Arada M Series 5 Wood Burning Stove
M SERIES 5 WOOD BURNING STOVE
M SERIES 5 WOOD BURNING STOVE
4.9kW Wood burning stove with three door styles
Superior styling with excellent fuel efficiency
The M Series 5 matches slim door bezels and one of our largest glass panes to date for a spectacular flame picture.
Just like its larger sibling, this stove is available with three distinct door styles. Choose from either a cast iron door model (MCAST-5) which features a bevelled edge and 'picture frame' styling; Next the steel door model (MSTEEL-5) for a more contemporary feel or for a sleek, flat contemporary look consider our super-flat fronted glass door (MGLASS-5).
INFORMATION
BRAND
Arada
PRDUCT TYPE
Stove
DIMENSIONS
- Width : 468mm
- Height : 468mm
- Depth : 363mm
PRODUCTION
Made in Serbia
COLLECTION
M Series 5
MATERIALS
Available with either Cast Iron, Steel or Glass door options
OUTPUT
4.9 kW (Wood)
CODE
MCAST-5
INSTALLATION
Suitable for installation on non-constructional hearth
OPTIONAL EXTRAS, STANDING PROUD
Further enhancing the base M Series 5 stove model, there are three optional stand variations to choose from. The first option is a set of bolt-on feet which increases the overall stove height by about 8cm. For additional practicality, our mid-height Stand and Log Store optional extras have integrated storage areas. Each of these three options has an integrated ash lip to help keep your hearth looking smart.
CONTROL
Approved for use in Smoke Control Areas
PLATE
Stainless steel ash pan and throat plate
DETAILS
The super-efficient stove engine in the 4.9kW M Series 5 stove is based upon our proven Ecodesign Ready technologies to give extended wood fuel efficiency and lower emissions than an open fire or a 10 year old stove.
ECODESIGN
Wood-only stove. Surpasses Ecodesign standards for wood burning
ENERGY RATING
A (Wood)
GUARANTEE
Lifetime guarantee
HEAT
Optional rear heat shield for closer positioning to combustibles
USE
Indoor
PAINT
Non-smoker paint
TOP OR REAR
Top or rear 127mm (5inch) flue outlet
ADJUSTABLE
Adjustable front feet and rear floor fixing kit as standard
DOWNLOADS
↓ Declaration of Performance
↓ M Series Stove User Guide (BK766-r4)
↓ Dry Stove Installation Guide (BK545-r14)
↓ Optional Stand / Log store fitting guide (BK748-r2)
↓ M Series Stove Glass replacement guide (BK774-r1)
↓ M Series Door Rope replacement guide (BK601-r1)
↓ Product Fiche and Technical Specification (BK999)
↓ Door Catch and Pin Adjustment for M Series Stove (BK773-r1)
↓ Declaration of Conformity M Series 5 (Cast/Glass/Steel door versions) UKCA
↓ Optional Heat Shield / Optional Direct Air fitting guides (BK736-r3 & BK737-r3)
LATCH
Click-close door latch
COMPATIBLE
Direct air compatible
CLEAN
Preheated airwash system for clean glass
COLORS
ORIGINAL AND METALLICS
THE BOLD EDIT
NEW THE EARTH COLLECTION
OPTIONAL EXTRAS
HANDLE
Alternative Matt Black colour handle for M Series 5 (AFS4793)
STOVE FEET (FEET-M5)
Height-extending bolt-on Feet (with ash lip) - extends height by 77 mm
- Width : 504mm
- Height : 77 mm
- Depth : 303 mm / 340 mm (inc. ash lip)
STOVE STAND (STAND-5)
Medium Stand (with ash lip) - extends height by 200 mm
- Width : 503mm
- Height : 200 mm
- Depth : 304 mm
LOG STORE (LOG-5)
High Log Store (with ash lip) - extends height by 420 mm
- Width : 503mm
- Height : 420 mm
- Depth : 304 mm
