Frigidaire Frigidaire Gallery 30" Single Electric Wall Oven with 15+ Ways To Cook

Frigidaire Gallery 30" Single Electric Wall Oven with 15+ Ways To Cook

Frigidaire Frigidaire Gallery 30\

FRIGIDAIRE GALLERY 30" SINGLE ELECTRIC WALL OVEN WITH 15+ WAYS TO COOK

This single wall oven features our most powerful and advanced Total Convection system ever - giving you over 15 ways to cook.

FEATURES

STEAM BAKE

With Steam Bake, steam evenly circulates throughout the oven cavity, resulting in breads and muffins that rise higher and are light and fluffy.

TEMPERATURE PROBE

Monitors and alerts when the desired finished cooking temperature has been reached.

Frigidaire Frigidaire Gallery 30\

READYCOOK™ AIR FRY TRAY-SOLD SEPARATELY

Optional ReadyCook™ Air Fry Tray allows you to achieve perfectly crispy and delicious results.3

STEAM ROAST

Steam Roast uses moisture to make perfectly crispy and tender meats and vegetables that are roasted to perfection.

PREMIUM GLIDE RACK

Our extending Glide Rack makes it easier to monitor and lift your food out of the oven.

FRIGIDAIRE® FIT PROMISE

We promise that your new 30" Frigidaire® Gallery single wall oven will fit your existing cabinet cutout of the same width and configuration, or we will reimburse you up to $300 for cabinet modification costs. 2

SMUDGE-PROOF® STAINLESS STEEL

Resists fingerprints and cleans easily.

EXTRA LARGE OVEN CAPACITY

Cook more at once with our extra large, 5.3 cu.ft. capacity oven.

PREMIUM TOUCH SCREEN CONTROL PANEL

Features a responsive 4.3 inch, full color, capacitive touch digital control panel.

AIR SOUS VIDE

Uses precisely-controlled temperature and airflow to lock in flavor and moisture to cook foods to the finish temperature you want.

SELF AND STEAM CLEAN CYCLES

Enjoy more cleaning flexibility. Select Steam Clean for a quick, 30 minute clean or choose Self Clean, which is available in 2, 3 and 4 hour cycles

INFORMATION

BRAND

Frigidaire

PRODUCT TYPE

Air Conditioner

FRIGIDAIRE FIT PROMISE

Yes

PRODUCT WEIGHT

125 lbs

PROP 65 LABEL

Yes

WARRANTY - LABOR

1 Year

WARRANTY - PARTS

1 Year

SABBATH MODE

Yes

AB-1200

Information available at frigidaire.com/en/ab1200

Frigidaire Frigidaire Gallery 30\

DIMENSIONS

- Height : 28"
- Width : 29 7/8"
- Depth : 27 5/8"

DEPTH WITH DOOR 90° OPEN

48 3/16"

OVEN CAPACITY

5.3 Cu. Ft.

VOLTAGE RATING

240 V

WINDOW DIMENSIONS

- Minimum Cutout Height : 26 3/4"
- Minimum Cutout Width : 28 1/2"
- Maximum Cutout Height : 28"
- Maximum Cutout Width : 29"

CONTROL LOCK

Yes

SABBATH MODE

Yes

COOKING CONTROLS FUNCTION

- Delayed Bake : Yes
- Timed Cooking : Yes
- Energy Saving Feature : Yes
- Silent Control Panel : Yes

DISPLAY

- Display Type : Capacitive Touch
- Display Light Color : White
- Display Interface Color : White

ELECTRICAL SPECIFICATIONS

- Amps @ 240 Volts : 20 Amps
- Connected Load @ 240V : 4.5 kW
- Minimum Circuit Required : 20 Amps

BAKE ELEMENT

2500 Watts

BAKE ELEMENT PASS

8

BAKE ELEMENT TYPE

Hidden

BROIL ELEMENT

4000 Watts

Frigidaire Frigidaire Gallery 30\

BROIL ELEMENT PASS

6

CONVECTION ELEMENT

3800 Watts

CONVECTION TYPE

Total

OVEN INTERIOR COLOR

Midnight Black

NUMBER OF CONVECTION FANS

1

NUMBER OF RACK POSITIONS

6

SAFETY CERTIFICATIONS AND APPROVALS

- RoHS : Yes
- UL Listed : Yes
- Csa Listed : Yes

GENERAL SPECIFICATIONS

- Prop 65 Label : Yes
- Warranty - Labor : Yes
- Warranty - Parts : Yes
- Frigidaire Fit Promise : Yes

Frigidaire Frigidaire Gallery 30\

OVEN LIGHT QUANTITY

2

OVEN LIGHT TYPE

Halogen

OVEN LIGHT WATTS

40 Watts

RACK POSITION TYPE

Handle

DEPTH WITH DOOR 90° OPEN

48 3/16"

DEPTH WITH HANDLE

27 3/5"

COLORS

- Stainless Steel
- Black Stainless Steel

INTERIOR DIMENSIONS

- Oven Interior Height : 18 1/8"
- Oven Interior Width : 25 2/10"
- Oven Interior Depth : 19 7/8"

FUNCTIONS

- Light :Yes
- No Preheat : Yes
- Oven Light Yes
- Perfect Turkey : Yes
- Auto Fan : Yes
- Dry Mode : No
- Sleep Mode : Yes
- Auto Restart : Yes
- Energy Saver : Yes
- Clean Air Ionizer : No
- 24-Hour On/Off Timer : No
- Low Voltage Start-up : Yes

Frigidaire Frigidaire Gallery 30\

DETAIL

Frigidaire Frigidaire Gallery 30\

AIR FRY

Make healthier and delicious meals for your entire family - right in your oven.

Frigidaire Frigidaire Gallery 30\

NO PREHEAT

Eliminates time wasted waiting on your oven to heat up - simply place your food in the cold oven and get to meal time, in no time.1

Frigidaire Frigidaire Gallery 30\

TOTAL CONVECTION SYSTEM

Gives you maximum versatility in the kitchen, powering cooking modes like Air Fry, No Preheat, Slow Cook, Convection Bake, Steam Bake, Convection Roast, Steam Roast, Air Sous Vide and more!

Frigidaire Frigidaire Gallery 30\

SLOW COOK

With Slow Cook, your food cooks slowly and at a lower temperature (as low as 100° F), allowing you to lock in moisture and flavor without over or undercooking your food.
