Rotel RA-6000 Amplifier
RA-6000 AMPLIFIER
RA-6000 AMPLIFIER
The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.
INFORMATION
BRAND
Rotel
PRODUCT TYPE
Amplifier
PRODUCTION
Made in Japan
DAMPING FACTOR
600
DIGITAL TO ANALOG CONVERTERS
Texas Instruments
TOTAL HARMONIC DISTORTION (THD)
<0.0075%
INTERMODULATION DISTORTION (60Hz:7kHz, 4:1)
<0.03%
NET WEIGHT
18.81kg (41.47lbs.)
OUTPUT IMPEDANCE
100Ω
USE
Entertainment
PREOUT LEVEL
1.9V
BLUETOOTH
Wireless aptX™ HD and AAC Bluetooth
POWER OUTPUT
- Maximum : 350W/Ch (4Ω)
- Continuous : 200W/Ch (8Ω)
FRONT PANEL HEIGHT
3U / 132.6mm (5.25")
POWER CONSUMPTION
380W
COAX/OPTICAL DIGITAL INPUT SIGNALS SPDIF LPCM
Up to 24-bit/192kHz
COLORS
- Silver
- Black
S/N RATIO (IHF "A" WEIGHTED)
- Phono Input : 80dB
- Digital Inputs : 102dB
- Line Level Inputs : 103dB
INPUT OVERLOAD
- Phono Input : 52mV
- Line Level Inputs (RCA) : 3.5V
- Line Level Inputs (XLR) : 4.5V
CONTROL
Remote Control
AVAILABLE COLORS
2
SOURCE
Analog & Digital
TESTED
Certified Roon Tested
INPUT IMPEDANCE
- Digital Inputs : 75 Ohms
- Phono Input (MM) : 47kΩ
- Line Level Inputs (RCA) : 5.6kΩ
- Line Level Inputs (XLR) : 100kΩ
FREQUENCY RESPONSE
- Line Level Inputs : 10Hz - 100kHz, ±0.5dB
- Digital Inputs : 10Hz - 90kHz, ±2dB
- Phono Input : 20Hz - 20kHz, ±0.5dB
PC-USB
- USB Audio Class 2.0 (up to 32-bit/384kHz)* *Driver installation required
- MQA and MQA Studio (up to 24-bit/384kHz ) Roon Tested
CONVERTER
Texas Instruments
premium 32-bit/384kHz
Digital to Analog Converter
DIMENSIONS
- Width : 431 mm (17")
- Height : 144 mm (5.7”)
- Depth : 425 mm (16")
BTU (4 OHMS, 1/8TH POWER)
1239 BTU/h
STANDBY POWER CONSUMPTION
<0.5W
PANEL
Front panel controls, back-lit IR remote and 2-line display ensure intuitive operation.
SYSTEM
Ethernet, RS232,12V trigger and external remote input simplify integration with control systems.
POWER REQUIREMENTS
- 120V
- 60Hz
DETAIL
The Diamond Series RA-6000 Integrated Amplifier celebrates Rotel’s 60-Years of Japanese heritage. The RA-6000 supports a wide array of modern and legacy analog and digital sources delivering 350 watts of Class AB power into 4 ohms with exceptional acoustic detail and controlled rich, deep bass energy.
Digital inputs support 24-bit/192kHz audio streams. The asynchronous PC-USB input supports up to 32-bit/384kHz audio, decodes and renders MQA, and is fully certified Roon Tested. A Moving Magnet Phono stage is also included for vinyl fans.
