Steel pellet stove, available in 8 versions (air, ducted, hydro and with Core technology).

FEATURES

CLEANING AUTONOMY

The amount of ash generated by the stove is minimal, and what little unburnt material remains is removed through a self-cleaning brazier that is activated automatically. Cleaning the firebox thus turns into a quick and easy chore that is only done once a week.

Mcz EGO Stove

TOTAL SILENCE, WHEN YOU WANT

The No-Air function allows you to completely exclude the forced ventilation in this stove, ensuring maximum silence and all of the advantages of heat diffused throughout the room by natural convection.

Mcz EGO Stove

SEALED STRUCTURE AS STANDARD

Thanks to a perfectly sealed combustion chamber, this product uses up the oxygen taken exclusively from the outside, ensuring reduced consumption and perfect thermal comfort in modern homes, even those with class A energy rating, with no risk of smoke emissions in the room.

Mcz EGO Stove
Mcz EGO Stove

CHOOSE THE UP! VERSIONS TO TAKE UP LESS SPACE

This stove is also available with the smoke outlet on the top instead of the back. This allows for installation flush with the wall, which reduces the depth of the stove and, consequently, optimises space in the home.

Mcz EGO Stove

NEW TOP WITH MORE SPACE FOR PELLET LOADING

The new Ego top has no conventional holes and slots, nevertheless heat is easily ejected through the groove between cast iron and sheet metal, taking advantage of its entire perimeter and hiding the technical parts below. The opening of the pellet loading door has been increased by +15% on all versions to make filling operations easier.

Mcz EGO Stove

EVEN MORE BEAUTIFUL VIEW OF THE FLAME

The combustion chamber is brand new, larger and more proportionate, to offer an even more breathtaking view of the fire. The height and depth of the firebox have been increased, ensuring vertical development and a more natural movement of the flame. The firebox and crucible have been cleaned also and their shape softened for an enjoyable viewing experience, even when the flame is out.

INFORMATION

BRAND

MCZ

COLLECTION

Tecla

PRODUCT TYPE

Stove

PRODUCTION

Made in Italy

Mcz EGO Stove

ENERGY EFFICIENCY CLASS (SCALE A++/G)

A+

SEASONAL SPACE HEATING ENERGY EFFICIENCY (ΗS)

85.00 %

MODEL

Ego Comfort Airmatic 10r M3 Core (7124032)

TEMPERATURE OF EXHAUST SMOKE

182.00 °C

HEATABLE VOLUME

- 20W/m³ : 500.00 m3 (*)
- 35W/m³ : 286.00 m3 (*)
- 55W/m³ : 182.00 m3 (*)

AVAILABLE COLORS

4

HOPPER CAPACITY

39.00 lt

DIMENSIONS

- Pitch : 52.6 cm
- Length : 53 cm
- Height : 104.1 cm

COLORS

Mcz EGO Stove
Metal White
Mcz EGO Stove
Metal Bordeaux
Mcz EGO Stove
Metal Silver
Mcz EGO Stove
Metal Dark

EFFICIENCY

- Max : 88.00 %
- Min : 92.90 %

HOURLY CONSUMPTION

- Max : 2.30 kg/h (**)
- Min : 0.60 kg/h (**)

DOWNLOAD

↓ Datasheet

SMOKE OUTLET

80 mm

NET WEIGHT

133.00 kg

MASS OF SMOKE

6.40 g/s

AUTONOMY

- Max : 11.00 h (**)
- Min : 42.00 h (**)

HEAT OUTPUT

- Nominal Heat Output : 10.00 kW
- Minimum Heat Output : 2.40 kW

DETAIL

Mcz EGO Stove

A STOVE THAT IS ALMOST A BOILER: ALL THE HEAT YOUR SYSTEM NEEDS

This is a hydro stove, which not only heats the air in the room, but also the water in the heating system. It is ideal whether you have normal radiators or an underfloor heating system in the house. The optimal efficiency of this stove allows you to have the whole house warm in a few minutes. More than 90% of the stove's power output is transferred to the water in the system.

THE RIGHT LEVEL OF COMFORT FOR A ROOM OR OPEN SPACE

This is an air stove, the most classic model of pellet stove. A single fan, powerful yet quiet, efficiently distributes the warm air in the room where the stove is installed, making it warm and cosy within minutes.

Mcz EGO Stove

Depending on how well insulated your home is and how it is laid out, this stove can also heat very large rooms. You can choose the fan power according to your needs. A warm, powerful breeze to heat up your home quickly or a barely perceptible whispering sound if you just need to keep the same temperature.

STEEL PELLET STOVE, AVAILABLE IN 8 VERSIONS (AIR, DUCTED, HYDRO AND WITH CORE TECHNOLOGY)

Pellet stove made with a steel structure, cast iron top and painted steel sides color White, Dark, Silver, Bordeaux. New 2022 restyling, which enhances the aesthetic performance of the flame.

Mcz EGO Stove

Thanks to the Maestro+ technology, the stove can be controlled directly from a smartphone, via a specific App, which provides full control either at home or away, by connecting via the home internet network (router) or directly via Bluetooth. An innovative retractable digital control panel fitted on the top is also available as standard.

HEAT THAT GOES A LONG WAY

This is a ducted stove, which allows several rooms to be heated simultaneously. The hot air produced by the stove is transported to other rooms in the house through wall pipes. With the Comfort Air® system, patented by MCZ, the air can reach a distance of up to 8 metres and guarantees an outlet temperature of up to 80°C.

Mcz EGO Stove

To complete the Comfort Air kit, MCZ proposes particularly neat and minimalist diffusers, designed for those who love detail even in the diffusion of heat. Unlike traditional systems in which the air outlets must be positioned at the top, MCZ diffusers can be installed freely, wherever you are most comfortable, even close to the floor.

CERTIFICATIONS

Mcz EGO Stove

CERTIFIED

This stove has been certified 7 stars Flamme Verte.

Mcz EGO Stove

ENERGY EFFICIENCY

This stove is in the A+ energy efficiency class.

Mcz EGO Stove

CONTO TERMICO

This product is eligible for a contribution from the Conto Termico, if installed to replace certain types of existing heating systems.

Mcz EGO Stove

ECODESIGN

This product is already compatible with EU Regulation Ecodesign 2022.

Mcz EGO Stove

TEST STANDARDS

Test standards: EN 14785, BimSchV 2nd stage, Regensburger/ Aachener/ Münchener BStV (Germany), Art 15a B-VG (Austria), LRV (Switzerland).

Mcz EGO Stove

PULITA SCHEME

This product guarantees high environmental performance, certified 4-star according to the emission and efficiency parameters of the Aria Pulita scheme.
