Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

Broan® F40000 Series Under-Cabinet Range Hood

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

BROAN® F40000 SERIES UNDER-CABINET RANGE HOOD

Broan® 30-Inch Convertible Under-Cabinet Range Hood, 230 Max Blower CFM, White

The F40000 series provides installation flexibility with 4-way convertibility to fit virtually all applications.

INFORMATION

BRAND

Broan Nutone

PRODUCT TYPE

Hood

FILTER TYPE

Aluminum

PRODUCTION

Made in USA

LIGHTING TYPE

Incandescent

MODEL

F403001

HVI CERTIFIED

Yes

UL LISTED

Yes

MANUFACTURER WARRANTY

1 Year

SOUND LEVEL (SONES)

6.5

DIAMETER

7" Round

DIMENSIONS

Available Width : 24", 30", 36" and 42"

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

ADA COMPLIANCE

Yes

LIGHT BULBS INCLUDED

No

MATERIAL

Steel

LIGHT LEVELS

1

DAMPER INCLUDED

No

ENERGY STAR® CERTIFIED

No

SWITCH CONTROL TYPE

Rocker

VENT TYPE

Convertible Built-In

DUCTLESS RECIRCULATION CAPABLE

Yes

REMOTE OPERATION CAPABLE

No

LIGHT BULB WATTAGE

75

NIGHTLIGHT OR NIGHLIGHT SETTING

No

DUCTLESS FILTER OR KIT INCLUDED

No

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

RATED VOLTAGE

120

SPEED LEVELS

2

BOOST MODE

No

COUNTRY OF ORIGIN

United States

RATED AMPS

2.5

BUILT-IN TIMER

No

BULB (RECOMMENDED TYPE)

A19

DIMENSIONS

- Height : 6"
- Width : 30"
- Depth : 17.5"

CFM

230 Max

HEAT SENTRY™

No

WATTAGE

300

DUCT DIRECTION

Horizontal/Vertical

DETAIL

The hood is designed for under cabinet use and installs as 3-1/4 in. x 10 in. ducted opening with vertical or horizontal ducting; or 7 in. round vertical ducting or as non-ducted with air recirculation. The hood is equipped with a 230 MAX Blower CFM designed for years of trouble free service, an easy to clean grease filter, a protective lamp lens that distributes light evenly over the cook-top, and control switches for fan speed and light activation

FEATURE

ALL APPLICATIONS

Provides installation flexibility with 4-way convertibility to fit virtually all applications

TACKLE A VARIETY

Two fan speeds help you tackle a variety of venting jobs

SMOKE AND COOKING

230 MAX Blower CFM quickly removes smoke and cooking odors from the air.

WARRANTY

One year limited warranty

CERTIFIED

UL listed and HVI 2100 certified

RANGE HOOD

Vertical and horizontal exhaust option lets you connect the ductwork to the top or rear of the range hood

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

LED LIGHT

Uses up to a 75-Watt in LED light to brightly illuminate the cooking area (bulb sold separately)

EASY INSTALLATION

Includes a 3-1/4 in. x 10 in. damper/adapter and a 7 in. round adapter for easy installation (7 in. damper sold separately)

EASY CLEANING

Enclosed light and fan/filter assemblies, mitered corners and hemmed edges for good looks and easy cleaning

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood

SETTING SEPARATELY

Simple to use rocker switches let you adjust the fan speed and the light setting separately

DISHWASHER-SAFE

Removable, reusable, dishwasher-safe aluminum mesh filter for easy cleaning and maintenance; supports ductless filtration via non-ducted filter (purchase separately)

COLOR FINISH

FINISHES

Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
Stainless Finish
Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
White
Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
Stainless Steel
Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
Black Stainless Steel
Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
Almond
Broan Nutone Broan® F40000 Series Under-Cabinet Range Hood
Black
