Sony VPL-FHZ85 / VPL-FHZ80 Projectors
VPL-FHZ85 / VPL-FHZ80 PROJECTORS
VPL-FHZ85 / VPL-FHZ80 PROJECTORS
The industry‘s smallest, lightest 8,000 lumen* projectors** with innovative features
VPL-FHZ85 7,300 lm (8,000 lm centre) / VPL-FHZ80 6,000 lm (6,500 lm centre) As of August 2021 (according to Sony research) in 3LCD laser projectors of over 8,000 lm centre brightness
Powerful, compact, light and superbly styled, these 3LCD laser projectors are bursting with the latest Sony innovations to deliver consistently rich, bright, colourful images. With versatile installation options and reduced maintenance they’re ideal for projection in mid-size corporate, education and public environments.
INFORMATION
BRAND
Sony
PRODUCT TYPE
Projector
PROJECTION LENS *1
- Focus : Powered
- Zoom - Ratio : Approx. x 1.6
- Throw ratio : 1.39:1 to 2.23:1
- Zoom - Powered/Manual : Powered
- Lens shift - Range Vertical : -5%, +70%
- Lens shift - Range Horizontal : +/- 32%
- Lens shift - Powered/Manual : Powered
LIGHT OUTPUT *2
-Mode-Middle : 5840lm
-Mode- Standard : 7300lm *3 / 8000lm (Center)*4
DISPLAY SYSTEM
3 LCD system
LIGHT SOURCE
Type : Laser diode
AUTO INPUT SELECT
The Auto Input Select feature automatically selects an active signal input, so there’s no need to change input each time a device is connected to the projector.
SCREEN SIZE
40'' to 600'' (1.02 m to 15.24 m) (measured diagonally)
COLOUR LIGHT OUTPUT *2
- Mode-Middle : 5840lm
- Mode-Standard : 7300lm
AUTO POWER ON
Connect the VPL-FHZ85/80 to a switched-on computer, and the projector turns on automatically without having to operate the power button.
HORIZONTAL
15 kHz to 93 kHz
VERTICAL
23 Hz to 63 Hz
TIME UNTIL LIGHT OUTPUT DECLINES TO 50 %*5
- Mode-Middle : 30000 hours
- Mode-Standard : 20000 hours
DATA CLONING
Settings for one projector can be copied to a second and subsequent projectors using a USB memory drive. This greatly simplifies installation and set-up of multiple projectors.
CONTRAST RATIO (FULL WHITE / FULL BLACK)
∞:1
KEYSTONE CORRECTION (MAX.)
- Horizontal : +/- 30 degrees
- Vertical : +/- 30 degrees
DISPLAY DEVICE
-Number of pixels : 6,912,000 (1920 x 1200 x 3) pixels
-Size of effective display area : New LCD panel 0.76" (19 mm) x 3 BrightEra LCD Panel, Aspect ratio: 16:10
ACCEPTED SIGNAL RESOLUTION
-Computer signal input : Maximum signal resolution: 1920 x 1200 *6
-Video signal input :
NTSC, PAL, SECAM, 480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i, 1080/60p, 1080/50p,3840/60p, 3840/30p, 3840/25p, 3840/24p,4096/60p, 4096/30p, 4096/25p, 4096/24p
OPERATING TEMPERATURE / OPERATING HUMIDITY
0°C to 45°C (32°F to 109°F) / 20% to 80% (no condensation)
USE
Display Image
MASS
Approx. 13 kg (29 lb)
POWER CONSUMPTION (STANDBY MODE)
- AC 100 V to 120 V : 0.5W (when “Standby mode” is set to “Low”)
- AC 220 V to 240 V : 0.5W (when “Standby mode” is set to “Low”)
POWER REQUIREMENTS
AC 100 V to 240 V, 5.1 A to 2.2 A, 50 Hz / 60 Hz
HEAT DISSIPATION
- AC 100 V to 120 V : 1617 BTU/h
- AC 220 V to 240 V : 1727 BTU/h
POWER CONSUMPTION
-AC 100 V to 120 V Mode: Standard: 506 W
-AC 220 V to 240 V
Mode: Standard: 474 W
STORAGE TEMPERATURE / STORAGE HUMIDITY
10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation)
OPTIONAL ACCESSORIES
Projection Lens : VPLL-3003 / 3007 / Z3009 / Z3010 / Z3024 / Z3032
COLORS
- Black
- White
DIMENSIONS (WITHOUT PROTRUSIONS)
460 x 169 x 494 mm (18 1/8 x 6 3/4 x 19 1/2 inches)
STANDBY MODE / NETWORKED STANDBY MODE ACTIVATED
Approx. 10 Minutes
ACOUSTIC NOISE (MODE: STANDARD / MIDDLE)
38 dB / 36 dB
POWER CONSUMPTION (NETWORKED STANDBY MODE)
-AC 100 V to 120 V : 9.8 W (LAN), 10.6 W (HDBaseT), 10.6 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")
-AC 220 V to 240 V : 10.9 W (LAN), 11.6 W (HDBaseT), 11.6 W (All Terminals and Networks Connected) (when "Standby Mode" is set to "Standard")
INPUT OUTPUT (COMPUTER / VIDEO / AUDIO / CONTROL)
-Lan : RJ45, 10BASE-T/100BASE-TX
-Remote : D-sub 9-pin (male) / R
-IR (Control S) : Stereo mini jack, Plug in power DC5V
-USB : TYPE-A (for F/W update) , TYPE-A (for Power supply)
-Input A : RGB / Y PB PR input connector:Mini D-sub 15 pin (female) Audio input connector: Stereo mini jack
-Input B : DVI input connector: DVI-D 24-pin (single link), HDCP support Audio input connector: Shared with INPUT A
-Input C : HDMI input connector: HDMI 19-pin, HDCP support Audio input connector: HDMI audio support
-Input D : HDBaseT interface connector: RJ45, 4 play (Video, Audio, LAN, Control)
-Video In : Video input connector: BNC, Audio input connector: Shared with input A
-Output A : Monitor output for Input A Connector: Mini D-sub 15-pin (female) Audio output connector: Stereo mini jack
-Output B : Monitor output for Input B Connector: DVI-D 24-pin (single link), HDCP not supported
