Franke Hood Fmas Bk Extra Matt F80 Kl Franke
HOOD FMAS BK EXTRA MATT F80 KL FRANKE
HOOD FMAS BK EXTRA MATT F80 KL FRANKE
EAN/UPC 7612985785303
information
ARTICLE NUMBER
345.0698.564
PRODUCT TYPE
Hood
BRAND
Franke
FINISH
Black Extra Matt
NUMBER OF LAMP
1
HOOD CATEGORY
Suspended
LAMP TYPE
Flush Led Bar L600
PRODUCT SPECIFICATIONS
- Air quality sensor : No
- Energy efficiency : Class A
DIMENSIONS
- Width : 800 mm
- Diam. air outlet : 150 mm
REMOTE CONTROL
Yes
WATERPROOF
No
SPEED SETTING
3+i
24H
No
DELAY
No
SENSOR SELF START
No
WI-FI
No
FILTER TYPOLOGY
Cassette
TYPE OF FILTER
Aluminium
CHARCOAL FILTER
Yes
INSTALLATION
Island
PLUG TYPE
No plug
ANNUAL ENERGY CONSUMPTION AEC
60.1
AIR QUALITY SENSOR
No
ENERGY EFFICIENCY CLASS
A
MODEL RANGE
Maris
ARTICLE NUMBER
345.0698.564
UI TYPE
Touch metal
MOTOR VOLTAGE
220-240V 50-60Hz
NUMBER OF MOTOR
1
MOTOR GR COMM.NAME
SP A+
DOWNLOADS
↓ Fact Sheet
↓ Energy Label 345.0698.564 001
↓ Exploded Drawing 345.0698.564 001
↓ Exploded Drawing 345.0698.564 002
↓ Exploded Drawing 345.0698.564 003
↓ Instruction Manual 345.0698.564 001
↓ Instruction Manual 345.0698.564 002
↓ Instruction Manual 345.0698.564 003
↓ Product Fiche 345.0698.564 001
↓ Tech.3D-Model 345.0698.564 001
↓ Wiring Diagram 345.0698.564 001
F. DYNAMIC EFFICIENCY CLASS
A
LIGHT EFFICIENCY CLASS
A
GREASE FILTERING EFFICIENCY CL
F
PERFORMANCE
| SPEED | 1 | 2 | 3 | BOOST |
|---|---|---|---|---|
| Flow (m³h) | 290 | 420 | 580 | 740 |
| Press. max | 460 | 550 | 570 | 580 |
| Power (Watt) | 150 | 200 | 240 | 250 |
| Noise level (db) | 57 | 60 | 64 | 68 |
GALLERY
