EGO STOVE
EGO STOVE
Steel pellet stove, available in 8 versions (air, ducted, hydro and with Core technology).
FEATURES
SEALED STRUCTURE AS STANDARD
Thanks to a perfectly sealed combustion chamber, this product uses up the oxygen taken exclusively from the outside, ensuring reduced consumption and perfect thermal comfort in modern homes, even those with class A energy rating, with no risk of smoke emissions in the room.
NEW TOP WITH MORE SPACE FOR PELLET LOADING
The new Ego top has no conventional holes and slots, nevertheless heat is easily ejected through the groove between cast iron and sheet metal, taking advantage of its entire perimeter and hiding the technical parts below. The opening of the pellet loading door has been increased by +15% on all versions to make filling operations easier.
EVEN MORE BEAUTIFUL VIEW OF THE FLAME
The combustion chamber is brand new, larger and more proportionate, to offer an even more breathtaking view of the fire. The height and depth of the firebox have been increased, ensuring vertical development and a more natural movement of the flame. The firebox and crucible have been cleaned also and their shape softened for an enjoyable viewing experience, even when the flame is out.
INFORMATION
ENERGY EFFICIENCY CLASS (SCALE A++/G)
A+
SEASONAL SPACE HEATING ENERGY EFFICIENCY (ΗS)
85.00 %
MODEL
Ego Comfort Airmatic 10r M3 Core (7124032)
TEMPERATURE OF EXHAUST SMOKE
182.00 °C
HEATABLE VOLUME
- 20W/m³ : 500.00 m3 (*)
- 35W/m³ : 286.00 m3 (*)
- 55W/m³ : 182.00 m3 (*)
AVAILABLE COLORS
4
HOPPER CAPACITY
39.00 lt
DIMENSIONS
- Pitch : 52.6 cm
- Length : 53 cm
- Height : 104.1 cm
EFFICIENCY
- Max : 88.00 %
- Min : 92.90 %
HOURLY CONSUMPTION
- Max : 2.30 kg/h (**)
- Min : 0.60 kg/h (**)
DOWNLOAD
↓ Datasheet
SMOKE OUTLET
80 mm
NET WEIGHT
133.00 kg
MASS OF SMOKE
6.40 g/s
AUTONOMY
- Max : 11.00 h (**)
- Min : 42.00 h (**)
HEAT OUTPUT
- Nominal Heat Output : 10.00 kW
- Minimum Heat Output : 2.40 kW
DETAIL
A STOVE THAT IS ALMOST A BOILER: ALL THE HEAT YOUR SYSTEM NEEDS
This is a hydro stove, which not only heats the air in the room, but also the water in the heating system. It is ideal whether you have normal radiators or an underfloor heating system in the house. The optimal efficiency of this stove allows you to have the whole house warm in a few minutes. More than 90% of the stove's power output is transferred to the water in the system.
THE RIGHT LEVEL OF COMFORT FOR A ROOM OR OPEN SPACE
This is an air stove, the most classic model of pellet stove. A single fan, powerful yet quiet, efficiently distributes the warm air in the room where the stove is installed, making it warm and cosy within minutes.
Depending on how well insulated your home is and how it is laid out, this stove can also heat very large rooms. You can choose the fan power according to your needs. A warm, powerful breeze to heat up your home quickly or a barely perceptible whispering sound if you just need to keep the same temperature.
STEEL PELLET STOVE, AVAILABLE IN 8 VERSIONS (AIR, DUCTED, HYDRO AND WITH CORE TECHNOLOGY)
Pellet stove made with a steel structure, cast iron top and painted steel sides color White, Dark, Silver, Bordeaux. New 2022 restyling, which enhances the aesthetic performance of the flame.
Thanks to the Maestro+ technology, the stove can be controlled directly from a smartphone, via a specific App, which provides full control either at home or away, by connecting via the home internet network (router) or directly via Bluetooth. An innovative retractable digital control panel fitted on the top is also available as standard.
HEAT THAT GOES A LONG WAY
This is a ducted stove, which allows several rooms to be heated simultaneously. The hot air produced by the stove is transported to other rooms in the house through wall pipes. With the Comfort Air® system, patented by MCZ, the air can reach a distance of up to 8 metres and guarantees an outlet temperature of up to 80°C.
To complete the Comfort Air kit, MCZ proposes particularly neat and minimalist diffusers, designed for those who love detail even in the diffusion of heat. Unlike traditional systems in which the air outlets must be positioned at the top, MCZ diffusers can be installed freely, wherever you are most comfortable, even close to the floor.
CERTIFICATIONS
