Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

1.5 TON 3 STAR WI-FI INVERTER SMART SPLIT AC

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

1.5 TON 3 STAR WI-FI INVERTER SMART SPLIT AC

Copper Condenser, 7 in 1 Convertible with True AI Mode, 2 Way Swing, PM 0.1 Air Purification Filter, 2024 Model, White

Crafted to suit the needs of a modern day household, Panasonic SU Series Air Conditioners come with a host of superior features.

Enabled by Miraie app, this truly smart Panasonic AC can be accessed remotely, and can also be operated via Alexa and Google Home Smart Devices.

Equipped with Converti7, you can manually adjust the AC for 7 stages of cooling capacity. Unlock the future with the coolest features from the no.1 Appliances Brand in Japan.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

INFORMATION

COOLING CAPACITY

-5050 [2270 - 5560] (Min-Max) W
-17230 [7746 - 18971] (Min-Max) Btu/h

COMFORT COOLING

-4
-Way Air Swing : No
-Powerful Mode : Yes
-Converti7 (7-in-1 convertible) : Yes

BRAND

Panasonic

PRODUCT TYPE

Air Conditioner

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

SERIES

SU (YC Series)

TONNAGE CLASS

1.5 Ton

PRODUCTION

Made in Thailand

PHASE


FREQUENCY

50Hz

REFRIGERANT PIPE DIAMETER

- Gas Side : Ø1.270
- Liquid Side : Ø0.635

WARRANTY

- PCB Warranty : 5 Years
- Compressor Warranty : 10 Years
- Comprehensive Warranty : 1 Year

WEIGHT

-N
et Weight Indoor/Outdoor Unit : 9 / 24 kg
-Gross Weight Indoor/Outdoor Unit : 10 / 28 kg

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

REFRIGERANT

R-32

NET QUANTITY

1 U

ECO-TOUGH OUTDOOR CASING

No

STABILIZER FREE OPERATION

145-285V

RATED ANNUAL POWER CONSUMPTION

1002.31

WIDE OPERATING TEMPERATURE RANGE

16 ~ 52°C

NOISE LEVEL INDOOR

- 53 (H/L) [dB-A]
- 48/38 (H/L) [dB-A]

USE

Cooling

COLOR

White

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

ISEER VALUE

3.90

SHIELD BLU+

Yes

INDOOR UNIT DIMENSIONS (Lx B x H)

87cm x 20.4cm x 29cm

OUTDOOR UNIT (L X B X H)

78.1cm x 28.1cm x 55.5cm

CONVENIENCE

- Miraie : Yes
- True AI : Yes
- Crystal Clean : Yes
- Hidden Display(Indoor Unit Panel) : Yes
- Voice Assistant with Amazon Alexa & Hey Google : Yes

STAR RATING

3

INDOOR AIR CIRCULATION

501 (ft³/min )

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

POWER SUPPLY SOURCE

Indoor

VOLTAGE

230 V-AC

CONTENTS OF THE PACKAGE

- Remote : 1N
- Indoor Unit : 1N
- Outdoor Unit : 1N
- AAA Batteries : 2N
- Assembly Manual : 1N

POWERFUL MODE

As temperatures rise outside, so will indoor temperatures. Being outdoors can keep you uncomfortable and sweaty. But that doesn't mean you have to prolong that discomfort after you set foot indoors. Panasonic air conditioners with POWERFUL mode delivers powerful cooling with strong airflow to cool a room quickly, providing an instant relief during hot days.

PM0.1 FILTER

Yes

AG CLEAN + FILTER

No

KEY FEATURES & DETAIL

- Smart Split AC with Auto Convertible Inverter compressor
- Converti7 : 7 Stages of Cooling Performance
- 3 Star Energy Rating for energy efficiency. Suitable for medium sized rooms.
- Warranty : 1 Year Comprehensive | 5 years on PCB |10 years on Compressor.
- Miraie : Connected Living | Comfortable Sleep Profile |Full Control Anytime Anywhere
- Copper Condenser Coil with Shield Blu Technology: For greater durability in high humidity & coastal areas
- Works with Amazon Alexa and Google Assistant |Customized Sleep Profiles | Remote Access and Control with Miraie

FEATURES

INTUITIVE VOICE CONTROL

Introducing intuitive voice control with Google Assistant and Amazon Alexa control compatibility. Using your existing Google assistant or Alexa devices, control your Panasonic air conditioner with just your voice.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

SMART COOLING WITH AI MODE

AI mode powered by Miraie senses external weather conditions like heat and humidity & automatically manages temperature, mode and fan speed to provide best cooling with optimum power consumption.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

STABILIZER FREE OPERATION

Panasonic Air Conditioners are designed to operate under tough conditions with stabilizer free operation for voltage range between. If power fluctuation is beyond the stated limit, then a stabilizer is required.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

ONE TOUCH SERVICE AND SELF DIAGNOSIS

With the intuitive auto-diagnosis feature, our SU Series Air Conditioner is equipped to detect issues in advance and alert users. Backed by superior on touch service, Miraie App allows users to monitor and manage e-warranties easily.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac
Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

CUSTOM SLEEP PROFILE

Indulge in blissful sleep with Panasonic AC's Custom Sleep Profile! Delicately crafted to cultivate an ideal environment for tranquil nights and revitalizing mornings. Experience a personalized haven of supreme comfort with no more midnight chills.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

7-IN-1 CONVERTIBLE AC

While Panasonic Inverter Air Conditioners are truly auto convertible, there is a provision to manually adjust the AC for up to 7 stages of cooling performance ranging from 45% to more than 100%, this can be done via Converti7 button on the remote or on the Miraie app

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

CRYSTAL CLEAN

Through defrosting, frosting, cold expansion, and a mechanism to remove all filth that enters the unit, the AC performs self-cleaning with its Crystal Clean feature. The leftover debris that accumulate in the fans and air ducts are often cleaned by the process.

Panasonic 1.5 Ton 3 Star Wi-fi Inverter Smart Split Ac

A SMARTER WAY TO CONTROL YOUR AIR

Miraie delivers convenient control, connectivity and comfort. Seamlessly adjust temperature, monitor status and change modes right from the Miraie App. With MirAIe, you can switch your Panasonic Air Conditioner on and off from anywhere, anytime. You can even pre-set the AC temperature as per your sleep profiles. It also notifies you about the indoor pollution level and the need to turn on the Nanoe-G technology. Through MirAIe, call for service is just a touch away.
