Frigidaire Frigidaire Gallery 27" Double Electric Wall Oven With 15+ Ways To Cook

FRIGIDAIRE GALLERY 27" SINGLE ELECTRIC WALL OVEN WITH 15+ WAYS TO COOK

Frigidaire Frigidaire Gallery 27\

FRIGIDAIRE GALLERY 27" SINGLE ELECTRIC WALL OVEN WITH 15+ WAYS TO COOK

GCWD2767AF

FEATURES

DELIVER ALL OF THE FLAVOR AND NONE OF THE GUILT WITH AIR FRY

Air Fry allows you to make healthier and delicious meals for the entire family, right in your oven.

Frigidaire Frigidaire Gallery 27\

START BAKING IMMEDIATELY WITH NO PREHEAT

Eliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.1

Frigidaire Frigidaire Gallery 27\

EXPERIENCE A HASSLE-FREE WAY TO COOK WITH SLOW COOK

With Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.

Frigidaire Frigidaire Gallery 27\

OUR MOST ADVANCED AND POWERFUL CONVECTION SYSTEM, TOTAL CONVECTION

Total Convection gives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Air Sous Vide, Bread Proof, Dehydrate and more!

Frigidaire Frigidaire Gallery 27\

INFROMATION

CONTROLS

- Control Lock : Yes
- Sabbath Mode: Yes

INSTALLATION

Power Supply Connection Location : Top Right

BRAND

Frigidaire

PRODUCT TYPE

Oven

Frigidaire Frigidaire Gallery 27\

FRIGIDAIRE FIT PROMISE

Yes

AB-1200

Information available at frigidaire.com/en/ab1200

COOKING CONTROLS FUNCTION

- Silent Control Panel : Yes
- Program Fahrenheit or Celsius : Yes
- Change between Continuous Bake Setting or 12-Hour Energy Saving Feature : Yes

PROP 65 LABEL

Yes

ACCESSORIES

Included Steam Tray : Yes

ELECTRICAL SPECIFICATIONS

- Voltage Rating : 240 V
- Amps @ 240 Volts : 40 Amps
- Connected Load @ 240V : 9 kW
- Minimum Circuit Required : 40
Amps

DISPLAY

- Control Location : Top
- Display Light Color : White
- Display Interface Color : White
- Display Type : Capacitive Touch

DIMENSIONS

- Width : 27"
- Height : 50 7/8"
- Depth : 27 7/16"

Frigidaire Frigidaire Gallery 27\

OVEN CAPACITY

3.8 Cu. Ft.

WARM AND HOLD

Yes

OVEN INTERIOR COLOR

Midnight Black

LOWER/UPPER INTERIOR DIMENSIONS

- Oven Interior Height : 17"
- Oven Interior Width : 20 1/2"
- Oven Interior Depth : 18 3/4"

DEPTH WITH HANDLE

27 7/16"

DEPTH WITH DOOR 90° OPEN

45 3/4"

CUTOUT DIMENSIONS

-Maximum Cutout Height : 28 1/4"
-Maximum Cutout Width : 25 1/4"
-Minimum Cutout Height : 27 14"
-Minimum Cutout Width : 24 7/8"

OVEN CAPACITY

3.8 Cu. Ft.

TOTAL CAPACITY

7.6 Cu. Ft.

STEAM

- Steam Bake : Yes
- Steam Clean : Yes
- Steam Roast : Yes

Frigidaire Frigidaire Gallery 27\

SAFETY CERTIFICATIONS AND APPROVALS

- RoHS : Yes
- UL Listed : Yes
- CSA Listed : Yes

LIGHT

- Oven Light Quantity : 2
- Oven Light Type : Halogen
- Oven Light Watts : 40 Watts

NUMBER OF RACK POSITIONS

5

NUMBER OF CONVECTION FANS

1

Frigidaire Frigidaire Gallery 27\

INSTALLATION DIAGRAM

DETAIL

The Frigidaire Gallery 27" Double Wall Oven with Total Convection, features our most powerful and advanced convection system, which enables cooking modes like No Preheat, Air Fry, Slow Cook, Steam Bake, Steam Roast, Air Sous Vide, Convection Roast, Convection Bake, Bread Proof and more! Also includes a convenient temperature probe, a premium touch screen digital control panel and our fingerprint resistant, Smudge-Proof® Stainless Steel finish.

WARRANTY

1 Year

AVAILABLE COLORS

- Stainless Steel
- Black Stainless Steel

OVEN

- Broil System : Yes
- Rack Type 2 : Glide
- Rack Type 2 Quantity : 1
- Broil Element Pass : 6
- Bake Element Pass : 8
- Bake Element : 2,500 Watts
- Bake Element Type : Hidden

- Convection : Yes
- Rack Type 1 : Handle
- Cleaning System : Yes
- Rack Type 1 Quantity : 5
- Convection Type : Total
- Broil Element : 4,000 Watts
- Convection Element : 2,500 Watts

Frigidaire Frigidaire Gallery 27\

COOKING CONTROLS

- Light Yes
- Broil : Yes
- Bake : Yes
- Air Fry : Yes
- On / Off : Yes
- Bake Time : Yes
- Oven Light : Yes
- Air Sous Vide : Yes

- Clock : Yes
- Cancel : Yes
- Delay : Start Yes
- My Favorite : Yes
- Fast Preheat : Yes
- Kitchen Timer : Yes
- Convection Bake : Yes
- Convection Roast : Yes

DETAIL

SMUDGE-PROOF® STAINLESS STEEL

Resists fingerprints and cleans easily.

PREMIUM TOUCH SCREEN CONTROL PANEL

Features a responsive 4.3 inch, full color, capacitive touch digital control panel.

TAKE THE GUESSWORK OUT OF COOKING WITH THE TEMPERATURE PROBE

The Temperature Probe monitors and alerts when the desired finished cooking temperature has been reached.

OPTIONAL READYCOOK™ AIR FRY TRAY (SOLD SEPARATELY)

Allows you to achieve perfectly crispy and delicious Air Fry results.3

PEACE OF MIND WITH OUR FRIGIDAIRE® FIT PROMISE

We promise that your new 27" Frigidaire® Gallery single wall oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs. 2

ENJOY CRISPY, PERFECTLY ROASTED MEALS WITH STEAM ROAST

Steam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.

ACHIEVE BAKERY RESULTS AT HOME WITH STEAM BAKE

With Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.

GET PRECISE TEMPERATURE CONTROL WITH AIR SOUS VIDE

Get the benefits of sous vide cooking, right in your oven. Air Sous Vide uses precisely-controlled temperature and airflow to lock in flavor and moisture for yummy, perfectly cooked meals.

OFFERS TWO CONVENIENT CLEANING OPTIONS

Enjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles.
