAKING IMMEDIATELY WITH NO PREHEAT
Eliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.1
EXPERIENCE A HASSLE-FREE WAY TO COOK WITH SLOW COOK
With Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
OUR MOST ADVANCED AND POWERFUL CONVECTION SYSTEM, TOTAL CONVECTION
Total Convection gives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Air Sous Vide, Bread Proof, Dehydrate and more!
INFROMATION
CONTROLS
- Control Lock : Yes
- Sabbath Mode: Yes
INSTALLATION
Power Supply Connection Location : Top Right
BRAND
Frigidaire
PRODUCT TYPE
Oven
FRIGIDAIRE FIT PROMISE
Yes
AB-1200
Information available at frigidaire.com/en/ab1200
COOKING CONTROLS FUNCTION
- Silent Control Panel : Yes
- Program Fahrenheit or Celsius : Yes
- Change between Continuous Bake Setting or 12-Hour Energy Saving Feature : Yes
PROP 65 LABEL
Yes
ACCESSORIES
Included Steam Tray : Yes
ELECTRICAL SPECIFICATIONS
- Voltage Rating : 240 V
- Amps @ 240 Volts : 40 Amps
- Connected Load @ 240V : 9 kW
- Minimum Circuit Required : 40
Amps
DISPLAY
- Control Location : Top
- Display Light Color : White
- Display Interface Color : White
- Display Type : Capacitive Touch
DIMENSIONS
- Width : 27"
- Height : 50 7/8"
- Depth : 27 7/16"
OVEN CAPACITY
3.8 Cu. Ft.
WARM AND HOLD
Yes
OVEN INTERIOR COLOR
Midnight Black
LOWER/UPPER INTERIOR DIMENSIONS
- Oven Interior Height : 17"
- Oven Interior Width : 20 1/2"
- Oven Interior Depth : 18 3/4"
DEPTH WITH HANDLE
27 7/16"
DEPTH WITH DOOR 90° OPEN
45 3/4"
CUTOUT DIMENSIONS
-Maximum Cutout Height : 28 1/4"
-Maximum Cutout Width : 25 1/4"
-Minimum Cutout Height : 27 14"
-Minimum Cutout Width : 24 7/8"
OVEN CAPACITY
3.8 Cu. Ft.
TOTAL CAPACITY
7.6 Cu. Ft.
STEAM
- Steam Bake : Yes
- Steam Clean : Yes
- Steam Roast : Yes
SAFETY CERTIFICATIONS AND APPROVALS
- RoHS : Yes
- UL Listed : Yes
- CSA Listed : Yes
LIGHT
- Oven Light Quantity : 2
- Oven Light Type : Halogen
- Oven Light Watts : 40 Watts
NUMBER OF RACK POSITIONS
5
NUMBER OF CONVECTION FANS
1
INSTALLATION DIAGRAM
DETAIL
The Frigidaire Gallery 27" Double Wall Oven with Total Convection, features our most powerful and advanced convection system, which enables cooking modes like No Preheat, Air Fry, Slow Cook, Steam Bake, Steam Roast, Air Sous Vide, Convection Roast, Convection Bake, Bread Proof and more! Also includes a convenient temperature probe, a premium touch screen digital control panel and our fingerprint resistant, Smudge-Proof® Stainless Steel finish.
WARRANTY
1 Year
AVAILABLE COLORS
- Stainless Steel
- Black Stainless Steel
OVEN
- Broil System : Yes
- Rack Type 2 : Glide
- Rack Type 2 Quantity : 1
- Broil Element Pass : 6
- Bake Element Pass : 8
- Bake Element : 2,500 Watts
- Bake Element Type : Hidden
- Convection : Yes
- Rack Type 1 : Handle
- Cleaning System : Yes
- Rack Type 1 Quantity : 5
- Convection Type : Total
- Broil Element : 4,000 Watts
- Convection Element : 2,500 Watts
COOKING CONTROLS
- Light Yes
- Broil : Yes
- Bake : Yes
- Air Fry : Yes
- On / Off : Yes
- Bake Time : Yes
- Oven Light : Yes
- Air Sous Vide : Yes
- Clock : Yes
- Cancel : Yes
- Delay : Start Yes
- My Favorite : Yes
- Fast Preheat : Yes
- Kitchen Timer : Yes
- Convection Bake : Yes
- Convection Roast : Yes
DETAIL
SMUDGE-PROOF® STAINLESS STEEL
Resists fingerprints and cleans easily.
PREMIUM TOUCH SCREEN CONTROL PANEL
Features a responsive 4.3 inch, full color, capacitive touch digital control panel.
TAKE THE GUESSWORK OUT OF COOKING WITH THE TEMPERATURE PROBE
The Temperature Probe monitors and alerts when the desired finished cooking temperature has been reached.
OPTIONAL READYCOOK™ AIR FRY TRAY (SOLD SEPARATELY)
Allows you to achieve perfectly crispy and delicious Air Fry results.3
PEACE OF MIND WITH OUR FRIGIDAIRE® FIT PROMISE
We promise that your new 27" Frigidaire® Gallery single wall oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs. 2
ENJOY CRISPY, PERFECTLY ROASTED MEALS WITH STEAM ROAST
Steam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.
ACHIEVE BAKERY RESULTS AT HOME WITH STEAM BAKE
With Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.
GET PRECISE TEMPERATURE CONTROL WITH AIR SOUS VIDE
Get the benefits of sous vide cooking, right in your oven. Air Sous Vide uses precisely-controlled temperature and airflow to lock in flavor and moisture for yummy, perfectly cooked meals.
OFFERS TWO CONVENIENT CLEANING OPTIONS
Enjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
