SOLAR WATER HEATER - SOLAR HOT WATER SYSTEM
INFORMATION
WEIGHT
- 150-1-T250 : 50kg
- 200-1-T270 : 57kg
- 300-2-T200/ W200 : 41kg each
BRAND
Sole
PRODUCT TYPE
Solar System
NUMBER OF COLLECTORS
- 150-1-T250 : 1
- 200-1-T270 : 1
- 300-2-T200/ W200 : 2
GLASSING
-150-1-T250/ 200-1-T270 : Tempered low iron glass 3,2 mm. 91.5% transmission.
-300-2-T200/ W200 : Tempered low iron glass 4 mm. 88.5% transmission
SEALING
EPDM Rubbe
MAX. WORKING PRESSURE
10 at
ABSORBER SURFACE
- 150-1-T250 : 2.31m²
- 200-1-T270 : 2.68m²
- 300-2-T200/ W200 : 3.82m²
HEAT EXCHANGER
Internal “double jacket” heat exchanger made from 1.5 mm U.S.D. 37.2 steel sheet
SIZES OF EUROSTAR FINO SOLAR WATER HEATERS
- 150lt
- 200lt
- 300lt
SOLAR SAFETY VALVE
Safety valve: 2.5at
ANODE PROTECTION
Magnesium rod
AREA OF COLLECTOR
- 150-1-T250 : 2.31m²
- 200-1-T270 : 2.68m²
- 300-2-T200/ W200 : 3.82m²
WEIGHT FILLED
- 150-1-T250 : 202.7kg
- 200-1-T270 : 245.7kg
- 300-2-T200/ W200 : 396.50kg
DIMENSIONS
- 150-1-T250 : 1320mm x Ø500
- 200-1-T270 : 1320mm x Ø530
- 300-2-T200/ W200 : 2080mm x Ø530
WEIGHT EMPTY
- 150-1-T250 : 60kg
- 200-1-T270 : 67kg
- 300-2-T200/ W200 : 106kg
EXTERNAL COVER
Silver color (Stainless steel cover is optional)
NOMINAL CAPACITY
- 150-1-T250 : 150ltr
- 200-1-T270 : 200ltr
- 300-2-T200/ W200 : 300ltr
BOILER BODY
The boiler “body” is made from 2.5mm USD 37.2 steel plate. The boiler is (glass) enameled with the advanced double “direct” method “fired” at 860°C
INSULATION
-150-1-T250/ 200-1-T270 : Polyurethane 50mm (40kg/m3) cast under pressure for EUR 150 and 40mm for EUR 200
-300-2-T200/ W200 : Polyurethane 40mm thickness casted under pressure with density 40kg/m³
ABSORBER FINS
Aluminum or Copper sheet with selective treatment. Welded to copper pipe with laser or ultrasonic welding. a = 95% e = 5% ±1
EUROSTAR THERMOSYPHON KITS - LOW HEIGHT
-The Eurostar Fino solar panel (collector) casing is made of specially designed extruded aluminium profile powder coated, without any external connections, screws, nuts or rivets. It has a special slot for the rubber sealing making it 100% watertight. At the same time the powerful support system will resist any weather conditions even typhoons. -The rockwool 40mm (50kg/m3) insulation of the solar panel (collector) will maintain very high temperatures, which along with the other technical characteristics, achieve an incredible high efficiency. -The absorber is composed of a full face copper sheet with blue super selective titanium coating of 0.20mm thickness (selective or non-selective aluminum absorbers are also available) and is welded to the copper pipes by ultrasonic or laser welding. -The primary heliothermic liquid developed by SOLE achieves maximum transfer of heat to the water in the tank and at the same time protects the collector from scaling, rusting, freezing and overheating. The Eurostar Fino “heliothermic liquid” will last for a lifetime without needing to be replaced.
-The solar panel’s glazing is 4 mm low iron solar prismatic tempered glass and ensures maximum penetration of irradiation. It is oven-treated at 700 ºC, achieving maximum strength and durability. -A special EPDM rubber profile ensures 100% water and vapor sealing. The rubber profile is covered by an aluminium profile on the top and sides of the solar water heater collector, protecting it from damage during transportation, stocking or installation. -Special blind rivet nuts on the back of the aluminium profile allows easy installation on: Flat roofs: the complete set of supports makes installation on flat roofs just simple. This aesthetic result proves the superiority of the Eurostar Fino design achieving a maximum height of 1,00m.
TECHNICAL DIAGRAM
