Elica Mezzano Hood

MEZZANO HOOD

Elica Mezzano Hood

NMEZZANO HOOD

Designed by Elica Design Center

Perfect blend of minimalist elegance and durability with Mezzano island range hood, featuring sleek black glass touch controls and a strong stainless steel construction.

FEATURES

LED LIGHT

Illuminate your culinary journey with LED brilliance
An expected lifetime of over 20,000 hours represents the most remarkable advantage of LED light bulbs.

Elica Mezzano Hood

HUSH SYSTEM

Silent innovation, redefine tranquility An exclusive sound-deadening technology that effectively reduces sound levels by over 35%

Elica Mezzano Hood

TOUCH CONTROL HOOD

Experience the power behind the touch with soft blue illumination Multifunction electronic touch control behind sleek black glass illuminates soft blue when activated.

Elica Mezzano Hood

TOP PERFORMANCE

High fume capture, low noise – the perfect balance.
Excellent performance for models equipped with this plus. High fume capturing capacity with an average aspiration range of 600 CFM’s with low noise levels, 1.2 - 1.7 sones at working speed.

Elica Mezzano Hood

INFORMATION

LIGHTING

Premium Dimmable LED 2 x 2.1 ww 4000 KK

BRAND

Elica

PRODUCT TYPE

Hood

INSTALLATION TYPE

Ducted or recirculating with kit (sold separately)

Elica Mezzano Hood

FINISHING

Stainless Steel + Black Glass

WARRANTY

2 Year

DUCT TRANSITION

Round 6"

SIZES (INCH)

36" x 9 11/16” x 29 11/16” x 36"

SERIES

Techne

VENTING TYPE

Convertible With Kit

GREASE FILTERS

Stainless Steel Microhole Filter

DIMENSIONS EMZ630S3/EMZ636S3

- A : 30” (76.2 cm) /36” (91.4 cm)
- B : 19 /₁₆” (50cm)
- C* Min: 33 /₈” (86 cm) /Max: 54 /₄” (139 cm)
- D** Min: 29 /₁₆” (77cm) /Max: 50 /₁₆” (129 cm)
- E : 6” (15.24 cm)
- F : 10 ³/₄” (27 cm)
- G : 13” (33 cm)
- H : 2 /₁₆” (6 cm) /2 /₈” (4 cm)
- I : 16 /₈” (40.8 cm)

Elica Mezzano Hood

CONTROLS

Multi-function Electronic with black glass touch display

MODEL

EMZ630S3

WIDTH

36"

Elica Mezzano Hood

AIRFLOW

600cfm

VOLTAGE

120 V

TELESCOPIC CHIMNEY

Can reach ceiling heights of min 7’6”, max 10’2” (ducted out) & min 7’10”, max 10’6” (recirculating)

TECHNOLOGY AND PERFORMANCE AT HOME.

With a minimalist design but a strong stainless steel construction, the Mezzano island range hood is in tune with avant-garde appliances where clear and architectural lines take precedence. Mezzano has a powerful 600 CFM blower, LED dimmable stainless steel microhole filters, and high-tech multi-function touch controls that deliver convenience and safety. Mezzano was designed for standard ducted installation, but can also be installed using the Recirculating Kit, available as an accessory.

BLOWER TYPE

Interior Unit

SONES

1.7 - 6.8