Audio output, Monitor out connector: Stereo mini jack
FEATURES
BOLD, RICH COLOUR EVEN IN BRIGHTLY LIT ROOMS
Even powerful projectors can suffer from washed-out image colours in strongly-lit rooms. Exclusive to Sony, Bright View delivers high-impact images that don’t sacrifice colour. Newly improved Reality Creation ensures images, diagrams and text look clear and sharp, even in bright conditions. Intelligent Settings with Ambiance match projected images with your environment for an enhanced viewing experience: there’s even an ambient light sensor to measure room brightness.
-Clearer images and text : Reality Creation uses powerful algorithms that boost image resolution closer to 4K clarity. Reality Text improves visibility of characters: great for conference rooms and classrooms.
-Bright, beautiful colours : Bright View is Sony’s unique processing technology that brightens images while maintaining rich colour – even in brightly-lit business and educational environments.
-Enhanced viewing experience : Intelligent Settings with Ambiance uses a built-in light sensor to measure room brightness, automatically adjusting Bright View mode, colour gain and Reality Creation to suit your presentation environment.
SOPHISTICATED DESIGN AND SUPERIOR INSTALLATION FLEXIBILITY
The light, compact VPL-FHZ85/80 make an elegant addition to any modern work space. Its understated blend-in design features a flat top surface that minimises visual impact when the projector is ceiling mounted. Installation is simplified with a choice of optional lenses, while a class-leading lens shift capability overcomes challenges like ceiling obstacles and other AV equipment.
-Beautifully slim and stylish : The slim, stylish case design features a flat top surface that blends in discreetly when the projector is ceiling mounted.
-Generous lens shift range : The class-leading vertical +70% lens shift adjustment range offers more installation freedom. A range of lens options suits virtually any room size and throw requirements: the quick-release bayonet simplifies lens exchange.
-4K 60P input capable : The projector’s 4K 60P input capability makes life simpler when you’re using the VPL-FHZ85/80 in multi-screen set ups with other devices like flat panel sub-screens. Just split the same 4K signal to drive all your displays, with no conversion needed.
BRIGHTER FOR LONGER
While other projectors can fade over time, the VPL-FHZ85/80 are engineered to maintain consistent image brightness. An exclusive Intelligent Settings feature automatically monitors real-world usage, optimising settings to keep images consistently bright. The sealed laser light source and automated filter cleaning system prevent dust build-up, ensuring cool, efficient operation with uncompromised image brightness.
-Hassle-free filter cleaning : Focus on great-looking images instead of time-consuming maintenance. The automated filter cleaning system removes dust every 100 hours, ensuring unrestricted clean air intake for optimised cooling.
-Keep dust out of the picture : The laser light source is sealed to prevent dust accumulation and eliminating reduced brightness. The dedicated cooling duct structure for the projector’s 3LCD panels is covered with an air filter to prevent dust from entering.
-Designed with intelligence : Intelligent Settings simplifies installation and maximises performance based on usage, image detail, colour richness and fidelity, light output, cooling level and output noise. The Meeting/Classroom function controls laser output to keep brightness as high as possible for a period of actual usage time.
21:9 SUPPORT OPEN DOORS TO NEW APPLICATIONS
21:9 projection displays offer a new dimension of immersion and engagement across various applications, making them essential for those who seek to captivate, educate, and entertain. In addition to 16:10 and 16:9 aspect ratios, the VPL-FHZ85/80 will now also support 21:9 aspect ratio with 2560×1080 signal input, allowing you to innovatively project ultra-wide hybrid meetings on larger screens that optimize visual presence of remote participants.
When combined with the Ambiance functionality, hybrid meetings are further enhanced by optimizing brightness, color, and resolution depending on the brightness of the conference room, making it easier than ever to see emotive expressions of remote meeting participants while displayed content is being shared.
CRISP, HIGH-IMPACT IMAGES
The use of 4K photos and videos is increasingly common in presentations. While the VPL-FHZ85/80 are WUXGA projectors, they offer a 4K60P input to display images with quality that’s close-to-true 4K resolution.
Reality Creation is Sony’s processing technology that’s been improved for displaying 4K content better, ensuring images look crisper with a stronger feeling of depth.
