SOL STOVE
SWING STOVE
Pure aesthetic lines.
Characterised by its exclusive and timeless design. Elegant stove with an extraordinary body.
FEATURES
INFORMATION
BRAND
Rika
PRODUCT TYPE
Stove
COLLECTION
Sol
ENVIRONMENT
Interioe
ROOM HEATING CAPACITY (DEPENDING ON HOUSE INSULATION)
90 - 210 [m³]
NOMINAL HEAT OUTPUT
8 kw
PARTIAL HEAT OUTPUT
4 kw
THERMAL MASS
~90 kg
PRODUCTION
Made in Austria
WEIGHT
- Weight Without Stones : ~120 kg
- Weight With Stones : ~195 kg
FIRING CHAMBER DIMESNIONS
- Width : 320 mm
- Height : 380 mm
- Depth : 280 mm
DIAMETER
125 mm
SIDE DISTANCE
270 mm
FUEL CONSUMPTION
1.1 - 2.2 kg/h
EFFICIENCY
83.2%
USE
Heating
COLOR
Black
CONNECTION HEIGHT
193 mm
RATED HEATING OUTPUT (8 KW)
This is the "normal heating capacity" determined according to DIN 18891. The stove is checked and the room heating capacity is determined according to this rating. The nominal heating capacity is particularly crucial for a safe heating procedure ant the functionality of the chimney. The combustion of a defind quantity of fuel is necessary to achieve the nominal heating capacity. This quantity of fuel is specified in the instruction manuals provided with RIKA stoves. The actual heating capacity of a stove is determined by the amount of fuel actually applied. The following applies as a "rule of thumb". 1 kg of wood generates a heating capacitt of around 3 kw in a stove.
DOWNLOADS
↓ Eu-declaration Of Conformity Wood
↓ Eu-declaration Of Conformity Rikatronic
↓ Declaration Of Performance Sol-sol R4
↓ Ce-declaration Of Conformity Sol-sol R4
↓ Ce-declaration Of Conformity Sol 6 Kw-sol R4 6 Kw
↓ Technical Documentation Sol-sol R4 - Ecodesign
↓ Technical Documentation Sol 6 Kw-sol R4 6 Kw - Ecodesign
DETAIL
The SOL model is quite striking, thanks to the natural vibrancy of its stone panels and its special body shape that makes it the perfect choice for installation in corners. This stove is also available with the RIKATRONIC4 system which controls your stove automatically at every stage of combustion, achieving a reduction in fuel consumption and emissions.
FLUE PIPE CONNECTION
- Flue pipe outlet : 130 mm
- Rear connection height : 885 mm
- Original angle pipe total depth : 694 mm
- Original angle pipe side distance : 270 mm
- Rear connection side distance : 270 mm
- Original angle pipe connection height : 1619 mm
- Original angle pipe distance to rear wall : 199 mm
- Deapth from rear wall to middle of flue pipe : 184 mm
ENERGY EFFICIENCY CLASS
A+
CHIMNEY DRAFT REQUIREMENT
12 [Pa]
3 STEPS TO THE STOVE
With just a few clicks you can get even closer to your dream stove: choose the material and colour of the body and side panels to suit your personal taste, select also the matching accessories such as stove-pipes and base plates. You can then download your configuration as a pdf file and take it with you when you meet with your RIKA dealer.
